Yakima ROCKETBox PRO 11 Bedienungsanleitung

RocketBox

ROCKETBOx PRO 11, ROCKETBOx PRO 12, ROCKETBOx PRO 14

IMPORTANT WARNING

IT IS CRITICAL THAT ALL YAKIMA RACKS AND ACCESSORIES BE PROPERLY AND SECURELY ATTACHED TO YOUR VEHICLE. IMPROPER

ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR

TO OTHERS. YOU ARE RESPONSIBLE FOR SECURING THE RACKS AND ACCESSORIES TO YOUR CAR, CHECKING THE ATTACHMENTS

PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR, AND DAMAGE. THEREFORE, YOU

MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR YAKIMA PRODUCT PRIOR TO INSTALLATION

OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL ExPERIENCE AND ARE NOT

THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER.

KEY (2x)

ROCKETBOx PRO (1x)

4,5Nm (40 in-lb)

2,2Nm (20 in-lb)

XX m / XX’

R8A9N1D

Max

75 Kg

XX kg

(XX lbs.)

MAX.

XX kg

(XX lbs.)

MAX.

ROCKETBOx PRO 11......17.2 Kg / 38 LBS.

ROCKETBOx PRO 12......13.6 Kg / 30 LBS.

ROCKETBOx PRO 14......17.2 Kg / 38 LBS.

1/2 1/4

1/4

R8A9N1D

ºC ºF

TO REMOVE cARGO bOX:

TO REPLAcE LOcK cORE:

2x 4x

6x 10x

#8007202 #8007204

#8007206 #8007210

KEEP THESE INSTRUcTIONS

cARE AND MAINTENANcE

YAKIMA cargo boxes should be cared for and maintained, especially in extreme weather conditions.

• To clean, use only mild detergents. Harsh detergents could damage the gear box surface.

• Protect your gear box from extreme temperatures, (heat or cold) during prolonged storage.

• Remove gear box before entering automatic car wash.

• Hardware such as locks should be lubricated with graphite or other dry lubricant.

Be sure to read all the warnings and

warranty information contained in the

insert accompanying these instructions!

IMPORTANT!

BE SURE ALL HARDWARE IS SECURED

ACCORDING TO INSTRUCTIONS.

FAILURE TO PERFORM SAFETY CHECKS

BEFORE DRIVING AWAY CAN RESULT

IN PROPERTY DAMAGE, PERSONAL

INJURY, OR DEATH.

ATTACHMENT

HARDWARE CAN

LOOSEN OVER TIME.

CHECK AND TIGHTEN

IF NECESSARY,

BEFORE EACH USE.

PERIODICALLY CHECK

THE LEVERS INSIDE THE

BOx AND TIGHTEN IF

NECESSARY.

READ THESE WARNINGS!

AVAILAbLE AccESSORIES

SKS Lock Cores 2 Pack SKS Lock Cores 4 Pack

SKS Lock Cores 6 Pack SKS Lock Cores 10 Pack
