Airlink101 AWLC6045 Bedienungsanleitung

Rev.1.0

Package Content:

•Cardbus Adapter

•Installation CD

•Quick Installation Guide

Model#AWLC6045

Section 1

Install Utility Software

300N Draft 802.11n Wireless Cardbus Adapter

This Quick Installation Guide only provides the basic instructions. For more

advancedfeaturessuch as configuring encryption settings, please refertothe

User’sManualintheprovidedCD.

Note: Donotinsert the Cardbus Adapter until you havereachedtheappointed

step.

For Windows 98SE and ME users, you may be prompted to insert the Windows

98SE or ME CD during the driver installation. Be sure to have your Windows 98SE

or ME CD ready.

Note: Ifthe Autorun screen doesn’t appear automaticallygotoStart, Run,and

type D:\Utility\Setup.exe (whereD is the letter of yourCDdrive)andclick OK.

Step 1 Insert the Installation CD into your CD drive and select Install Driver and

Utility fromthemenu.

Step 2 Click Next at the welcome screen.

Step 3 Click Next to accept the default destination folder.

Quick Installation Guide

Continue on back...

ContinueonBack

Step 5 Verify Yes, I want to restart my computer now is selected and click

Finish torestartyourcomputer.

Step 4 Click Continue Anyway at the Windows Logo Screen.

(For Windows 2000, click Yes at the Digital Signature Not Found prompt).

Step 7 Select Install the software automatically and click Next.

Step 8 Click Continue Anyway at the Windows Logo Screen.

(For Windows 2000, click Yes at the Digital Signature Not Found prompt).

For Windows 98SE and ME, select Search for the best driver for your device

and click Next. Verify all the check boxes are checked and click Next.

Step 9 Click Finish. (Restart the computer for Windows 98SE and ME).Step 6After your computer is restarted, insert the CardbusAdapter.

Section 3

Section 2

Configure the Cardbus Adapter

To open the utility, go to Start > (All) Programs > AirLink101 300N Wireless

Cardbus Adapter >AirLink101 300N Wireless Cardbus Adapter.

Step 1 Go to the AP List tab, select the SSID (Network Name) of the wireless

network you wish to connect to, and click Connect.

Step 2 If encryption is not enabled for the selected access point / router, skip to

step 6. Otherwise, enter a Profile Name for your wireless setting and click Next.

Step 3 Verify that the Network Name matches the SSID of your wireless network

and click Next.

E-mail:[email protected]

TollFree:1-888-746-3238

WebSite:www.airlink101.com

Section 3

Technical Support

Section 4

Step 4 The utility will detect the encryption settings of your wireless router or

access point and show it in the boxes below automatically. If you do not have any

encryption settings, you will not see this window. After selecting the proper

encryption settings from the drop-down menu, click Next.

Step 8Verifythat you are receivingadequateSignalStrength andLinkQualityand

thatyou have been assigneda valid IP address(instead of all 0’s).

Step 5 Follow the on-screen instructions to complete the encryption settings.

Click Complete when finished.

*Theoreticalmaximum wireless signalrate derivedfrom IEEE 802.11g standard and IEEE802.11ndraftspecification version1.0.Actualdata

throughputwill vary.Networkconditionsand environmentalfactors, includingvolume of networktraffic,buildingmaterials andconstruction,mix

ofwireless products used,radio frequencyinterference (e.g.,cordlesstelephones andmicrowaves) aswell as networkoverhead loweractual

datathroughput rate.Specificationsare subjectto changewithoutnotice. Allproducts andtrademarks aretheproperty oftheir respective

Step 6 You should see a blue circle around the antenna icon indicating a valid

connection.

Step 7 Go to the Link Information tab and click on the More button.
