Vista Quantum Evolution QUANTUM04-XXEVs Bedienungsanleitung
KD16-0205E
Quantum Evolution –Installation and User manual
User and programming manual for
Vista‟s Quantum Evolution range of
DVR.
Including:
QUANTUM04-XXEVs
QUANTUM04DVDXXXEVs
QUANTUM08DVDXXXEVs
QUANTUM16DVDXXXEVs
IntelligentSecurity&Fire
2
Quantum Evolution installation and user manual
This page is intentionally left blank
IntelligentSecurity&Fire
3
Quantum Evolution installation and user manual
CE INFORMATION
The product must be installed according to the currently valid installation regulations
for EMC to guarantee the designed use and to prevent EMC problems.
The device supplied with this manual is according to the EC, EMC Directive,
89/336/EEC & LVD 73/23/EEC
Standard used for showing compliance with the essential requirements of the device:
EN 55022
EN 61000-3-2
EN 61000-3-3
EN 50130-4
EN 55024
LVD: EN60950-1
ELECTRICAL SAFETY
Explanation of electrical safety symbols
IntelligentSecurity&Fire
4
Quantum Evolution installation and user manual
This page is intentionally left blank
IntelligentSecurity&Fire
5
Quantum Evolution installation and user manual
Contents
Description
Page No
Safety Precautions
8
Contents of packaging
9
Features
10
Front Panel
11
Rear Panel connections
13
System Connection diagram
15
Remote Control
16
OSD Description ( On Screen Display )
17
Menu Tree
18
Default Password
20
Main Menu
21
Menu Navigation
21
DISPLAY
21
Camera Covert
21
Cameras Name
21
OSD on/off
21
Set Display Sequence
22
Event Clear
22
Camera Control
23
RECORDING
24
Global Parameters
24
Normal Record
25
Alarm Recording
26
Motion Recording
28
Schedule Recording
30
Recording Priority
32
SYSTEM
33
Basic
33
IntelligentSecurity&Fire
6
Quantum Evolution installation and user manual
Disk Format
36
Password Change
36
Client Account
37
Program Update
38
Sensor
40
Auto Delete Mode
40
PTZ Set-up
41
PTZ Control
42
NETWORK
43
DDNS
43
IP SET
44
EVENT NOTIFICATION
45
E-Mail Registration
45
E-Mail Report
46
Notification Out
46
SEARCHING VIDEO FOOTAGE
47
Date / Time Search
47
Calendar Search
48
DOWNLOADING EVIDENCE
50
LOG
52
VISTA –VIEWER SOFTWARE
53
Minimum PC Specification
53
Live monitoring
54
Recording and Playing back
55
Downloading of video from Quantum Hard drive to PC
57
Playback video downloaded to PC
60
Playback video on PC direct from Quantum hard drive
62
PTZ Control via software
64
SET-UP
65
Remote Set-up
65
Local Set-up
67
Firmware Upgrade
68
IntelligentSecurity&Fire
7
Quantum Evolution installation and user manual
Explanation of on screen buttons
70
APPENDIX 1 –Alarm Sensor Installation
72
APPENDIX 2 –DYNAMIC IP (Supporting DDNS)
75
APPENDIX 3 –Setup for DVR port / Web server port using IP Sharing router
( Port Forwarding)
77
APPENDIX 4 –Making a partition on an External USB hard drive
79
APPENDIX 5 –System Specification
85
IntelligentSecurity&Fire
8
Quantum Evolution installation and user manual
SAFETY PRECAUTIONS
CAUTION BEFORE USE
Please read this manual before installing or using the Vista Quantum DVR.
Please keep this manual in a safe place, to allow for future reference
For the safety and proper use, The DVR is marked with various symbols. Please read these
to prevent injury of financial loss.
INSTALLATION SITE
Ensure installation position is level, secure and adequately ventilated.
Avoid installing close to sources of humidity or water.
IntelligentSecurity&Fire
9
Quantum Evolution installation and user manual
CONTENTS OF PACKAGING
Power
Cable
Digital Video Recorder System
User Manual
Remote Controller
( Not included with
4chn Non DVD
units)
Battery
IntelligentSecurity&Fire
10
Quantum Evolution installation and user manual
FEATURES
●Convenience
-User-friendly GUI ( Graphic Based User Interface)
-Easy-to-use menu structure
-Easy-to-use recorded data search (Time, Date, Motion, Alarm)
●Stability
-Auto restart after power interruption
-DB structure offers data stabilization and best storage utilization
●Expandability
- Various remote multi DVR‟s can be controlled by Web browser (PC Client System)
●Technology
- Embedded LINUX OS
- Maximum recording rate 100 fps
- High-resolution & high-quality MPEG-4 algorithm
- Using Water marking & scrambling technologies,
- MPEG-4: 1 ~ 2 Kbytes per image with resolution 360x240
● Functionality
- Variable recording function (normal, alarm, motion, schedule)
- Full channel real-time monitoring
- Live monitoring, recording, playback, backup and remote access similtaneously
- Multi channel playback
- Variable events notification to e-mail, buzzer or PC Client system
IntelligentSecurity&Fire
