Model IS15/S

Integrated Electric Steamer Module

From a temperature of 140˚F to boil,

you can keep food hot for long periods

of time in the Wolf steamer module or

defrost food easily without drying out

or losing its flavor. With a two-gallon

capacity this unit can hold up to 14 cups

of cooked pasta and includes one solid

and one perforated stackable insert pan.

Model IS15/S is available in classic

stainless steel.

Features

Integrated design allows for installation of

multiple cooktops or modules

Stainless steel top construction with

classic stainless steel finish

Hidden 2600-watt heating element

Illuminated electronic touch controls with

graduated control lighting

Large two-gallon maximum capacity tub—

10-cup capacity for steaming

Two stackable stainless steel steamer

insert pans—one solid and one perforated

Uses include steaming vegetables, eggs

and custard, double boiling, proofing

bread dough, warming food and melting

chocolate

Can function as a slow cooker for 8–10

hours

Reversible domed glass lid for easy

storage

Independent digital timer

Digital temperature readout and preheat

indicator

Electronic drain

Accessories

Filler strip for installation of multiple

cooktops or modules

Accessories are available through your

Wolf dealer. To obtain local dealer information,

visit the Showroom Locator section of our

website, wolfappliance.com.

Model IS15/S

Classic

Model IS15/S

Stainless Steel Finish Classic

This appliance is certified by Star-K to

meet strict religious regulations in

conjunction with specific instructions

found on www.star-k.org.

Model IS15/S shown installed

with Model CT15E/S electric cooktop.

Electronic Touch Controls

Installation Notes

IMPORTANT NOTE: This steamer module

must be installed at least 15" away from a

Wolf fryer module, as contact between water

and hot oil may cause burns from steam and

hot oil.

Complete installation specifications can be

found on our website, wolfappliance.com.

Unit dimensions may vary by ±

Specifications

Exterior Finish Classic

Overall Width 15"

Overall Height 131/2"

Overall Depth 21"

Heating Element 2600 W

Recommended Cabinet Width

one module 18"

two modules 33"

Minimum Cabinet Depth 223/4"

Minimum Height Clearance 131/2"

Countertop Cut-Out Width 14"

Countertop Cut-Out Depth 191/4"

Electrical Requirements 240/208 V AC

60 Hz, 15 amp circuit

Conduit 4' flexible 3-wire

Electrical Rating 2.6 kW at 240 V

1.9 kW at 208 V

Shipping Weight 40 lbs

Installation Specifications

Overall Dimensions

Model IS15/S

Integrated Electric Steamer Module

Dimensions in parentheses are in

millimeters unless otherwise specified.

15" (381)

OVERALL WIDTH

21"

(533)

OVERALL

DEPTH

131/2" (343)

TO DRAIN

OUTLET

71/2"

(191)

7"*min (178)

CUT-OUT TO

COMBUSTIBLE

MATERIALS

(BOTH SIDES)

14" (356)

COOKTOP CUT-OUT

WIDTH

14" (356)

COOKTOP CUT-OUT

WIDTH

33" (838)

RECOMMENDED

CABINET WIDTH

18"

(457)

NOTE: Application shown allows for installation of two 15" (381) modules side-by-side with 33" (838) recommended cabinet width. 18" (457)

recommended cabinet width for installation of single 15" (381) cooktop or module. *Minimum clearance from both side edges of cooktop cut-ou

to combustible materials up to 18" (457) above countertop. **Minimum clearance from rear edge of cooktop cut-out to combustible materials up

to 18" (457) above countertop.

191/4" (489)

COOKTOP CUT-OUT

DEPTH

21/2"min

(64)

36" (914)

STANDARD

FLOOR TO

COUNTERTOP

HEIGHT

13" max

(330) 30" (762)

COUNTERTOP TO

COMBUSTIBLE

MATERIALS

ABOVE COOKTOP

FRONT OF COUNTERTOP

21/2"min

(64)

191/4" (489)

COOKTOP

CUT-OUT DEPTH

75/8"

(194)

123/8"

(314)

DRAIN OUTLET

LOCATION

131/2"

(343)

15"

(381)

15"

(381)

123/8"

(314)

(152)

DRAIN

OUTLET

LOCATION

2"**

(51)

Countertop Cut-Out Dimensions
