Advantech B+B SmartWorx SmartStart Leitfaden

Start Guide

SmartStart, SmartFlex, SmartMotion

Start Guide

Safety instructions

Please take care to following instructions:

•Use the router in compliance with national and international law and in compliance with

any special or additional restrictions regulating use of the router in the various applica-

tions and environments.

•To avoid possible injury and/or damage to the device, observe the relevant provisions

and standards. Use only the original accessories as recommended. Unauthorized de-

vice or accessory modiﬁcation, or using accessories that have not been approved can

result in router damage and/or violation of the regulations.

•Unauthorized device or accessory modiﬁcation or using the accessories that have not

been approved can result in warranty termination.

•Do not open the router.

•Caution! The SIM card can be swallowed by small children.

•When connecting the device to a power supply do not exceed the deﬁned voltage.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture, and high temperature.

•It is recommended that you do not use the router at petrol ﬁlling stations. We recommend

observing local restrictions concerning the use of radio-based devices while working with

explosive material for example, at petrol ﬁlling stations, or in chemical plants.

•While using the router close to personal medical devices, such as cardiac pacemakers

or hearing aids, proceed with heightened caution.

•Operating the router too close to TV sets, radio receivers, personal computers, or tele-

phones can cause interference.

•It is recommended that you create a copy or backup of the important settings stored in

the memory of the router.

1QSG issued in CZ, January 25, 2017

Start Guide

Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) direc-

tive has been introduced to ensure that electrical/electronic products are recy-

cled using the best available recovery techniques to minimize the impact on

the environment. This product contains high quality materials and components

which can be recycled. At the end of its life this product MUST NOT be mixed

with other commercial waste for disposal. Check with the terms and conditions

of your supplier for disposal information.

Open Source Software License

The software in this device uses various pieces of open source software governed by

following licenses:

•GPL versions 2 and 3

•LGPL version 2

•BSD-style licences

•MIT-style licences

The list of components together with complete license texts can be found on the device

itself. See Licenses link at the bottom of the router’s main Web page (General Status) or point

your browser to this address (replace the DEVICE_IP string with real router’s IP address):

https://DEVICE_IP/licenses.cgi

This is a written offer valid for 3 years since the device purchase offering any third party for

a charge no more than cost of physically performing source distribution, a complete machine-

readable copy of the corresponding source code on a ﬂash drive medium. If you are interested

in obtaining the source, please contact us at:

cellularsales@advantech-bb.com

Modiﬁcations and debugging of LGPL-linked executables:

The manufacturer of the device hereby grants the right to use debugging techniques (e.g.

decompilation) and making customer modiﬁcations of any executable linked with a LGPL li-

brary for own purposes. Note these rights are limited to the customer’s own usage. No further

distribution of such modiﬁed executables and no transmission of the information obtained dur-

ing these actions may be done.

2QSG issued in CZ, January 25, 2017

Start Guide

3QSG issued in CZ, January 25, 2017

SmartStart

SmartStart Router

SL302, SL304

4QSG issued in CZ, January 25, 2017

SmartStart

First Use

Before applying power to the router, connect the components that you required for your

applications. You cannot operate the router without connected antenna, inserted SIM card,

nor connected power supply.

If you do not have connected main antenna during operation of the router, the router can

be damaged!

1. Antenna

Use a SMA connector to connect the antennas to the router. The main antenna is con-

nected to the router by screwing on the ANT connector (see the ﬁgure below). A second

diversity antenna can also be connected to the DIV connector to improve performance.

2. SIM card

The SIM card readers, for 3 V and 1.8 V SIM cards, are located on the rear panel of the

router. If you intend to use this device to communicate over a cellular network, please place

an activated data-provisioned SIM card with an unblocked PIN into the SIM card reader. Push

your SIM card into the SIM1 (or SIM2 in case of the SmartStart router SL302 or SL304) slot

until it clicks in place.

5QSG issued in CZ, January 25, 2017

SmartStart

Before handling of the SIM card disconnect the router from power supply!

3. Power

The router requires an external DC power supply. The DC voltage required is between

+9 to +36 V DC. The router has built-in protection against reverse polarity without signaling.

Connect the power supply cable to the PWR connector on the front panel of the router (see

ﬁgure below).

6QSG issued in CZ, January 25, 2017

SmartStart

4. Ethernet

An Ethernet cable may be connected to the ETH connector (designated as ETH0 in some

versions of this router) on the front panel (see ﬁgure above). By default, the Ethernet port is

conﬁgured as follows:

Connector Purpose Default Setting

ETH LAN port (default)

Connect your laptop or PC to this port to

get a local web-server for device conﬁgu-

ration and diagnostics.

DHCP Server

IP Address: 192.168.1.1

NetMask: 255.255.255.0

Conﬁguration

1. Conﬁguring the Device Using the Web Browser

You can access the router for status monitoring, conﬁguration, and administration after

entering the IP address of the router into the web interface. The default router IP address is

192.168.1.1 (netmask 255.255.255.0). Conﬁguration access is allowed for the user "root" with

the initial password "root". Attention, it is necessary to use HTTPS protocol for secure

communication over a network! For a detailed description and examples of the router con-

ﬁgurations, see the Conﬁguration manual.

2. Conﬁguration Settings via SmartWorx Hub

If your router has been pre-installed with the SmartWorx Hub client, you may conﬁgure it

from SmartWorx Hub. Navigate your browser to:

https://hub.bb-smartworx.com

If this is your ﬁrst time, please register with the site. If not, please login with your username

and password. Once logged in, further assistance can be found here:

https://hub.bb-smartworx.com/Login/Help?HelpFile=bbdms_help.pdf

3. Restoring and Backing up the Router Conﬁguration

After you reset the router, the current conﬁguration is overwritten by the default settings.

We recommend that you back up the router conﬁguration before resetting the device. Refer to

the Conﬁguration manual for more information.

7QSG issued in CZ, January 25, 2017

SmartStart

When the PWR LED starts blinking, it is possible to restore the default conﬁguration of the

router by pressing the RST button on the rear panel. After pressing this button, the default

conﬁguration is restored and then the router reboots (green LED will be on).

After logging on to the device for the ﬁrst time, we strongly recommend to change

the default password due to security reasons. Simultaneously, you will gain ac-

cess to all functions of the router.

Documentation

User’s Manual and Conﬁguration Manual for the router can be found on the company web

site www.bb-smartcellular.eu/download. Please, use the following login information:

Username: smartrouters

Password: smartrouters

We declare that the SmartStart router SL304 is in compliance with the essential re-

quirements and other relevant provisions of direction 1995/5/EC.

The Declaration of Conformity is available on the company website or from technical support,

on request.

8QSG issued in CZ, January 25, 2017

SmartStart

9QSG issued in CZ, January 25, 2017
