Bosch BX3 Bedienungsanleitung

BX3

Instructions for use

9000 148 718 A 07.09.2007 12:23 Uhr Seite 1

Your vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Disposal information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

When the work is done . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Emptying the dust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Cleaning the filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Replacement parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Frequently asked questions and answers . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Troubleshooting small problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

9000 148 718 A 07.09.2007 12:23 Uhr Seite 2

1 Adjustable floor tool*

2 Hard-floor brush*

3 Pet hair brush

4 Telescopic tube*

5 Sliding switch*

6 Suction pipe*

7 Handle*

8 Flexible hose

9 Upholstery nozzle*

10 Crevice nozzle*

11 Multi-purpose nozzle*

(crevice nozzle + hard furnishings brush)

12 Parking aid

13 Power cord

14 Exhaust filter cover

15 Carrying handle

16 Dust container release button

17 Emptying button

18 Dust container

19 Maximum level mark

20 Dust container flap

21 Particulate filter with lint filter and foam filter

22 On/off button with electronic suction regulator

23 Exhaust filter*

24 Dual separator with lid

25 Dual separator

26 Dual separator release button

*Depending on equipment

7*6* 8

23 222526 24 21 20

9* 10* 11*

Your vacuum cleaner

9000 148 718 A 07.09.2007 12:23 Uhr Seite 3

Please keep this instruction manual.

Please pass on this instruction manual if

you pass this vacuum cleaner on to a

new owner.

Intended use

This vacuum cleaner is intended for

household

use and is not intended for commercial

purposes.

This vacuum cleaner should only be

used in accordance with these

instructions for use.

The manufacturer will not accept any

responsibility for damage caused by

improper use or incorrect operation.

Therefore, please note the following

points.

The vacuum cleaner must only be

operated with:

manufacturer's replacement parts,

-accessories and -optional

accessories

The vacuum cleaner is not to be used

for:

vacuuming persons or animals

vacuuming up:

- insects (e.g. flies, spiders, etc.).

– hazardous, sharp-edged,

– hot or burning substances

- damp or liquid substances

- highly flammable or explosive

substances and gases

Safety information

This vacuum cleaner complies with the

recognised rules of technology and the

relevant safety regulations. We confirm

that it complies with the following

European directives: 89/336/EEC

(amended by Directives 91/263/EEC,

92/31/EEC and 93/68/EEC). 73/23/EEC

(amended by Directive 93/68/EEC).

Always observe the information on the

rating plate when using the vacuum

cleaner and connecting to the power

supply.

Never vacuum without the dust

container and particle filter fitted.

=> This can damage the vacuum

cleaner!

Only allow children to use the vacuum

cleaner under supervision.

Keep the vacuum cleaner away from

the face when using nozzles and

tubes.

=> This could cause injury!

Never carry the vacuum cleaner by the

power cord or hose.

Fully extend the power cord when

using the vacuum cleaner continuously

for several hours.

When disconnecting the appliance

from the mains, pull the plug, not the

power cord.

Do not pull the power cord around

sharp corners or allow it to become

trapped.

Unplug the vacuum cleaner from the

mains before carrying out any work on

it.

Do not use the vacuum cleaner if it is

damaged. Unplug the power cord

from the mains if a fault is detected.

9000 148 718 A 07.09.2007 12:23 Uhr Seite 4

For safety reasons, only authorised

after-sales service personnel are

permitted to carry out repairs and fit

replacement parts to the vacuum

cleaner.

The vacuum cleaner should be

protected from outside weather

conditions, moisture and sources of

heat.

The vacuum cleaner is not suitable for

use on building sites.

=> Vacuuming up building rubble

could damage the vacuum cleaner.

Switch off the vacuum cleaner when it

is not in use.

At the end of its life, the vacuum

cleaner should be disposed of in an

appropriate manner.

Disposal information

Packaging

The packaging is designed to protect

the vacuum cleaner from being

damaged during transportation.

It is made of environment-friendly

materials and can be recycled.

Dispose of packaging that is no longer

required at an appropriate recycling

point.

Used vacuum cleaner

Used vacuum cleaners still contain

many recyclable materials.

Therefore, please take used vacuum

cleaners to your retailer or recycling

centre so that they can be recycled.

For current disposal methods, please

enquire at your appliance dealership or

local council.

!Please note

Only connect the appliance to a

socket that is protected by at least a

16 amp circuit breaker.

If a circuit breaker should trip when you

switch on the vacuum cleaner, this

may be because other electrical

appliances which have a high current

draw are connected to the same

power circuit.

To prevent the circuit breaker from

tripping, select the lowest power

setting before switching the vacuum

cleaner on, and increase the power

only once it is running.

9000 148 718 A 07.09.2007 12:23 Uhr Seite 5

Push the handle onto the flexible hose until it engages.

*Depending on equipment

Push the crevice nozzle and upholstery nozzle into the

accessories holder as illustrated.

*Depending on equipment

Push the flexible hose adapter into the air intake

opening on the dual separator until it engages.

CLICK!

Before using for the first time

Setting up

9000 148 718 A 07.09.2007 12:23 Uhr Seite 6

Push the handle into the suction pipe/telescopic tube.

To remove it, turn the handle slightly and pull it off the

tube.

*Depending on equipment

Insert the suction pipe/telescopic tube into the adapter

of the floor tool.

*Depending on equipment

To remove the flexible hose, turn it to release the catch

and pull the hose out.

Setting up

9000 148 718 A 07.09.2007 12:23 Uhr Seite 7

To remove it, turn the tube slightly and pull it out of the

floor tool.

*Depending on equipment

Connect the suction pipes together, or...

...unlock the telescopic tube to adjust its length by

moving the sliding switch in the direction of the arrow.

*Depending on equipment

Holding the power cord by the plug, pull out the

required length and plug it into the mains socket.

Setting up

9000 148 718 A 07.09.2007 12:23 Uhr Seite 8

Adjust the suction by turning the on/off button in the

direction of the arrow.

Set the power setting to maximum for the best results

when vacuuming. We recommend that you reduce the

setting only when vacuuming very delicate materials.

Adjust the adjustable floor tool:

Rugs and carpets =>

Hard/parquet floors =>

*Depending on equipment

Press the on/off button in the direction of the arrow to

switch your vacuum cleaner on/off.

Vacuuming

Setting up

9000 148 718 A 07.09.2007 12:23 Uhr Seite 9

Remove the upholstery nozzle and crevice nozzle from

the accessories holder as illustrated.

Adjust the "autofloor" floor tool:

Hard floor setting =>

Fixed position for vacuuming hard/parquet floors

Automatic setting => auto

The nozzle adjusts automatically to the floor covering

and switches from hard/parquet floors to carpeted

floors

Carpet setting =>

Fixed position for vacuuming rugs and carpets

If you are vacuuming varying types of floor

coverings (hard floors <-> carpets), we recommend

that you use the automatic setting so that the

nozzle adjusts automatically to the floor and you

do not need to switch over the nozzle setting.

To clean the "autofloor" nozzle, switch it to the hard

floor setting and simply vacuum it using the suction

pipe/telescopic tube.

*Depending on equipment

auto

Vacuuming

9000 148 718 A 07.09.2007 12:23 Uhr Seite 10
