Vax V-037 Produktinformationsblatt
UK SERVICE & HELP - VAX CARE 0870 6061248
Mon-Fri. 9.00am to 5.00pm. An answer phone is available out of these hours. If you have queries or concerns about using your VAX, call the HELPLINE. Calls are charged at the UK national rate.
Please make a note of the serial number and model number of your VAX before calling. There are over 400 approved VAX Service Agents in the UK . For your nearest Service Agent please call VAX Care.
V-037 Easy Guide
2
1Hanging loop
2Vac on/off button
3Vac on/off lock
4Mid-handle grip
5Cleaning solution tank
6Dust canister release button
7Dust canister
8Mop head
9Vacuum cleaner nozzle
10 Cleaning pads
11 Charger
12 Multi Hard Floor cleaner
13 Solution dispensing trigger
14 Solution tank release button
15 Charger input
16 Charging indicator
*NOT MEANT FOR USE
WITH WAX BASED FLOORS
Parts checklist
1
2
3
4
5
6
7
9
8
10
11
12
13
4
5
14
15
16
FRONT BACK
3
To assemble the handle:
Insert the handle into the body of the unit and
push down firmly until it locks into place. Be sure
to line up the button on the handle with the notch
on the body, to help guide the lower handle into
the body. The pin should be visible in the hole on
the body. NOTE: The vacuum may turn on during
handle assembly. To turn the vacuum off, press
the trigger on the handle once.
To disassemble the handle: Use a ball point
pen to push the button in while pulling the handle
up and out of the body of the cleaner.
Connect the charger to a wall socket.
NOTE: Charge for 24 hours before first use.
Plug the charger end into the side of the unit.
NOTE: The indicator light will come on to
indicate that the appliance is charging. Unit
will be charged in 16-24 hours. The light will
not change colour when the unit is charged.
Putting your cleaner together Charging
NOTE: Only use the charger supplied.
CHARGE 24 HOURS BEFORE FIRST USE.
Notch
Top view of cleaner
Storage Recommended use
Use the storage hook to hang the cleaner up.
NOTE: Hang in a place convenient for charging.
Use the dry vacuum to remove loose dirt and debris
from floors.
Wet mop by dispensing the cleaning solution and
using an absorbent pad to remove dirt and grime.
123
4
5
Operating the Vac ‘n’ Mop
FOR ADVICE ON CLEANING SOLUTIONS AND ABSORBENT CLEANING PADS, PLEASE CALL VAX CARE ON 0870 6061248.
NOTE: This product is intended for dry pick up only. Do not attempt to vacuum up any liquids with this cleaner.
Prepare Vac’n’Mop
Lift the vacuum nozzle. It should lock into position. Place one absorbent cleaning pad on to the mop
head of the unit. Secure by pushing the edge of the
cloth into the tabs.
Push the vacuum nozzle back to the floor cleaning
position.
456
6
Operating the Vac ‘n’ Mop
Prepare Vac’n’Mop
Unscrew the cap from the top of the cleaning solution
tank.
Mix one cupful of the Multi Hard Floor cleaner per litre
of water and pour into the solution tank. Replace the
cap on the solution tank.
NOTE: If needed, the solution tank can be removed
from the body of the unit. When the bottle is removed
from the appliance, cleaning solution may be visible in
the bottle recess. This is normal and will not cause any
problems with your appliance.
To remove: Push the tank release button and pull the
tank up and out of the housing.
To return: Firmly push the tank down until it locks into
place.
789
7
Operating the Vac ‘n’ Mop
Vacuum Mop
To turn the vacuum on: Push the on/off button down (a).
To lock the vacuum on:Slide the lock button forward (b).
Pull back with the thumb to unlock.
To dispense the solution: Pull the trigger on the back of the handle (c).
For best results, clean one small area at a time. Spray the solution by holding the
trigger down for 3-4 seconds. This will dispense enough solution to clean approx 1
square yard. Mop as you normally would, using the absorbent cleaning pad. NOTE:
For tough spots and stains, spray the solution directly on to the spot or stain. Allow
the solution to soak for a few minutes, then mop with an absorbent cleaning pad.
10 11
cb
a
Dust canister and filter: removal
IMPORTANT: FOR BEST RESULTS, CLEAN THE FILTER AFTER EACH USE. FOR ADVICE ON FILTER REPLACEMENT, PLEASE CALL VAX CARE ON 0870 6061248
NOTE: This product is intended for dry pick up only. However, if a wet spill is accidentally vacuumed into the dust canister, the filter should be rinsed thoroughly, then allowed to
air dry completely before re-using.
Press the dust canister release button located above
the cup on the body of the unit. Tip the dust canister
out to remove.
Grasp the centre tab on the filter and pull it out of
the dust canister. Pull the filter away from the
protector. Remove debris from the filter and filter
protector.
Empty the contents into a waste bin.
For best results, shake and lightly
tap the filter against the waste bin to
remove remaining dirt.
12 13 14
8
9
Dust canister and filter: removal
Return the filter to the filter protector and return to the
dust canister.
Re-attach by aligning the tab on the dust canister with
the slot on the body of the unit.
Tilt and push the dust canister until it locks into place.
15 16 17
Tab
Slot
Troubleshooting
PROBLEM
Cleaner won’t run
Cleaner won’t pick-up/loss of suction
Cleaner won’t spray solution
Dust escaping from cleaner
POSSIBLE REASONS
1. Battery not charged.
2. Handle not pushed into housing.
3. Battery dead - won’t hold a charge.
4. Needs service.
1. Dust canister full.
2. Filter dirty.
3. Battery charge getting weak.
4. Hose clogged.
1. Battery charge getting weak.
2. Nozzle clogged.
3. Solution tank not fully engaged.
4. Solution tank empty.
1. Dust canister full.
2. Filter dirty.
POSSIBLE CAUSES
1. Charge battery. For first use, charge for at least 24
hours.
2. Make sure handle is pushed firmly all the way into
housing and pin is visible in the hole in the body.
3. Call VAX CARE on 0870 6061248.
4. Call VAX CARE on 0870 6061248.
1. Empty dust canister
2. Remove filter and clean.
3. Charge battery.
4. Remove dust canister and check inside hose for
any obstruction(s).
1. Charge battery.
2. Call VAX CARE on 0870 6061248.
3. Remove and replace solution tank.
4. Refill solution tank.
1. Empty dust canister.
2. Clean or replace filter.
10
VAX CARE 0870 6061248
Battery Disposal
NOTE: You must never use ordinary batteries for replacement, as these may leak and cause damage.
This product contains Nickel-Cadmium battery and must be disposed of properly. For disposal information, call the VAX care helpline on 0870 6061248
WARNING: TO REDUCE RISK OF PERSONAL INJURY - UNPLUG CLEANER BEFORE SERVICING.
