Zepco MDVR?CF Datenblatt

Zepco“Mini”

DVR

MobileDigitalVideoRecorder–

CompactFlash

(MDVR‐CF)

InstallationQuick‐StartGuide

PartsList

1–MasterHarness

1–MDVR‐CF(1or2cameras)

1or2Day/Night8.0mmColor

Camw/Audio*

2or4FBNC/MRCAAdapter*

1or25MVideo/AudioCable*

1or212VPowerExtension*

1–CDw/ClientSoftware,

DigitalUsersManual

&Digital

InstallationQuickStartGuide

*QuantityDependsonOrder

ProvidingPowerforYour

Camera(s)

NOTE:TURNOFFDVRBEFOREPLUGGINGINCAMERAS!

InternaltotheMDVR‐CFisaregulatedpowersupply

thatprovides12Vtopowerupyourcameras.

WithZepco’s

custompowerextensioncable

providingexternalpowertoyourcamerasismade

easy.BesureyourMDVR‐CFisinstalledinagood,

tightlocation.

NOTE:Ifyoufindthatyouarenotgettingpictures

whenyouarelookingatvideoonyourCFcard,this

wouldbethefirstplacetolook.Ensureyourcamera

aregettingpower.

Yourvideo/audiocableattachestothe‘Vin’

(video

in)and‘Ain’

(audioin)attherearoftheMDVR‐CF.

YourcablinghasBNCconnectorsforyourvideoand

audiochannels.Youthenhavemaleandfemale

powerjacksoneachendofyourcable.Besureyou

installthecablecorrectly–thefemalepowerjack

goestothecameraside.There’snothingworsethan

uninstallingsomethingyoujustinstalledbecauseitis

backwards–trustus,youwillonlydoitonce!☺

Camera&AudioCables

ConnectingtotheMDVR

Inordertomakethecableconnectionto

yourMDVR‐CF,youneedtoinsertan

adapter.IncludedinyourMDVRsystem

are(2)FBNC/MRCAadaptersor(4)ifyou

orderedatwo‐channelMDVR‐CF.

EnsuretheBNCconnectionsarelockedto

theadapter

WhenZepcoinstallsMDVRsystems,we

wrapallconnectorswithelectricaltapeto

ensureafirmconnectionattheDVRand

at

thecamera.Theseareruggedautomotive

connectors,howeverextremelyrough

roadscouldshakethemloose.Alittletape

cansavetroubleshootingtimelater!

SecuringCamerasand

Cabling

Onceyou’vedeterminedthelocationforyour

camerasyouneedtodrillaholeforyourcabling.

Zepcosuggestsa1”

3/8in.hole.ALWAYSusea

propersizedgrommettoensurethattherewillbe

nocutsorscrapesfromsharpedgesonthevideo

cable.

Makingtherightconnectionsiscriticaltoaworking

system.Ageneralruleofthumbisthatyourvideo

connectionisYELLOW,audioisWHITEandthe

powerisRED.Asyoucanseeinthisillustrationthe

audiofromthiscameraisREDhoweverwestill

connectittotheWHITEconnectorofthevideo

cable.Thepowerconnector,regardlessofcolor,is

obviouslydifferentthantheaudio/videoconnectors

andwillonlyplugintooneavailableconnector(black

toredinthispicture).

Onceagain,sincewe’reinstallingavideosystemina

mobileenvironmentweliketotaketheextrastepto

ensuresoundconnectionsforallourconnectionsin

thevideosystem.

CameraViews–MakingAdjustments

Thebestwaytoensureyourcamera(s)are

recordingtheviewyouwantistoalignthem

attheinstallation.Thefocusofthecameras

willbecorrectfromthefactory.We

recommendusingasmallinexpensiveLCD

monitorforcameraalignment.Thiswould

alsobethelaststepintheinstallationprocess.

NOTE!Beforereinstallingceilingpanelsand

“buttoningupthevehicle,”

powerupthe

MDVR‐CFsystem,lineupyourcamerasand

ensuretheentiresystemisoperating

correctly!

VideoOut

AudioOut

StrainReliefs

Wehighlyrecommendprovidingstrainrelieftoallcablesinany

mobileenvironment.

Takeup&secureallslackandensureallcameraconnectionsremainintactwhilemoving

yourcablesoutoftheway.Tiewrapyourslacktoanexistingwiringbundleorother

securedareasbehindyourceilingpanels.

4‐6in.cableslack tiewraps

13/8in.holegrommet

InstallingGPS

IftheGPSoptionwasordered,yoursystemwillincludeaGPSreceiverthatisinstalledinternally.

ConnecttheGPSantennaattherearofyourMDVR‐CFsystemthenruntheantennacabletothetop

ofyourvehicle.Themagneticantennamustbeplacedontopofthevehicleforafullviewofthesky.

Thesamerulesapplyforsecuringslackcablinginamobileenvironment:properstrainreliefs,tie‐

wrapsforasecureinstallation,apropersizedholeforaccesstotheroofofthevehiclewith

protectiverubbergrommet.BesureandprovideawatertightsealwheretheGPScableentersthe

vehicle.

Internalcenterpin

Pushonconnector
