Wali M001LP Bedienungsanleitung

M001LP

WARNING

！

USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIP OVER.

SMALL PARTS- NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may

cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect

assembly or inappropriate use.

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:

Single Mount With Laptop Tray

75x75\100x100

INSTALLATION MANUAL

1-844-SATTLER (18447288537)

[email protected]

www.walielectric.com

(10kg/22lbs)x2

RATED

TIPOVER WARNING

● NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR STAND.

● USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL.

Supplied Parts List

Pole

a (x1)

C-Clamp Brace

c (x1)

C-Clamp

b (x1)

VESA Plate

e (x2)

M8x12 Bolt

g (x2)

Nut

h (x2)

M5x14 Bolt

f (x3)

Support Plate

j (x1)

Spring Washer

l (x1)

M10 Washer

k (x1)

M10 Bolt

i (x1)

Grommet Base Plate

m (x1)

Wire Clip

n1 (x2)

Allen Key

o (x1)

Wire Clip

n2 (x3)

M4 Spacer

s (x8)

M4x30 Bolt

r (x8)

Wrench

p (x1)

M4x12 Bolt

q (x8)

Swivel Arms

d (x1)

Laptop Tray

t (x1)

M4 Nut

v (x4)

M4x10 Bolt

u (x4)

Option A : Clamp Installation

1. Connect Pole a and C-Clamp Brace c from the bottom using M5x14 Bolt f and

tighten with Allen Key 3mm o .

2. Select the preferred height according to your desk thickness. Connect C-Clamp b to C-Clamp

Brace c using M8x12 Bolt g and tighten with Allen Key 5mm o . Rotate the hand knob

clockwise to fasten for stability.

Hand Knob

a c f

Option B : Grommet Base Installation

1. Place Pole a onto Grommet Base Plate m . Connect them from the bottom using

M5x14 Bolt and tighten with Allen Key 3mm .

Laptop : 17” Max

Monitor: 27” Max

Washer

w (x4)

Anti-skid Pad

x (x4)

Option A : Laptop Tray Installation Option B : Monitor Mount Installation

Laptop Tray Holder

For safety, please remove your laptop when making adjustments.

6Manually swivel, tilt, and rotate the monitor laptop tray for the best viewing angle.

5Guide the cable through the Wire Clips ( n1, n2 ) and store the Allen Keys o in the Wire Clip n1 .

Adjust the tilt angle using Allen Key 5mm n .

n1 n1

n2 15°

15°

2b. Self-drilled Grommet Hole Installation

ø 10mm

(ø ")3/8

Step 1

Select Monitor Screws

Step 3a

Flat Back Monitor

Step 3b

Curved or Recessed Back Monitor

M4x12 M4x30

Only one screw size fits your Monitor

Step 2

Select Spacers ( if needed )

Hand thread screws into the

threaded inserts on the back

of your Monitor to determine

which screw (M4x12 or M4x30)

to use.

4Put the assembled laptop tray and TV/Monitor onto the Swivel Arms d . Tighten the VESA

Plate e with Nut h for stability.

Mark the position of the hole on your mounting surface. Drill a 3/8"(10mm) diameter hole at the

marked position through the mounting surface. Position the Pole a on the mounting surface and

secure using the Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the

Bolt using the provided Wrench p .

jkl

2Put the Wire Clip n1 and Swivel Arms d through the Pole a , adjust the preferred height

and tighten using Allen Key 6mm o . Attach the Wire Clips n1 to the Swivel Arms d .

2a. Existing Grommet Hole Installation

If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before

installing the desk mount. Position the Pole a on the mounting surface and secure using the

Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the Bolt using

the provided Wrench p .

jkli

Select bolts and spacers (if needed) according to your TV/Monitor. Attach the VESA Plate to the Monitor and tighten with a screwdriver. (Screwdriver not included)

Notice: Please make sure the security nut is installed before you rotate the monitor.

Using M4 X 10 Bolt u , M4 Nut v , and Washer to attach the VESA

Plate e to the laptop tray t and tighten with a screwdriver. Put the Anti-skid

Pad on the designated position on the tray. (Screwdriver not included)
