BestScope BS-2080MH10 Bedienungsanleitung
Multi-viewing Microscope
Model Number
BS-2080MH10
Instruction Manual
This instruction manual is for the microscope BS-2080MH10. To insure safety and obtain optimum
performance and familiarize yourself fully with the use of this microscope. We recommend that you
read the manual thoroughly before operating the microscope ,Attain this manual instruction in an easily
accessible place near the microscope for the further reference.
BestScope International Limited
1
Contents BS-2080MH10
Use Notices
1. Name of Components ……………………………………………………1
2. Installation ……………………………………………………………… 2
2-1 Order of Installation ……………………………………………………………2
2-2 Installation Steps ……………………………………………………………… 3
3. Adjustment ………………………………………………………………10
4. Operation ………………………………………………………………11
4-1 Primary Minor Operation ………………………………………………… 11
4-2 Adjusting Secondary Minor …………………………… …………………… 16
5. Technical Specifications ………………………………………………… 17
6. Trouble Shooting …………………………………………………………18
BestScope International Limited
2
Use Notices BS-2080MH10
I. Safety note
1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being damaged.
2. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and easy
shaking environment. Make sure the stage is smooth, horizontal and firm enough.
3. If the bacterium solution or the water splash to the stage, objective or viewing tube, pull out the
power cord at once, and wipe up the microscope. Otherwise, the instrument will be damaged.
4. When running, the lamp house and nearby parts will be very hot. Please ensure there is enough
cooling room for them.
5. Make sure the instrument is earthed, to avoid lighting strike.
6. For safety, be sure the main switch is in “O” (off) state before replace the halogen lamp or the fuse,
then cut off the power, and do the operation after the lamp bulb and the lamp house completely
cool.
7. Check the input voltage: be sure the input voltage which signed in the back of the microscope is
consistent with the power supply voltage, or it will bring a serious damage to the instrument.
8. Use the factory supplied power cord, please.
II. Maintenance
1. All the lenses have been well checked and adjusted. It is forbidden to disassemble them yourself.
2. The nosepiece and coarse/fine focus unit have a compact and precise frame, please don’t
disassemble them as possible as you can.
3. Keep the instrument clean, wipe dust regularly, and be attention to avoid contaminating the
optical elements especially.
4. The contaminations on the prism, as finger mark and oil, could be gently wiped with a piece of soft
cloth or tissue paper, gauze which has been immersed in pure alcohol or xylene. (notethatthe
alcohol and the xylene are all burned easily, do not let them near the fire, and use them in a
drafty room as possible as you can.)
5. Don’t use organic solvent to wipe the non-optical elements, when you need to clean, use the soft
detergent, please.
6. When using, if the microscope is splash by liquid, cut off the power at once,andwipeupthe
moisture.
7. Do not disassemble any parts of the microscope. That will affect the function or decline the
performance of the microscope.
8. Place the instrument in a cool, dry position. After using the microscope, remember to cover it
with dust helmet. Do wait for the lamp house cooling completely before cover.
BestScope International Limited
3
1. Name of Components BS-2080MH10
Video Port
Primary Minor
Trinocular Viewing Unit
Right Image Rotation
Connecting Tube
Secondary Minor
Binocular Viewing Device
Right Secondary Minor
Column support
Left Secondary Minor
Column support
Secondary Minor
Binocular Viewing Device
Left Image Rotation
Connecting Tube
Body Teaching Image
Rotation Minors
Microscope Body
BestScope International Limited
4
2. Installation BS-2080MH10
2-1 Order of Installation
Left Image Rotation
Connecting fitting
Mechanical Stage
Trinocular Viewing Unit
LED Pointer Image Rotation Set
Tow Binocular
Viewing Device
Microscope Body
Four Eyepieces Four EyepiecesTow Eyepieces
Tow Binocular
Viewing Device
Right Image Rotation
Connecting fitting
Left Secondary Minor
Column Support
Right Secondary Minor
Column Support
Left Connecting Fitting
Right Connecting Fitting
Objective
Lamp House
Video Port (optional)
①Installing the Mechanical Stage
②Installing the Lamp House
③Installing the Objective
④Connecting Teaching Image Rotation Set
⑤Connecting Left\Right Secondary Minor Set
⑥Stack Mounting Teaching Image Rotation Set
⑦Stack Mounting Secondary Minor Set
⑧Installing the Trinocular Viewing Unit
⑨Installing Binocular Viewing Device
⑩Installing Eyepiece and Video Port (optional)
① ②
③
④④
⑤⑤
⑥
⑦
⑦
⑧
⑨
⑨
⑩
⑩
⑩
⑩
BestScope International Limited
5
Figure 2
BS-2080MH10
2-2 Installing steps
Guide Board
Locking Block and Bolt
Figure 3
2-2-1 Installation Body’s chassis
1. Installing the Mechanical Stage
Support Device
Before installing the device, be sure to adjust
the coarse focus knob. Make the guide board
(see figure 1) down to the lowest position, so
you can install the mechanical stage support
device easily.
Hold on the mechanical stage support device
(figure 2), place it from the top of the guide
board (figure 1), let the device (figure2)
falling free until it reach the limit position.
Use the hexagon wrench screw down the
locking block, make the stage support device
(figure1) and the guide board fixed together.
The mechanical stage have been adjusted
horizontally and fixed together before leaving
factory. Do not disassemble unless necessary,
that may affect the observation precision of
the instrument.
Figure 1
BestScope International Limited
6
Figure 5
BS-2080MH10
3 Installing and Replacing the Lamp (figure4)
Please use the specified halogen Lamp 6V30W.
1. Hold to the bulb after you wrap it with gauze or other
protection materials, and then deeply insert it into the
lamp holder.
2. Replacing Lamp when using or soon after
When using, or soon after it is turned off, the lamp,
the lamp house and nearby parts will be very hot and
will cause serious burns. Please turn the main switch
on “O” (off), pull out power plug, and make sure the
bulb, the lamp room and periphery are all cool. Then,
you can do your replacing.
Please insert the lamp gently, or it will be damaged
by excessive extrusion
Do not touch the Halogen bulb with your bare
hands. It will shorten the service life or cause it to
burst. If you leave finger marks on the surface
carelessly, clean it with a dry soft cloth.
Figure 4
Bolt
Figure 6
Jack
Lamp House Bolt
2 Installing the Lamp House
Keep the bolt on the lamp house
(figure 4) in line with the jack on the
back of the microscope (like the show
of figure 5), then pushing the lamp
holder into the illumination kits gently
until they are against each other
(figure 6).
BestScope International Limited
7
BS-2080MH10
4 Installing the Objective
1. Adjusting the coarse focus knob until the
support device of the mechanical stage reach
its low limit position.
2. Wresting the lowest magnification objective
onto the nosepiece from the left or the right
side (figure 9), then push the nosepiece
clockwise, then place other objectives by the
sequence of low to high magnification
( figure 10).
Installing objective this way will make the
change of magnification to be easier while in
using.
Clean the objective regularly, the objective of
the inversed microscope is very sensitive to
dust.
When operating, use 10 ×magnification
objective to search specimen and focus
firstly, then replace with higher
magnification objective if necessary.
When replacing the objective, slowly
turning the nosepiece until you hear
“clicked”, that means the objective enter the
required position--the light path center.
Figure 7
Figure 8
BestScope International Limited
8
A-3 B-3A-2 A-2
B-2A-2
B-2
BS-2080MH10
l
2-2-2Connecting Teaching Image
Rotation Set
☆Spinning the left/right Image
Rotation Connecting Fitting
(figure9,figure11) into the
corresponding port of LED pointer
Image Rotation Set(figure10), and
make sure the coincidence of label
show in A-2,B-2. The result is
showing in the figure 16.
★When installing please make sure
the coincidence of label in the
left/right port of LED pointer
Image Rotation Set with the
left/right Connecting Fitting port
Figure 9 Figure 10 Figure 11
2-2-3 Connecting left/right
Secondary Minor Set
1. Spinning the left Connecting Fitting
(figure13) into left Secondary
Minor Column Support (figure
12), and make sure the
coincidence of the label show in
A-1. The result is showing in the
figure 16.
2. Spinning the right Connecting
Fitting (figure14) into right
Secondary Minor Column Support
(figure 15), and make sure the
coincidence of the label show in
B-1. The result is showing in the
figure 19.
★The height of left/right Secondary
Column Support have been
adjusted before leaving factory, Do
not adjustability unless necessary.
Figure 12
Left Secondary Minor
Column Support
Figure 13
Left Connecting fitting
Figure14
Right Connecting
Fitting
Figure 15 Right Secondary
Minor Column Support
A-1 A-1
B-1 B-1
BestScope International Limited
9
B-3 B-1
BS-2080MH10
2-2-4 Stack Mounting Teaching Set
1. Stack Mounting Teaching Image
Rotation Set
Please loosen the bolt on
microscope head and insert the
Teaching Image Rotation Set
(figure16) into Microscope head
installed (figure17) , turn to a
proper position, then use the
hexagon wrench screw down the
bolt to fix.
Figure 16
Figure 19
2. Stack Mounting Secondary Minor Set
Easing bolts off on the left Secondary
Minor A-3 port and the right
Secondary
Minor(figure18)B-3port,making them
and left/right Teaching Image
Rotation Set on the same level,
adjusting their distance and direction,
make sure their Connecting tube on a
horizontal and connecting on the
biggest port, then screwing down the
bolt to fix.
★Before installing, please make sure
the coincidence of label in the
left/right Secondary Minor A-3/B-3
port with the port of Teaching Image
Rotation Set.
Figure 17
A-1 A-3
B-3 B-1
Figure 18
BoltBolt
A-3 A-2 B-2 B-3
Inhaltsverzeichnis
Andere BestScope Mikroskop Handbücher
BestScope
BestScope BS-2076 Series Bedienungsanleitung
BestScope
BestScope BS-2080D Bedienungsanleitung
BestScope
BestScope BS-3015 Series Bedienungsanleitung
BestScope
BestScope BS-6000B Bedienungsanleitung
BestScope
BestScope BS-2094C Bedienungsanleitung
BestScope
BestScope BLM2-241 Bedienungsanleitung
BestScope
BestScope BS-7000B Bedienungsanleitung
BestScope
BestScope BS-2052BDBD Bedienungsanleitung
BestScope
BestScope BS-5092 Series Bedienungsanleitung
BestScope
BestScope BLM-205 Bedienungsanleitung
BestScope
BestScope BS-6002 Series Bedienungsanleitung
BestScope
BestScope BS-2041FB(LED) Bedienungsanleitung
BestScope
BestScope BS-2064 Series Bedienungsanleitung
BestScope
BestScope BS-2052 Series Bedienungsanleitung
BestScope
BestScope BS-4000A Bedienungsanleitung
BestScope
BestScope BS-2030B Bedienungsanleitung
BestScope
BestScope BS-5040B Bedienungsanleitung
BestScope
BestScope BS-2020B Bedienungsanleitung
BestScope
BestScope BS-2036F2B(LED) Bedienungsanleitung
BestScope
BestScope BS-6000A Bedienungsanleitung
Beliebte Mikroskop Handbücher anderer Marken
Thermo Scientific
Thermo Scientific Nicolet iN10 Leitfaden
National
National DC3-163 Bedienungsanleitung
KERN Optics
KERN Optics OPE-1 Bedienungsanleitung
OPTIKA MICROSCOPES
OPTIKA MICROSCOPES B-150D Bedienungsanleitung
Prior
Prior Lux POL Bedienungsanleitung
Opitec
Opitec Smartscoop 115615 Bedienungsanleitung
VWR
VWR VisiScope 384 Series Bedienungsanleitung
Nikon
Nikon ECLIPSE E200 POL Bedienungsanleitung
Leica
Leica DI C800 Handbuch
ThermoFisher Scientific
ThermoFisher Scientific Continuµm Bedienungsanleitung
ThermoFisher Scientific
ThermoFisher Scientific Continuµm Bedienungsanleitung
Olympus
Olympus SZ61 Bedienungsanleitung
