Vivo MOUNT-VW100F Bedienungsanleitung

Extra Large TV Wall Mount

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-vw100f

SKU: MOUNT-VW100F

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

PACKAGE CONTENTS

TOOLS NEEDED

165lbs

(74.84kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

WARNING!

Phillips

Screwdriver

A (x1)

Mount

B(x2)

Bracket

C(x1)

Level

M-F (x4)

Metal Spacer

M-G (x8)

Small Spacer

W-A (x6)

Bolt

M-E (x4)

M8x50

M-A (x4)

M5x14

M-B (x4)

M6x14

M-C (x4)

M6x30

M-D (x4)

M8x30

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

NOTE: NOT ALL HARDWARE INCLUDED WILL BE USED

W-C (x6)

Washer

W-B (x6)

Anchor

Drill

CAUTION!

DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO

MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us.

com, email at [email protected], or call us at 309-278-5303.

M-H (x8)

Big Spacer

Pencil

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

ASSEMBLY STEPS

STEP 1

OPTION A: Wood Wall

Use mount (A) with level (C) to mark mounting holes on wall where studs are located. Using a 5/32”

bit, drill 2.2” into wall. Install mount using bolts (W-A) and washers (W-C).

OPTION B: Concrete/Brick Wall

Use mount (A) with level (C) to mark mounting holes on wall. Using a 3/8” bit, drill 2.4” into wall. Insert

anchors (W-B) into holes and use bolts (W-A) and washers (W-C) to install mount.

STEP 2

Mount brackets (B) to back of television using bolts (M-A, M-B, M-C) and metal spacer (M-F). Make

sure straps are towards bottom of TV. If bolts are too long, spacers (M-H, M-G) may be required.

STEP 3

Attach TV to mount (A) as shown in diagram. Make sure bottom of brackets (B) are attached securely.

NOTE: To remove, pull both straps down and li television o of mount (A).

LAST UPDATED: 06/12/2020

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
