Wali M002XLS Bedienungsanleitung
M002XLS
WARNING
！
！
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIP OVER.
SMALL PARTS- NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect
assembly or inappropriate use.
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
Dual Monitor Desk Mount
75x75\100x100
INSTALLATION MANUAL
1-844-SATTLER (18447288537)
www.walielectric.com
RATED
(10kg/22lbs)x2
MAX 27”
TIPOVER WARNING
● NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR STAND.
● USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL.
Supplied Parts List
Lower Pole
a1 (x1)
Monitor Arm
d (x2)
VESA Plate
e (x2)
Nut
h (x2)
M5x14 Bolt
f (x3)
M8x12 Bolt
g (x2)
Support Plate
j (x1)
Spring Washer
l (x1)
M10 Washer
k (x1)
M10 Bolt
i (x1)
Grommet Base Plate
t (x1)
Wire Clip
n1 (x2)
Allen Key
o (x1)
M4 Spacer
s (x8)
M4x30 Bolt
r (x8)
Wrench
p (x1)
M4x12 Bolt
q (x8)
Upper Pole
a2 (x1)
Pole Cover
n2 (x1)
C-Clamp Brace
c (x1)
C-Clamp
b (x1)
1
a2
a2
a1
a1
a1
o
t
n2
o
Option B : 16.3'' Pole Installation (Only Used For Single Monitor Mount)
Option A : 31.5'' Pole Installation
Loosen the screw on the Lower Pole a1 with Allen key 2mm o . Connect
Lower Pole a1 to Upper Pole a2 and tighten the screw with Allen key
2mm o to fix the two poles.
a1
a1
Press Pole Cover into the top of Lower Pole a1.
a1
a1
Pre-Assembly
Pre-Assembly
o
a2
o
t
n2
Option A : Clamp Installation
1. Connect Lower Pole a and C-Clamp Brace c from the bottom using M5x14
Bolt f and tighten with Allen Key 3mm o .
2
2. Select the preferred height according to your desk thickness. Connect C-Clamp b to C-Clamp
Brace c using M8x12 Bolt g and tighten with Allen Key 5mm o . Rotate the hand knob
clockwise to fasten for stability.
Hand Knob
a1
c
c
c
f
o
o
o
g
g
b
b
a1 c
fo
o
3Put the Wire Clips n1 and Monitor Arms d through the Upper Pole a , adjust the preferred
height and tighten using Allen Key 6mm o .
7Manually swivel, tilt, and rotate the monitor for the best viewing angle.
6Guide the cable through the Wire Clips and store the Allen Keys o in the Wire Clips n1 .
Adjust the tilt angle using Allen Key 5mm n .
n1 n1
o
o
d
d
n1
45°
45°
45°
45°
a2
o
j
j
k
l
i
p
a1 j
a1
j
k
lp
i
2a. Existing Grommet Hole Installation
If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before
installing the desk mount. Position the Lower Pole a on the mounting surface and secure using the
Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the Bolt using
the provided Wrench p .
2b. Self-drilled Grommet Hole Installation
Mark the position of the hole on your mounting surface. Drill a 3/8"(10mm) diameter hole at the
marked position through the mounting surface. Position the Lower Pole a on the mounting surface and
secure using the Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the
Bolt using the provided Wrench p .
p
jkli
a1 a1
jkl
p
i
ø 10mm
(ø ")3/8
Select bolts and spacers (if needed) according to your TV/Monitor. Attach the VESA Plate to the Monitor and tighten with a screwdriver. (Screwdriver not included)
Step 4.1
Select Monitor Screws
Step 4.3a
Flat Back Monitor
Step 4.3b
Curved or Recessed Back Monitor
e
e
r
s
q
M4x12 M4x30
4
Only one screw size fits your Monitor
Step 4.2
Select Spacers ( if needed )
Hand thread screws into the
threaded inserts on the back
of your Monitor to determine
which screw (M4x12 or M4x30)
to use.
5Put the assembled TV/Monitor onto the Monitor Arms d and tighten the VESA Plate e with
Nut h for stability.
h
o
Option B : Grommet Base Installation
1. Place Lower Pole a onto Grommet Base Plate m . Connect them from the bottom using M5x14 Bolt
and tighten with Allen Key 3mm .
o
a1 t
o
a1
t
f
o
n1
e
d
h
a2
n1
e
h
d
Notice: Please make sure the security nut is installed before you rotate the monitor.
h
h
