Daewoo RC-6003F Bedienungsanleitung

;;;;;;

VACUUM CLEANER

RC-6003F

READ AND KEEP THIS

• Thank you for purchasing this vacuum cleaner.

• For proper operation, please read and this manual before use.

OWNER’S MANUAL

CONTENTS

•Description and operation.....................................2,3

•Cleaning the filter and Changing the dustbag...........4

•Precaution for safe use .............................................5

•Specifications...........................................................6

•Before asking for service...........................................6

ACCESSORY NOZZLEWIDE SUCTION NOZZLE

DESCRIPTION AND OPERATION

HOSE CONNECTION

PIPE CONNECTION

• To connect the nozzle, hold the

tubes and the handle:

insert the narrowed section.

•Connecting the hose : insert the

hose firmly into the hose inlet.

(“Click”)

•Disconnecting the hose: press

the button and pull the hose out

of the vacuum cleaner.

CLICK!

SUCTION CONTROL

•The suction control at the hand

grip enable you to control suction.

•Use this nozzle for cleaning both

carpeted and uncarpeted floors.

Floors Carpet

DUSTING BRUSH

CREVICE NOZZLE

PRACTICAL PARKINGRY NOZZLE

DUST METER

ON/OFF SWITCH

•Press the on/off switch.

CORD REWIND

•Rewind the power cord by

pressing the cord rewind button.

•When the color of the dust

meter is changed to RED for

long time, change the dust

bag<page 4.>

STORAGE

•If you want to store the cleaner,

hitch the brush clip onto the

vacuum cleaner

•If you want to stop vacuum

cleaning for a while, you can

place the brush clip into the rest.

ROL

he hand

l suction.

RUSH

BRUSH

CLIP

BRUSH

NOZZLE

CLEANING THE FILTER

CHANGING THE DUST BAG

•Switch off

•Open the cover. •Pull out motor proctection filter. •Shake the dust out of the filter.

•Close the cover.

•Switch off and open the cover. •Hold the cover while

separating the dustbag from

the dustbag holder.

•Open the exhaust grill. •Pull out the exhaust filter.. •Shake the dust out of the filter.

•Close the exhaust grill..

•Insert the new dust bag into

the dustbag holder properly

as shown in picture.

•IClose the cover.

231

564

MOTOR PROTECTION

FILTER

EXHAUST

FILTER

Note: If no dust bag has been placed into the dustbag holder, the cover can not be closed.

•Do not vacuum areas which contain moisture

or water and inflammable matter, needles,

pins, razor blades, matches, cigarette-ends,

etc., since they may damage the cleaner or

dust bag or cause a fire.

•Make sure a dust bag and a motor protection

filter are always inserted.

•When rewinding the power cord, hold the plug

body before pressing the cord rewind button to

prevent whipping.

•Do not pull the power cord out beyond the

specified length.

•This product provided with a cable which, if

damaged, must be replaced by a repair shop

authorized by the manufacturer since special

tools are required.

This vacuum cleaner should only be used for normal dry household dust and dirt.

The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner

contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can be

accepted for any possible damage.

PRECAUTIONS FOR SAFE USE

■ Before Asking for Service, please check each item below if you have trouble with your cleaner.

BEFORE ASKING FOR SERVICE

Problem

Suction power is weak.

The cleaner does not work.

Power cord does not rewind.

Check Point

•Dust bag

•Pipe or hose

•Power cord

•ON/OFF switch

•Power cord

Measure

If dust bag is dirty, replace it.

If clogged or blocked, remove the object.

Check if power cord is plugged.

Check if the power switch is turned on.

Pull the power cord out a little and press

the cordrewind button.

•Specifications can be changed for improvement without notice.

Model

Rating

Watts

Weights(Net)

Dimension (L X W X H)

Cord Length

RC-6003F

230V/50Hz

MAX 1600W

5.3kg

478X 286 X 235mm

SPECIFICATIONS
