QU-16E-4K
1 to 16 HDMI Distribution Amplier (4K Resolution Support)
OPERATION MANUAL
3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 23/06/14 First release
5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions .......8
6.1 Front Panel................................................... 8
6.2 Rear Panel..................................................... 8
7. Connection Diagram .............................9
8. Specications...................................... 10
9. Acronyms............................................. 10
6
1. INTRODUCTION
The QU-16E-4K is a versatile 1 to 16 HDMI distribution amplier.
This product is designed to be used in a 19″rack and will distribute
uncompressed HDMI signals up to 4K resolutions. Each buered output
can run 1080p/8-bit up to 10 metres and can be cascaded up to two
layers.
2. APPLICATIONS
Simultaneously display one HDMI source on 16 displays
Showroom display
University lecture hall display
Retail sales display
3. PACKAGE CONTENTS
1× 1 by 16 HDMI Distribution Amplier
1× 5V/6 A DC Power Supply Adaptor
Operation Manual
4. SYSTEM REQUIREMENTS
HDMI equipped source device such as a DVD/Blu-ray player with HDMI
or DVI to HDMI cable
HDMI equipped displays (HDTVs or projectors) or AV Receivers with
HDMI cables
7
5. FEATURES
HDMI, HDCP 1.1 and DVI 1.0 compliant
Resolution Supported: PC - VGA to UXGA; HDTV - 480i to 1080p +
1080p24fps, and 4K
High Denition Audio supported: LPCM 7.1Ch, Dolby TrueHD, Dolby
Digital Plus and DTS-HD Master Audio transmission (32-192kHz Fs
sample rate)
HDMI cable distance tested with 1080p/8bits resolution the I/O source
can up run up to 15/15 meters. If 1080p/12bits the I/O source can run
up to 15/10 meters.
Supports xvYCC
Supports CEC bypass
Supports 3D signals
4K Resolution Support
Note: When displaying a 3D signal with a higher bandwidth than 225 MHz or
a 4K×2K resolution source, a High Speed HDMI cable is required.
8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWERSYNC
1 2
1
POWER LED: The power LED will illuminate when the unit is powered.
2
SYNC LED: The LED will illuminate when the HDMI source signal is
connected to the input port.
6.2 Rear Panel
DC 5V
SERVICE
2
1
4
3
6
5
8
7
10
9
12
11
14
13 15
STD TV
INPUTOUTPUT
EDID
16
1 2 3 4 5
1
EDID STD/TV: The default factory setting is TV, when in this mode,
the unit will detect the rst HDMI output device's EDID settings and
record them in the unit's memory. If there are any audio or video
issues then switch the unit to STD (Standard) mode and power cycle it,
the unit will be congured as standard stereo (PCM) Audio and initiate
a search for a common compatible video resolution.
2
SERVICE: Manufacturer use only.
3
HDMI INPUT: Connect the input port to the HDMI or DVI output of
your source equipment such as DVD player or set-top box.
4
HDMI OUTPUTS (1~16): Connect each of the output ports to an
HDMI display for simultaneous HDMI distribution.
5
DC 5V: Connect the 5V DC power supply into the splitter and Plug the
adaptor to AC wall outlet.
9
7. CONNECTION DIAGRAM
DC 5V
SERVICE
2
1
4
3
6
5
8
7
10
9
12
11
14
13 15
STDTV
INPUT OUTPUT
EDID
16
TV/Projectors
TV/Projectors
Power
Supply
Blu-ray
Player
HDMI Input Simultaneous
HDMI Outputs
Simultaneous
HDMI Outputs
10
8. SPECIFICATIONS
Video Bandwidth 300 MHz/9 Gbps
Input Port 1×HDMI (Female connector), 1×USB
(Manufacturer use only)
Output Ports 16×HDMI (Female connector)
Output Resolutions 480i~1080p@50/60, 1080p@24/50/60,
VGA~UXGA, Ultra HD (4K×2K@30)
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Dimensions 436 mm (W)×26 mm (D)×48 mm (H)
Weight 1664 g
Chassis Material Metal
Colour Black
Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F
Storage Temperature −20 ˚C~60 ˚C/−4 ˚F~140 ˚F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 15.8 W
9. ACRONYMS
ACRONYM COMPLETE TERM
4K×2K Ultra HD Resolution (3840×2160)
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
