Cypress CY3633 Bedienungsanleitung

Cypress Semiconductor

3901 North First Street

San Jose, CA 95134

Tel.: (800) 858-1810 (toll-free in the U.S.)

(408) 943-2600

www.cypress.com

Version 1.1

CY3633

WirelessUSB™ LS Gaming

DVK User’s Guide

Warranty Disclaimer and Limited

Liability

Cypress Corporation makes no warranty for

the use of its products, other than those

expressly contained in the Company’s stan-

dard warranty which is detailed in Cypress’s

Terms and Conditions located on the Com-

pany’s web site. The Company assumes no

responsibility for any errors which may appear

in this document, reserves the right to change

devices or specifications detailed herein at any

time without notice, and does not make any

commitment to update the information con-

tained herein. No licenses to patents or other

intellectual property of Cypress are granted by

the Company in connection with the sale of

Cypress products, expressly or by implication.

Cypress’s products are not authorized for use

as critical components in life support devices

or systems.

WirelessUSB is a trademark of the Cypress

Corporation. PSoC is a trademark of Cypress

Microsystems. All product and company

names mentioned in this document are the

trademarks of their respective holders.

CY3633 User’s Manual,

Version 1.1.

Cypress Semiconductor Corporation.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Quick Start Using the Pre-programmed Chips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

XBOX Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PlayStation2 Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Auto-Bind Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Game Controller Calibration Process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

XBOX Firmware Development . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

XBOX Receiver Dongle Firmware Development . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Software Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Software Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Compiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Using the USB Chip Emulator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

XBOX Memory Unit Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Game Controller Firmware Development. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Hardware Configuration For Controller Firmware Development . . . . . . . . . . . . . . . . . . . 13

Compiling and Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

PlayStation2 Firmware Development. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

PS2 Receiver Firmware Development . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

PS2 Game Controller Firmware Development . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1 Page -1

WirelessUSB™ LS Gaming DVK User’s Guide

1.0 Introduction

The WirelessUSB LS CY3633 Gaming DVK is an add-on to the WirelessUSB LS CY3632 DVK.

The Gaming DVK is intended to serve the gaming industry by providing example wireless solutions

for the XBOX and PlayStation2 (PS2) gaming platforms.

The contents of this DVK combine with the CY3632 DVK to provide a hardware/firmware solution

for XBOX and PS2 gaming platforms. Refer to the CY3632 Users’s Guide for a list of basic hard-

ware components that will be required to use the additional components supplied with the Gaming

DVK. The Gaming DVK provides the following components:

• USB Hub Adapter board with a pre-programmed CY7C65113 USB chip

• XBOX USB Adapter cable (PN 300-11840)

• CY8C27643 PSoC™ pre-programmed adapter board (labeled “XBOX G”) to provide

XBOX Game Controller functionality

• CY8C27643 PSoC™ pre-programmed adapter board (labeled “PS2 G”) to provide PS2

Game Controller functionality

• CY8C27643 PSoC™ pre-programmed adapter board (labeled “PS2 D”) to provide PS2

receiver dongle functionality

•PlayStation interface cable (PN 300-11841)forconnecting the PS2 receiver to the PS2 game

console

• Plastic joystick knobs

• CD-ROM

• Printed documentation

Hardware items that are required from the standard CY3632 WirelessUSB LS DVK, which

are not included in the CY3633 WirelessUSB LS Gaming DVK are:

• Platform Board PDC-9075 (assembly 121-07500*G) with joysticks and potentiometers

installed

• Platform Board PDC-9075 (assembly 121-07501*E) without joysticks or potentiometers

installed

• Two Radio Modules (PDC-9163)

• Standard USB cable (PN 140xc2)

WirelessUSB™ LS Gaming DVK User’s Guide

Page -2 WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1

The following diagram shows the contents of the CY3633 WirelessUSB LS Gaming DVK.

Figure 1. WirelessUSB LS Gaming DVK Kit Contents

2.0 Quick Start Using the Pre-programmed Chips

Out of the box, the Gaming DVK is ready to support both the XBOX and PlayStation2 gaming plat-

forms.

2.1 XBOX Quick Start Guide

The XBOX system consists of two Platform Boards (PDC-9075): One is used for the XBOX Don-

gle and the other is used for the XBOX Game Controller.

Dongle - Assembly 121-07501*E (the assembly number is printed on a

white sticker near the DC power jack) has the USB Hub

Adapter Board piggy-backed onto socket U2A, and there are

no potentiometers or joysticks loaded on the board.

Game Controller - Assembly 121-07500*G has the PSoC device labeled “XBOX

G” installed into socket U3.

XBOX USB

Adapter Cable

PlayStation2

Interface Cable

Joystick Knobs

CD-ROM

"PS2 G" PSoC Module

"PS2 D" PSoC Module "XBOX G" PSoC Module

Programmed USB Chip

Blank USB

Chips

USB Hub Adapter

Board

PS2 G

PS2 D

XBOX G

WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1 Page -3

The hardware setup for operating the XBOX gaming system is shown in Figure 2.

Figure 2. XBOX System Hardware Configuration

A close-up of the receiver dongle is shown Figure 3. The XBOX USB Adapter Cable along with a

standard USB cable are used to interface the Platform Board to the XBOX Console. Power for the

receiver is provided by the XBOX USB interface. Note: The Platform Board and the standard USB

cable are supplied with the standard CY3632 WirelessUSB LS DVK (they are not included in the

CY3633 WirelessUSB LS Gaming DVK).

Figure 3. USB Hub Adapter Board installed into Platform Board (XBOX Receiver Dongle)

Joystick Knobs

XBOX USB Adapter

Cable

Standard

USB Cable

XBOX Game

Console

"XBOX G"

Chip

(No Chip)

Receiver/Dongle Platform Board

(without Joysticks or Potentiometers)

Game Controller Platform Board

(with Joysticks and Potentiometers)

USB Hub Adapter

Board with USB

Chip Installed

WirelessUSB™ LS Gaming DVK User’s Guide

Page -4 WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1

The Game Controller has a PSoC™ device labeled “XBOX G” installed into socket U3 of the Plat-

form Board. The Game Controller can be powered with batteries or the provided power supply

connected to J5 (DC power jack).

To configure the XBOX system, perform the following steps:

1. Power on the XBOX game console and load any XBOX game.

2. Install the USB Hub Adapter board as shown in Figure 3 above and ensure that the radio mod-

ule is installed in P1 correctly.

3. Connect the XBOX USB Adapter Cable to any of the four game ports on the XBOX Console.

4. Attach the “A” end of the standard USB cable to the other end of the XBOX USB Adapter

cable.

5. Connect the “B” end of the standard USB cable into Platform Board connector J3.

6. Verify that header J2 has pins 1 and 2 connected, which selects VBUS as the power source

for the board.

7. On the Game Controller board, verify that the radio and the proper PSoC™ adapter board are

installed on the board before power is supplied to the assembly. Verify that all eight potentiom-

eters, POT A-H, are turned fully counterclockwise.

8. If batteries are used as the power source, then install them now or plug in the DC power sup-

ply if batteries are not being used. Only one or the other can be used at a time. Ensure that

header J2 has pins 2 and 3 connected. This selects the battery or external DC power source.

9. Perform the binding procedure described in Section 2.3.

The figure below shows the PSoC Adapter Board that is used to adapt the 48-pin SSOP PSoC to

the 48-DIP socket on the platform board.

Figure 4. PSoC Adapter Board Assembly

CY8C27643 48-pin

SSOP PSoC

Pin 1

In System

Programming

Header

PSoC Adapter Board

WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1 Page -5

The mapping of the XBOX Game Controller joysticks, analog buttons, and digital buttons on the

Platform Board is shown in Figure 5. The eight potentiometers on the Platform Board act as analog

buttons, where clockwise rotation behaves as a depressed button, while fully counterclockwise

rotation behaves as a released button. The push-buttons that make up the Platform Board keypad

area are used for the Game Controller digital buttons as shown in the figure. Pressing the ‘Mode’

button will cause the ‘Right Joy button’ to activate the ‘R Trigger’ function in order to facilitate first

person shooter games. The ‘Connect’ LED flash rate will increase when in the button swap mode.

‘Reset Factory’ is used to clear all of the stored auto bind parameters and should be used when-

ever the radio module has been replaced. See Section 2.3 for more details.

Figure 5. XBOX Joysticks, Analog Buttons, and Digital Buttons

White

Trigger

Black

Trigger

Left Joy

button

Right Joy

button

"Gamepad" area of Platform Board

Num

Lock

Up +

Left

Up +

Right

Left

Right

Start +

Back

Down +

Left

Down

Down+

Right

Select

Start

Enter

Mode

"Keypad" area of Platform Board

Reset

Factory

WirelessUSB™ LS Gaming DVK User’s Guide

Page -6 WirelessUSB™ LS Gaming DVK User’s Guide Rev 1.1

2.2 PlayStation2 Quick Start Guide

The PlayStation2 system hardware configuration is shown in Figure 6.

Figure 6. PlayStation2 System Hardware Configuration

The PlayStation2 gaming system uses the Platform Board assembly (121-07501*E) as the

receiver dongle. The PSoC chip labeled “PS2 D” should be installed in chip socket U3 of the

receiver dongle Platform Board. The PlayStation interface cable is used to interface the receiver

Platform Board assembly to the PS2 game console. The PS2 provides power through this cable to

the receiver assembly.

Figure 7. PS2 Interface Cable Connection Diagram

P layS tation2 Interface C able

PlayStation2 Game

Console

Game Controller Platform Board

(with Joysticks and Potentiometers)

Dongle/Receiver Platform Board

(without Joysticks or Potentiometers)

"PS2 G"

Module

"PS2 D"

Module

Joystick Knobs

Inhaltsverzeichnis

Andere Cypress Mikrocontroller Handbücher

Cypress

Cypress S6E1C1 Series Betriebsanleitung

Cypress

Cypress CY8CKIT-147 Handbuch

Cypress

Cypress CE219490 Bedienungsanleitung

Cypress

Cypress S6J3200 Series Bedienungsanleitung

Cypress

Cypress PSOC CY8CKIT-146 Bedienungsanleitung

Cypress

Cypress Perform PSOC 5LP PROTOTYPING KIT Bedienungsanleitung

Cypress

Cypress PSoC CY8CKIT-048 Bedienungsanleitung

Cypress

Cypress MB9BF564K Bedienungsanleitung

Cypress

Cypress EZ-USB AT2LP CY4615B Bedienungsanleitung

Cypress

Cypress MB9BF568R Series Bedienungsanleitung

Cypress

Cypress FM0+ S6E1C-Series Bedienungsanleitung

Cypress

Cypress MB95710M Series Bedienungsanleitung

Cypress

Cypress CY3280-BSM Bedienungsanleitung

Cypress

Cypress CYW9P62S1-43438EVB-01 Bedienungsanleitung

Cypress

Cypress PSOC 3 CY8CKIT-030A Bedienungsanleitung

Cypress

Cypress PERFORM MB96630 Series Bedienungsanleitung

Cypress

Cypress EZ-USB NX2LP-Flex CY3686 Bedienungsanleitung

Cypress

Cypress CY8CKIT-040 PSoC 4000 Pioneer Kit Bedienungsanleitung

Cypress

Cypress CY8CKIT-042 Bedienungsanleitung

Cypress

Cypress EZ-PD CY4502 Bedienungsanleitung

Cypress

Cypress PSoC 5 CY8CKIT-050A Bedienungsanleitung

Cypress

Cypress SPANSION FM4 MB9BF568 Series Bedienungsanleitung

Cypress

Cypress S29XS128R Bedienungsanleitung

Cypress

Cypress CY3642 Bedienungsanleitung

Beliebte Mikrocontroller Handbücher anderer Marken

AMS

AMS AS7261 Demo Kit Bedienungsanleitung

Novatek

Novatek NT6861 Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266 SDK Einrichtungshandbuch

Nuvoton

Nuvoton ISD61S00 ChipCorder Leitfaden

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Bedienungsanleitung

Texas Instruments

Texas Instruments Chipcon CC2420DK Bedienungsanleitung

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Bedienungsanleitung

NEC

NEC 78GK0S/K 1+ Series Montage- und Bedienungsanleitung

Mikroe

Mikroe SEMITECH N-PLC Click Montage- und Bedienungsanleitung

Intel

Intel Agilex Bedienungsanleitung

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320F2837 D Series Bedienungsanleitung

CYPRES

CYPRES CY14NVSRAMKIT-001 Bedienungsanleitung

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266EX Betriebsanleitung

Abov

Abov AC33M8128L Bedienungsanleitung

Laird

Laird BL654PA Bedienungsanleitung

Silicon Laboratories

Silicon Laboratories C8051F800 Bedienungsanleitung
