CYP DCT-23 Bedienungsanleitung

DCT-23

Integrated Zone Amplier

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version VR1.0 January 2012

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VR0 10/02/15 Preliminary Release

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel ........................................3

6.2 Rear Panel.........................................4

6.3 Remote Control................................5

6.4 OLED Menu .......................................6

6.5 RS-232 Protocols ...............................7

6.6 RS-232 & Telnet Commands............8

6.7 Telnet Control ...................................9

6.8 Web GUI Control ............................11

7. Connection Diagram .......................... 12

8. Specications ...................................... 13

1. INTRODUCTION

The Integrated Zone Amplier can accept any one of analog and

digital audio from 3.5Ø line in, R/L RCA, HDMI, optical and coaxial

inputs and output synchronously to R/L speaker, HDMI, optical and

coaxial outputs with microphone sound added. Suitable for any

musical events use, sound addition, and sound amplifying. With audio

output sampling rate supports up to 48kHz and I/O data rate supports

up to 24-bit, it provides a high standard of quality sound presentation

an can amplier sound up to -80dB.

2. APPLICATIONS

• Public speech

• Show event audio set up

• Home theater

• Educational/Lecture presentation

3. PACKAGE CONTENTS

• 1 x Integrated Zone Amplier

• 1 x IR Extender

• 1 x Remote Control CR-126

• 1 x 24V/ 3.75A DC Power Adaptor

• 1 x Power Cable

• 1 x Rack Ears set

• Operational Manual

4. SYSTEM REQUIREMENTS

Input audio source equipment such as DVD/Blu-ray players, PC, CD

player, MP3 and …etc. with output display TV/monitor and active

speakers.

5. FEATURES

• Supports Digital to Analog audio Conversion (DAC) and Analog to

Digital audio Conversion(ADC)

• Supports input sampling rate up to 96kHz, output at 48kHz and

HDMI loop out

• Supports video resolution from VGA~WUXGA(RB) or 480i~1080p

• Supports HDMI bypass

• Supports microphone sound mix into output sounds

• Synchronous output sound on both digital and analog

• Supports RS-232, Telnet, WebGUI, IR and on-panel controls

• Sound supports up to -80dB

• Elegant design and easy to install/using

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

EXIT POWER

UPDATE

Integrated Zone Amplifier

CONTROL

PUSH

MIC

1 2 3 4 5 6 7

1MIC: Connect with microphone for input sound signal.

2UPDATE: Connect with USB ash driver for rmware update only.

3LCM: Display current input source selection and volume setting.

4IR Window: Accept IR signal from the remote control included in

the package.

5CONTROL: This button has 2 uses, one for volume control and 2

for menu selections. Turn the wheel to adjust the output sound

volume outside the menu or press it to enter into the menu

selection. After enter into the menu turn the wheel to rotate from

the selection and press it again to enter or conrm.

6EXIT: Press this button to exit from the menu selection. When

outside the menu selection press this button to mute the output

sound, the LED will illuminate in red . Press it again to unmute.

7POWER: Press this button to turn on the device and the LED will

illuminate in blue. Press it again to switch to standby mode and the

LED will turn red.

6.2 Rear Panel

CONTROL

HDMI OUT HDMI IN 1 HDMI IN 2

RS-232 LINE IN

OUTOPT. COAX.

INOPT. COAX.

OUTR

SPEAKER

RCA

IN DC 24V

IR IN

OUT

IN RLRL

1 2 4 7 129

3 5 6 8 10 11

1CONTROL: Connecting from PC/NB with RJ-45 cable for telnet

control.

2HDMI OUT: Connect to HD TV/monitor for both audio and video

display.

3IR IN: Connect the IR extender included in the package for

receiving the IR signal from the device’s remote control.

4HDMI IN 1& 2: Connect to DVD/Blu-ray players or any HDMI source

equipment for input audio and video signal sending.

5RS-232: Connecting from PC/NB with D-Sub 9pin cable for RS-232

controls.

6LINE IN: Connect from audio device with 3.5Ø phone jack for

stereo audio signal input.

7OPT. & COAX. OUT: Connect from active optical speakers &

coaxial speakers for digital audio outputs.

8OPT. & COAX. IN: Connect from source equipment such as Set-

top-box or PS3 or any other source with optical and coaxial output

for audio signal sending.

9R/L SPEAKER: Connect from speakers with wired cables for stereo

audio output.

10 R/L IN: Connect from audio source equipment with RCA jack for

stereo audio input.

11 R/L OUT: Connect L/R output to active speakers with RCA jack for

stereo audio output.

12 DC 24V: Plug the 24V DC power supply into the unit and connect

the adaptor to an AC outlet.

6.3 Remote Control

1POWER:

Press this button to switch on the

device or set it to standby mode.

2MUTE:

Press this button to mute all the

output sound.

3 VOL.▲▼:

Press these buttons to turn the output

volume up and down.

4MENU:

Press this button to bring up the OLED

MENU then press the ▲&▼ buttons to

select and press it again to conrm

the selection.

5EXIT:

Press this button to return or exit from the menu selection.

6INPUT:

Press these hot keys to switch the input sources instantly.

CR-126

MUTE

POWER

VOL.

EXIT

HDMI 1 HDMI 2

OPTICAL

COAXIAL LINE

INPUT
