Vicon Extra 328 Bedienungsanleitung
Extra 328-332-336-340
Assembly instructions
Translated from the original assembly manual
Version 01.2013
Date printed 02.2013
Language EN
Document number KT19001203EN
Index number 2013-01
INSTRUCTIONS FOR RECIPIENTS
These instructions describe how to unpack and assemble the machine.
The machine is split into main components which are out together using these assembly instructions. Follow
the order for assembly given in the instructions and use the size and type of bolt shown for assembling the
parts - see the symbols below.
This warning symbol denotes instructions which concern your safety and that of others.
Generally speaking, machines must only be assembled by trained service personnel who are able to use
workshop equipment in complete safety. Assembly of some machines also requires knowledge of how to use
the tractor's hydraulics or hydraulic pump station.
Avoid loose, trailing clothing that can get caught in the machine's parts!
Use the personal protective equipment required for the work being carried out.
Only use approved, sturdy lifting equipment. Protect the lifting equipment from sharp edges and prevent any
chains form twisting.
For safety reasons, before the machine is used for the first time, the accompanying instructions
must be read carefully.
Kverneland Group Kerteminde AS
DK-5300 Kerteminde - Denmark
Phone/Fax: +45 65 19 19 00 / +45 65 19 19 99
web: www.kvernelandgroup.com
Copyright Kverneland Group Kerteminde AS, Denmark. Copying,reproduction in any form, translation, or use of excerpts or parts of this document
are not permitted without specific permission from Kverneland. All rights reserved. The contents of these operating instructions may be changed
without prior warning. Rights reserved for technical amendments.
Round head bolts
Hex head bolts
Contents
3
Contents
The meaning of the symbols
This symbol indicates tips or additional
information.
This warning triangle indicates important safety
information and dangers. If this is not complied
with, it can lead to:
•Serious errors with the machine's operation.
•Damage to the machine.
•Injury or accidents.
Torque moment
Tightening torque for grade 4.6 - 5.8 - 8.8 - 10.9 -
12.9 black and/or galvanised and ungreased
bolts when tightened on smooth surfaces or plain
washers.
For safety reasons, always use original parts.
Dim.
Bolt grade
4.6 5.8 8.8 10.9 12.9
Nm ft/lb Nm ft/lb Nm ft/lb Nm ft/lb Nm ft/lb
M5 2 1.6 3.5 2.5 5.5 4 8 6 10 7
M6 3.5 2.6 64.5 10 714 10 17 12
M8 9 6.4 15 10.5 24 17 33 23.5 40 28.5
M10 17 12 29 21 47 33.5 65 46.5 79 56.5
M12 3021.55136.581 5811481.513697
M14 48 34 80 57 128 91.5 181 130 217 155
M16 74 53 123 88 197 141 277 200 333 238
M18 103 73.5 172 123 275 196.5 386 275 463 330
M20 144 103 240 171.5 385 275 541 386.5 649 463.5
M22 194 138.5 324 231.5 518 370 728 520 874 624
M24 249 178 416 297 665 475 935 668 1120 800
Assembly
4
Assembly The transport safety device is removed from
the hitch.
Fit the hitch on the tractor.
Connect the hydraulics to the tractor.
Remove the springs from the chain.
Pull in the cord.
Activate the tractor's hydraulic system and
swivel the arm down.
Assembly
5
Remove the bolt and bushing from the arm.
Apply oil or grease to the bushings.
Inject some grease or viscous oil into the
groove for the O-ring on both sides of the
hinged points on the arm.
Fit O-rings on both sides of the hinged points
on the arm.
58.237.000
Groove for O-ring.
58.237.000
Groove for lubricating.
O-rings
Assembly
6
Model 340 only
Fit the bracket.
Fit the guard.
M12x40
M12
M10x30
M10
M10
M10x25
M10
M10
Assembly
7
Fit the tarpaulin.
Fit the shock absorber.
Attach the tarpaulin
M10x60
M10
M10
M10x55
M10
M10
M16
M16
M10x25
M10
M10
Assembly
8
Fit the arm on the cutting unit.
The machine's cutting unit can be moved 130
mm so that the attachment point is moved as
shown.
When the attachment point is moved, the PTO
shaft is shortened.
See the Instruction manual for further instruc-
tions.
Apply oil or grease to the bushings before
fitting.
Tighten the bolt to a torque of 650 Nm (480 ft/
lb).
650 Nm
(480 ft/lb)
58.237.000
58.237.000
Assembly
9
Fit and secure the steel wire on the cutting
unit.
Fit the PTO shaft onto the bevel gear.
Remember that the friction clutch on the PTO
shaft must be fitted with the bevel gear.
Assembly
10
Secure the PTO shaft with the chain.
Fit the PTO shaft onto the cutting unit.
Do not forget the clamping ring!
Fit and secure the guard on the cutting unit.
Rotate the sleeve so that the lubrication hole in the universal joint is turned as
shown.
