Agilent Technologies

Agilent L4411A

6 ½ Digit Multimeter

Getting Started Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2L4411A Getting Started Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation

into a foreign language) without prior agree-

ment and written consent from Agilent

Technologies, Inc. as governed by United

States and international copyright laws.

Manual Part Number

L4411-90001

Edition

First Edition. February 2007

Printed in Malaysia

Agilent Technologies, Inc.

3501 Stevens Creek Blvd.

Santa Clara, CA 95052 USA

Microsoft® and Windows® are U.S. regis-

tered trademarks of Microsoft Corporation.

Software Revision

This guide is valid for the firmware that was

installed in the instrument at the time of

manufacture. However, upgrading the firm-

ware may add or change product features.

For the latest firmware and documentation,

go to the product page at:

www.agilent.com/find/L4411A

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connec-

tion with the furnishing, use, or per-

formance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a license

and may be used or copied only in accor-

dance with the terms of such license.

Restricted Rights Legend

U.S. Government Restricted Rights. Soft-

ware and technical data rights granted to

the federal government include only those

rights customarily provided to end user cus-

tomers. Agilent provides this customary

commercial license in Software and techni-

cal data pursuant to FAR 12.211 (Technical

Data) and 12.212 (Computer Software) and,

for the Department of Defense, DFARS

252.227-7015 (Technical Data - Commercial

Items) and DFARS 227.7202-3 (Rights in

Commercial Computer Software or Com-

puter Software Documentation).

Safety Notices

CAUTION

A CAUTION notice denotes a haz-

ard. It calls attention to an operat-

ing procedure, practice, or the like

that, if not correctly performed or

adhered to, could result in damage

to the product or loss of important

data. Do not proceed beyond a

CAUTION notice until the indicated

conditions are fully understood and

met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and

met.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L4411A Getting Started Guide 3

Safety Information

Do not defeat power cord safety ground fea-

ture. Plug in to a grounded (earthed) outlet.

Do not use product in any manner not speci-

fied by the manufacturer.

Do not install substitute parts or perform

any unauthorized modification to the prod-

uct. Return the product to an Agilent Tech-

nologies Sales and Service Office for service

and repair to ensure that safety features are

maintained.

Safety Symbols

WARNING

Main Power and Test Input Dis-

connect: Unplug instrument from

wall outlet, remove power cord,

and remove all probes from all

terminals before servicing. Only

qualified, service-trained person-

nel should remove the cover from

the instrument.

WARNING

Current Protection Fuse: For con-

tinued protection against fire,

replace the current-protection

fuse only with a fuse of the speci-

fied type and rating.

WARNING

IEC Measurement Category II. The

HI and LO input terminals may be

connected to mains in IEC Cate-

gory II installations for line volt-

ages up to 300 VAC. To avoid the

danger of electric shock, do not

connect the inputs to mains for

line voltages above 300 VAC. See

"IEC Measurement Category II

Overvoltage Protection" on the

following page for further infor-

mation.

WARNING

Protection Limits: To avoid instru-

ment damage and the risk of elec-

tric shock, do not exceed any of

the Protection Limits defined in

the following section.

Earth Ground

Chassis Ground

Risk of electric shock

Refer to manual for addi-

tional safety information

CAT II (300V) IEC Measurement Category II.

Inputs may be connected to

mains (up to 300 VAC) under

Category II overvoltage condi-

tions.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4L4411A Getting Started Guide

Protection Limits

The Agilent L4411A Digital Multimeter pro-

vides protection circuitry to prevent damage

to the instrument and to protect against the

danger of electric shock, provided the Pro-

tection Limits are not exceeded. To ensure

safe operation of the instrument, do not

exceed the Protection Limits shown on the

front or rear panel, and defined below:

Input Terminal Protection

Limits

Protection Limits are defined for the input

terminals:

Main Input (HI and LO) Terminals. The HI

and LO input terminals are used for voltage,

resistance, capacitance, and diode test

measurements. Two Protection Limits are

defined for these terminals:

HI to LO Protection Limit. The Protection

Limit from HI to LO ("A" in the figure at

left) is 1000 VDC or 750 VAC, which is

also the maximum voltage measurement.

This limit can also be expressed as 1000

Vpk maximum.

LO to Ground Protection Limit. The LO

input terminal can safely "float" a maxi-

mum of 500 Vpk relative to ground. This is

Protection Limit "B" in the figure.

As is implied by the above limits, the Protec-

tion Limit for the HI input terminal is a maxi-

mum of 1500 Vpk relative to ground.

Current Input Terminal. The current input

("I") terminal has a Protection Limit of 3A

(rms) maximum current flowing from the LO

input terminal. This is Protection Limit "C"

in the figure. Note that the current input ter-

minal will be at approximately the same

voltage as the LO terminal.

Note: The current-protection circuitry

includes a fuse on the rear panel. To main-

tain protection, replace this fuse only with a

fuse of the specified type and rating.

Sense Terminal Protection

Limits

The HI and LO sense terminals are used

only for four-wire resistance and tempera-

ture measurements ("Ω 4W"). The Protec-

tion Limit is 200 Vpk for all of the terminal

pairings ("D" in the figure):

LO sense to LO input.

HI sense to LO input.

HI sense to LO sense.

Note: The 200 Vpk limit on the sense termi-

nals is the Protection Limit. Operational

voltages in resistance measurements are

much lower — less than 10 V in normal

operation.

IEC Measurement Category II

Overvoltage Protection

To protect against the danger of electric

shock, the Agilent L4411A Digital Multime-

ters provide overvoltage protection for

line-voltage mains connections meeting

both of the following conditions:

The HI and LO input terminals are con-

nected to the mains under Measurement

Category II conditions, defined below,

and

The mains are limited to a maximum line

voltage of 300 VAC.

IEC Measurement Category II includes elec-

trical devices connected to mains at an out-

let on a branch circuit. Such devices include

most small appliances, test equipment, and

other devices that plug into a branch outlet

or socket. The L4411A may be used to make

measurements with the HI and LO inputs

connected to mains in such devices, or to

the branch outlet itself (up to 300 VAC).

However, the L4411A may not be used with

its HI and LO inputs connected to mains in

permanently installed electrical devices

such as the main circuit-breaker panel,

sub-panel disconnect boxes, or permanently

wired motors. Such devices and circuits are

subject to overvoltages that may exceed the

protection limits of the L4411A.

Note: Voltages above 300 VAC may be mea-

sured only in circuits that are isolated from

mains. However, transient overvoltages are

also present on circuits that are isolated

from mains. The Agilent L4411A is designed

to safely withstand occasional transient

overvoltages up to 2500 Vpk. Do not use this

equipment to measure circuits where tran-

sient overvoltages could exceed this level.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L4411A Getting Started Guide 5

Additional Notices

Waste Electrical and

Electronic Equipment (WEEE)

Directive 2002/96/EC

This product complies with the WEEE Direc-

tive (2002/96/EC) marking requirement.

The affixed product label (see below) indi-

cates that you must not discard this electri-

cal/electronic product in domestic

household waste.

Product Category: With reference to the

equipment types in the WEEE directive

Annex 1, this product is classified as a

"Monitoring and Control instrumentation"

product.

Do not dispose in domestic household

waste.

To return unwanted products, contact your

local Agilent office, or see

www.agilent.com/environment/product

for more information.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6L4411A Getting Started Guide

DECLARATION OF CONFORMITY

According to EN ISO/IEC 17050-1:2004

Manufacturer’s Name: Agilent Technologies, Incorporated

Manufacturer’s Address:

900 South Taft Ave

Loveland, CO 80537

USA

Declares under sole responsibility that the product as originally delivered

Product Name: 6 ½ Digit Multimeter

Model Number: 34410A, 34411A, L4411A

Product Options: This declaration covers all options of the above product(s)

complies with the essential requirements of the following applicable European Directives, and

carries the CE marking accordingly:

Low Voltage Directive (73/23/EEC, amended by 93/68/EEC)

EMC Directive (89/336/EEC, amended by 93/68/EEC)

and conforms with the following product standards:

EMC

Standard Limit

IEC 61326:2002 / EN 61326:1997+A1:1998 +A2:2000+A3:2003

Reference Standards

CISPR 11:1990 / EN 55011:1990 Class A Group 1

IEC 61000-4-2:1995 / EN 61000-4-2:1995 4 kV/4 kV contact/air

IEC 61000-4-3:1995 / EN 61000-4-3/1995 3 V/m, 80-1000 MHz

IEC 61000-4-4:1995 / EN 61000-4-4:1995 0.5 kV signal lines, 1 kV power lines

IEC 61000-4-5:1995 / EN 61000-4-5:1995 0.5 kV line-line, 1 kV line-ground

IEC 61000-4-6:1996 / EN 61000-4-6:1996 3 V, 0.15-80 MHz

IEC 61000-4-11:1994 / EN 61000-4-11:1994 1 cycle, >95%

Canada: ICES-001:2004

Australia/New Zealand: AS/NZS CISPR 11:2002

The product was tested in a typical configuration with Agilent Technologies test systems.

Safety

IEC 61010-1:2001 / EN 61010-1:2001

Canada: CAN/CSA-C22.2 No. 61010-1-04, 168520

USA: ANSI/UL 61010-1:2005

Supplementary Information:

This DoC applies to above-listed products placed on the EU market after:

17 January 2007

Date

David L. Kepler

Quality Manager

For further information, please contact your local Agilent Technologies sales office, agent or distributor,

or Agilent Technologies Deutschland GmbH, Herrenberger Straße 130, D 71034 Böblingen, Germany.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L4411A Getting Started Guide 7

Contents

1 Preparation for Use 11

About the Instrument 12

Materials Included 12

No Manuals? 12

The L4411A and the 34411A 13

Operating and Storage Environments 13

Electrical Requirements 13

Network Configuration 13

Selecting a LAN Network 14

Private LAN Considerations 14

Site LAN Considerations 15

Connecting the LAN Cable 15

Private Network Connections 15

Site Network Connections 16

Using the GPIB and USB Interface 17

Applying Power 17

Using the Web-Enabled Instrument Interface 19

Browser Configuration 19

Instrument Identification and SCPI Programming 20

Editing the L4411A LAN Settings 23

Basic Measurement Connections 25

Input Terminal Protection Limits 26

DC Voltage and Current Measurements 27

AC Voltage and Current Measurements 28

Resistance Measurements 29

Frequency and Period Measurements 30

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8L4411A Getting Started Guide

Contents

Capacitance Measurements 30

2 L4411A Software Installation and

Configuration 31

Software Requirements 32

Installing the Agilent IO Libraries 33

Installing Instrument Drivers 35

Interface Configuration 37

Configuring the LAN Interface 37

Locating the Instruments 38

Adding and Configuring the Instruments 40

Using Interactive IO 43

Opening the Web-Enabled Interface 45

GPIB and USB Configuration 45

GPIB Configuration 46

Starting Agilent Connection Expert 46

Adding Instruments to the GPIB Configuration 46

The GPIB Address String 49

The Web-Enabled Instrument Interface and Interactive IO 49

Changing the GPIB Address 49

USB Configuration 50

Adding Instruments to the USB Configuration 51

The USB Address String 52

The Web-Enabled Instrument Interface and Interactive IO 53

Firmware and Driver Updates 54

Downloading the Update Utility and Firmware 54

Downloading and Installing the Firmware Update 54

Downloading IVI-COM Driver Updates 57

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents

L4411A Getting Started Guide 9

3 Introduction to Programming 59

Installing the Example Programs and Agilent IntuiLink 60

Example Programs 60

Modifying the Examples for Use 62

Visual Studio 6.0 (Visual Basic) 62

Visual Studio .NET (C++) 63

Visual Studio .Net (C#) 63

Visual Studio .NET (Visual Basic 7.0) 64

Agilent IntuiLink 65

Using the Tool Bar Add-ins with Microsoft“ Excel and Word 66

Additional Information 67

4 Rack Mounting 69

Rack Mounting the L4411A 70

Rack Mount Kit Contents 70

Procedure 71

Install the Shelf Rails 72

Install the Sliding Shelf 74

Install Instruments on the Shelf 74

Connect the Shelf to the Rack Frame 75

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Inhaltsverzeichnis

Andere Agilent Technologies Multimeter Handbücher

Agilent Technologies

Agilent Technologies 3458A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 34410A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1251A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1252B Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1231A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1401A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 34405A Handbuch

Agilent Technologies

Agilent Technologies 34450A Montage- und Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1251B Bedienungsanleitung

Agilent Technologies

Agilent Technologies Agilent E1412A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1251B Handbuch

Agilent Technologies

Agilent Technologies 34450A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1253A Handbuch

Agilent Technologies

Agilent Technologies 34401A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 34450A Bedienungsanleitung

Agilent Technologies

Agilent Technologies E1420B Technisches Handbuch

Agilent Technologies

Agilent Technologies U1253B Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1273A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 34401A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1241B Bedienungsanleitung

Agilent Technologies

Agilent Technologies Agilent 8163A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 3458A Gebrauchs- und Pflegehandbuch

Agilent Technologies

Agilent Technologies U1273A Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1270 Series Bedienungsanleitung

Beliebte Multimeter Handbücher anderer Marken

Fluke

Fluke 83 Bedienungsanleitung

Hameg

Hameg HM 8012 Bedienungsanleitung

Mastech

Mastech MY70 Bedienungsanleitung

Steren

Steren MUL-300 Bedienungsanleitung

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Bedienungsanleitung

PeakTech

PeakTech 4000 Gebrauchs- und Pflegehandbuch

YOKOGAWA

YOKOGAWA 90050B Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Bedienungsanleitung

Fluke

Fluke 8846A Bedienungs- und Wartungshandbuch

Tempo Communications

Tempo Communications MM200 Bedienungsanleitung

Elenco Electronics

Elenco Electronics CM-1555 Bedienungsanleitung

Mastech

Mastech MS8238C Bedienungsanleitung

SDAR

SDAR 830A, 830B, 830D, 830C Bedienungsanleitung

RS PRO

RS PRO RS-9519BT Bedienungsanleitung

BGS technic

BGS technic 8890 Bedienungsanleitung

Amprobe

Amprobe Hexagon 60 Bedienungsanleitung

Morris

Morris 57074 Bedienungsanleitung
