CYP CH-2527TXV Bedienungsanleitung
CH-2527TXV & CH-2527RXV
4K UHD+ HDMI w/HDR over HDBaseT
Transmitter (PD) & Receiver (PSE)
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2017 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 09/03/06 Preliminary release
CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................2
5. Features............................................................3
6. Operation Controls and Functions.................4
6.1 Transmitter's Front and Rear Panels......... 4
6.2 Receiver's Front and Rear Panels............ 6
6.5 IR Cable Pinouts ........................................ 8
6.6 RS-232 Pinout ............................................. 8
7. Connection Diagram ......................................9
8. Specications ................................................10
8.1 Technical Specications (Transmitter) .. 10
8.3 Video Specications............................... 12
8.4 Audio Specications............................... 13
8.4.1 Digital Audio................................... 13
8.5 Cable Specications .............................. 14
8.6 HDBaseT Features.................................... 15
9. Acronyms .......................................................16
1
1. INTRODUCTION
This transmitter and receiver set is a great solution for extending UHD
video and audio as well as Ethernet and control via a single run of
Cat.5e/6/7 cable over distances up to 100 meters. This extender set
complies with the advanced HDCP 2.2 and HDMI 2.0 standards, as
well as supporting the legacy HDCP 1.x and HDMI 1.x standards.
Despite HDBaseT’s 10.2Gbps bandwidth limitation, 4K UHD HDMI video
sources, up to and including 4K@60Hz (4:4:4, 8-bit) as well as 10/12-
bit sources with HDR, are able to be processed and extended by the
use of AVLC (Adaptive Visually Lossless Compression) when needed.
Multiple data and control interfaces are also provided, including IR,
RS-232 and LAN connections. The Transmitter (PD) is powered by PoH
(Power over HDBaseT) provided by the Receiver (PSE), allowing for
greater exibility within different installation scenarios.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
Transmitter
• 1×4K UHD HDMI w/HDR over HDBaseT Transmitter
• 1×48V/0.83A DC Power Adapter
• 1×Power Cord
• 1×3.5mm to IR Blaster Cable
• 1×Operation Manual
Receiver
• 1×4K UHD HDMI w/HDR over HDBaseT Receiver
• 1×3.5mm to IR Extender Cable
• 1×Operation Manua
2
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of "Premium High Speed" HDMI cables, and industry
standard Cat.6, Cat.6a or Cat.7, is highly recommended.
3
5. FEATURES
• HDMI with HDR, 3D & 4K@60Hz support, DVI 1.0 compatible
• HDCP 2.2 and HDCP 1.x compliant
• Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input
and output
• Supports Deep Color input and output up to 12-bit
• Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output.
• Supports CEC bypass
• HDBaseT output transmits video, audio and data over a single
Cat.5e/6/7 cable and can reach distances up to 70m/230ft at 4K
when using Cat.6a/7
• Supported HDBaseT feature set: HD Video & Audio, 100BaseT
Ethernet, PoH, and Control (Bi-directional IR/RS-232 pass-through)
• Integrated AVLC (Adaptive Visually Lossless Compression) activates
when the bandwidth requirements of the source are beyond
10.2Gbps (340MHz) allowing for support of sources up to 18Gbps
(600MHz) with no loss of visual quality
• The AVLC function allows manual selection between High Quality
(Full bandwidth) mode and Standard mode (Lower bandwidth,
activates at a lower bandwidth threshold)
• Supports pass-through of many audio formats including 8 channel
LPCM, Bitstream, and HD Bitstream
• Receiver (PSE) provides power to the Transmitter (PD) using PoH
(Power over HDBaseT)
Note: The PoH function is designed for powering compatible
Transmitter units only. Non-PoH Transmitters will need their own power
supply. Transmitters from other brands may not be compatible.
4
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter's Front and Rear Panels
LINK
PWR
RS-232 IN
STD
UPDATE
SYNC
HQ/STD
ISP
HQ
STD
AVLC
1 2 3 5 64
HDMI INCAT5e/6/7 OUT
IR2
EXTENDER
IR1
BLASTER
7
89 10
1AVLC HQ/STD Switch: This switch allows the user to select which
compression mode to use when AVLC is active.
HQ (High Quality) mode uses the least amount of compression and
provides the highest possible visual quality (perceptually identical
to the original). In this mode, AVLC compression activates for any
signal requiring more than 9Gbps.
STD (Standard Quality) mode applies additional compression
methods to lower the bandwidth requirements even further,
improving transmission reliability at the cost of some visual delity.
In this mode, AVLC compression activates for any signal requiring
more than 7.5Gbps.
2ISP Pinhole: This button is reserved for factory use only.
3UPDATE Switch: This switch is reserved for factory use only. The
default setting is “STD”.
4RS-232 IN Port: Connect to a PC, laptop, or serial controllable
device for the extension of RS-232 signals between both ends of
the HDBaseT connection.
5LAN Port: Connect to an Ethernet supporting device or to your
local network, as appropriate, to extend the network to both ends
of the HDBaseT connection.
5
6SYNC LED: This LED will illuminate when a live input source is
detected.
HQ/STD LED: This LED will illuminate whenever the AVLC function
is active. A green LED indicates that AVLC is in HQ (High Quality)
mode. A red LED indicates that AVLC is in STD (Standard) mode.
POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
LINK LED: This LED will illuminate solidly when a live connection with
a compatible Receiver is active. The LED will blink with a regular
pattern if a Receiver is connected but there is not currently a live
signal. The LED will blink with an irregular pattern if a connection
error has occurred.
7IR1 BLASTER Port: Connect to the provided IR Blaster to transmit IR
signals from the other end of the HDBaseT connection to devices
within direct line-of-sight of the IR Blaster.
8IR2 EXTENDER Port: Connect to an IR Extender to receive IR control
signals and extend them to devices connected to the other end
of the HDBaseT connection. Ensure that the remote being used is
within direct line-of-sight of the IR Extender.
9CAT 5e/6/7 OUT Port: Connect to a compatible HDBaseT Receiver
with a single Cat.5e/6/7 cable for transmission of all data signals.
PoH will also be supplied when connected to a compatible PSE
Receiver.
10 HDMI IN Port: Connect to HDMI source equipment such as a media
player, game console, or set-top box. DVI sources are supported
with the use of an HDMI to DVI adapter.
