Ameriwood HOME 2893222COM Bedienungsanleitung

2893222COM

Fireplace/TVStand

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B342893222COM0

WARNING

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:2

ESTIMATEDASSEMBLYTIME:2HOUR

3

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

5

BoardIdentification

Notactualsize

ThispieceispaperboardconstructionItisnotmadefrom

wood,butisrequiredfortheassemblyofyourunit.

LeftPanel

32893222010

RightPanel

32893222020

Partition

32893222030

Top

32893222040

Bottom

32893222050

Shelf

32893222060

TVRail

32893222070

VerticalRail

32893222080

HorizontalRail

32893222090

Door

32893222100

Divider

32893222110

BackPanel

K289322200

ABCD

6

BoardIdentification

Notactualsize

7

PartList

ActualSize

NotActualSize

(x15)

#A22610

cambolt

(x15)

#A22620

camlock

(x12)

#A21670

wooddowel

(x8)

#A23030

confirmatscrew

(x7)

#A12120

7/16"round

headscrew

(x2)

#A52365

knob

(x2)

#A17400

7/8"bolt

(x6)

#A22910

connector bolt

(x15)

#A12420

5/8"round

headscrew

(x1)

#A53655

anglebracket

(shown @ 1/2 scale)

(x5)

#A54800

footbracket

(x5)

#A44320

foot

123

8912

Note:Yourmodelmayhave

extrahardwareincluded.

(x6)

#A22920

connector

(x26)

#A21110

nail

(x1)

#A95010

fireplace insert

(x1)

#B64359

TV Warning Label

(x4)

#A65640

hinge

8

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x3)

#A22620

(x2)

#A22910

(x2)

#A21670

9

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22610

(x3)

#A22620

(x2)

#A21670

(x2)

#A65640

Loosenscrewtoseparatethe

hingeplatefromthehinge.

10

STEP3

Proper orientation of CAM LOCK

Tip

Assembly

Quick

113

(x2)

#A22910

(x3)

#A22620

(x2)

#A21670

(x2)

#A65640

(x2)

#A22610

Separate hinge plate from

hinge as you did in the

previous step.

finishededge

(leftsurface) (rightsurface)
