QUICK START GUIDE

Before you begin

If you do not have a OneLab account,

please create one by going to:

onelab.com/signup

Getting started

Plug your Pipette+ stand

to a power source.

Wait the LED sign to turn blue

and blink

After a couple of minutes, the Pipette+

stand will inform you when it is in

installation mode.

Connect your computer, tablet or smartphone to the Pipette+ stand

Launch a web browser, type http://192.168.2.1

and follow the on-screen steps to continue installation.

A. Go to your Wi-Fi settings

and select the network named Stand-618.xxxx.xxxxx

1 2

scan me

Please take note that

the installation page

might open automatically.

If you do not have access to

a Wi-Fi compatible device,

please refer to our online help:

help.andrewalliance.com

xxxx.xxxxx is the Pipette+ stand serial number (you can nd it in the back of

your stand)

B. The LED sign will stop blinking when it’s successfully connected.

Stand-618.xxxx.xxxxx

If the Stand+ doesn’t enter auto-

matically in installation mode,

press 5 times the push button.

http://192.168.2.1

Operations

Design your protocol

Execute experiment with

Pipette+

Follow instructions and trigger action

by clicking on the pipette operating button

Select the Pipette+ as experiment setup

then prepare all the required materials.

Our drag-n-drop editor makes it easy to

design a precise and complete protocol

with all that you need to run your

experiment perfectly.

Follow the visual instructions

based on the protocol being

used and you will be guided

throughout your experiment.

Each step of the experiment will

be traced and available in OneLab.

Feel free to contact

the Waters Automation

support team Send us an email to

[email protected]

Chat with our support team

directly in OneLab

We reply within 1 business day

Product overview Technical data

Serial number

Push button

Built-in

computer

4 Andrew Alliance

pipettes holders

Built-in wireless

adapter

LED sign

Power socket

Ethernet socket

for cable

connection

USB charging

socket

(no data)

Waters Corporation

34 Maple St

Milford, MA 01757

Phone: 1-800-252-4752

Sartorius Biohit Liquid Handling Oy

Laippatie 1

00880 Helsinki, Finland

Phone: +358 9 755 951

lhinfo.[email protected]

Power supply Wall / desktop power supply

with universal wall plugs

Input: 100 - 240 VAC v~50/60Hz

Output: 12 VDC, 4 A

Power supply

connector

DC plug 5.5/2.1 mm with 90

degree angle

Pipette charge

voltage

7,5 VDC, 500 mA

Weight 1.7 kg

Dimensions 395 x 314 x 170 mm (W × H × D)

Operating

temperature

+15 to +40 °C

Air humidity max 80%

LAN 10/100 Mbits/s

WiFi 802.11 ac/a/b/g/n

Bluetooth BTLE version 4.2

USB charging USB-A connector

5 VDC, 1 A

User interface 9 RGB LEDs in a form of plus

symbol

Audio 2 speakers for mono audio,

nominal power 1W

Embedded PC Freescale i.MX 7 with ARM

Cortex-A7 1 GHz CPU

SO-DIMM 204 pin connector

1GB DRAM

4GB eMMC

Operating system Linux Debian

Warranty 1 year

Ingress Protection IP40

Certication CE, FCC, RoHS II, REACH, WEEE

Cleaning Disinfectant or decontaminant

liquid such as 70% ethanol,

60% isopropanol, mild detergent

or similar

Supported pipette

models

All Andrew Alliance Pipettes

Identication Unique serial number on the

back of the stand

720007800EN | Part number: 618.003.2 | 2022 © Waters Corporation.
