Daewoo RC-382A Bedienungsanleitung

䮦#Read the instruction manual carefully before using this vacuum

cleaner!

䮦##To protect environment, Please don’t throw away this unit with

daily rubbish together.

Model: RC-382A

VACUUM CLEANER

INSTRUCTION MANUAL

FEATURES

䮦Streamline mold-making and original design, representing modern fashionable life.

䮦With strong suction power

1600W/1800W/2000W motors, strong suction power.

䮦Multi-filter to avoid the second air pollution

Using the multi-filter system ensures cleaning out all the dust, and keep the air clean from

the outlet.

䮦One appliance fit with various suction nozzles for multi-purposes

Various suction nozzles are used to suck up dust on carpet or hard floor but also to remove

dust on wall, ceiling, couch, bed and all home electric appliance.

䮦Pedal on/off buttons for easy operation

Pedal on/off buttons can release you from stooping for easy operation.

䮦Suction power with freely regulation

To regulate the suction power on the air flow handle and unit.

䮦Dust bag full indicator function

When the dust bag or the air filter is full of dust, the dust full indicator on top of the body will

be covered by red indications. This shows that you need to empty the dust bag or clean the

air filter.

Warning:

1.This appliance is for household use only, It is only used

indoors for dust, but not applied for industrial or decorating

areas. It can not suck in water.

2.This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of

the appliance by a person responsible for their safety.

3.Children should be supervised to ensure that they do not play

with the appliance.

DESCRIPTION OF THE PARTS

Combi

crevice nozzle

Sofa brush

PRECAUTIONS HOW TO ASSEMBLE

䮦#Before using, please make sure the network voltage coincides with the product rated voltage.

䮦

##When in use, do not block or shelter the rear outlet cover to avoid influencing normal air

exhaustion. Otherwise, the motor will be damaged by overheat.

䮦

##If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a

similarly qualified person in order to avoid a hazard.

䮦#

#Keep the appliance away from stove or any other high temperature objects so as not to

influence its operation by deforming its plastic parts.

䮦#

#Do not bend, extrude or pull by the flexible hose, Stop using the broken or damaged

hose, instead to use the new hose.

䮦#

#When you need to clean your appliance or stop operation, unplug from the power outlet.

When unplugging, be sure to hold the plug, but not pull or carry by the power cord.

䮦#

#Never use the appliance without dust bag or when the dust bag is broken or not

assembled .

䮦#

#When sucking, do not suck up particles as mud, paste ,wall ashes, or sharp articles.

otherwise it may result in obstruction to the dust bag or air filter or damage to the motor.

If sucking up these particles, please immediately clean the dust bag and air flow filter.

䮦#

When in use, do not suck up suck hair rolls, large paper rolls or plastic bags which may

easily lead to block the suction hole or suction tube or hose. Other wise it may cause

breakdown or deforming of body cover. If any block occur to the suction ,immediately

stop operation by unplugging from the outlet for cleaning.

䮦#

When cleaning the appliance, wet cloth soaked with water or neutral detergent shall be

used instead of gasoline or banana water. Otherwise it may lead to breakage of

fadedness of the body cover.

䮦

Push the button of hose head,

and insert it into unit inlet until

locked

䮦

If want to pull out the hose from

unit, please press the button on

the hose before pull out.

䮦

How to use connecting tubes

and curved wand?

When connecting, insert the

bigger end of the connecting

tube into air flow handle and

then swivel it to firm connection.

䮦

Connection of the tubes. Refer

to the above said.

䮦

Connection of connecting tube

with floor brush. For connection,

insert the smaller end of

connecting tube into the tube on

the floor brush, and then swivel

it to firm connection.

䮦

Regarding the connection of

connecting tubes with crevice

nozzle, refer to the above said.

TO START OPERATION

䮦#

Pull out the power cord

The power cord can be pulled out as long as it is marked with yellow color. It is

forbidden to exceed the red mark

䮦#

Power button

After plugging into electrical power outlet, press the power button on the body cover to

control start and stop.

䮦#

Regulation of suction power

You can control suction power not only by speed regulation knob but also by air flow regulator on handle. (fig.1, fig.2)

䮦#

For corner or crevice place, you can use combi nozzle

䮦#

For couch, curtain or decoration surfaces, the sofa brush should be used. And the floor

brush is used for blanket and floor.

䮦#

Cleaning dust bag and replacing parts.

When the cleaner indicator on top of the body is filled with red indications, it means the

dust bag is full of dust. You need to replace paper dust bag and clean the air filter when

clogged.

䮦#Replacing the dust bag

1) Lift up by the front cover clamp to open the front cover (fig.3)

2) To take out the dust bag from dust bag holder.(fig.4)

3) If you use a paper dust bag, replace it with a new one. If a cloth dust bag, Take out the clip and open the

dust bag to empty dust then insert it back to Its Position for further use by sealing the bag well with the

clip.(fig.5)

4) Assembling the dust bag, you should press the clamp button on the bag holder, and insert the dust bag

into the two slots, then release the button to clip the dust bag.(fig 6)

5) If the dust bag is broken, replace it immediately

䮦#

Replacing the front cover and turn the dust bag holder over to take out the filter for

cleaning or replace a new one.

䮦#

Replacing the air outlet filter

Press the clamp position of the air outlet cover to discharge the air outlet cover for

clean up or a new replacement.

䮦#

Cleaning the air inlet and outlet filter.

1) Put the filter into running water for rinsing.

2) Remove some water by patting the filter with towel, then dry it in cool place.

3) Dry the filter in a ventilation place, take care not to bake it so as to avoid being

deformed by high temperature.

Warning: Neither wash the filter in a washing machine nor dry it with a hair dryer.

(fig.1) (fig.2)

(fig.3) (fig.4) (fig.5) (fig.6)

8 9

䮦#

Power cord rewinding

When not in use, unplug from the electrical power outlet and then press the cord

rewinding button to feed back the power cord.

䮦#

For storage

Insert the plastic holder of the Connecting tube into the unit base or

holder hook on the back unit.

䮦#

Put the combination crevice nozzle in the accessory hole in the bottom of the body after

finishing suction.

TROUBLE SHOOTING GUIDE

䮦

Please check the following details before you have your appliance repaired in an authorized

servicing department.

Problem

Motor can’t

work

1. Check if the power plug is firmly

inserted into the outlet.

2. Check if the power switch of the

appliance is on.

3. Check if the heat sensitive thermostat

be off due to overheating.

1. Insert the plug back again into the outlet to

secure it is switched on.

2. And then turn the power switch on.

3. After the motor be cool off, the unit will

restart working automatically.

Suction

power

becomes

weak

1. Check if the hose, floor brush or

connecting tube is clogged.

2. Check if the dust is full;

3. Check if the air filter is clogged, the

connecting tube is correctly attached.

1. Immediately remove the obstruction.

2. Empty dust.

3. Clean the dust bag for reassembly of

connecting tubes.

Power cord

will not fully

feed back

䮦#

Check if the power cord is twisted. Pull out the power cord at its certain length

and rewind it.

Power cord

can not be

taken out

䮦#

The power cord may be twisted.

Rewind or pull the cord in or out for several

times by pressing the power cord rewind

button.

Power cord

rewinds itself

䮦#

###

The inertial rewinding by the cord

rewinder device may lead to be out of

control.

Pull the power cord out in for 4-5 times. If

still rewinds itself, ask for an authorized

servicing department for repair.

No speed

regulation

䮦#

###

The speed regulation device may be

out of control

Restart the appliance for reuse at several

times, if it is exactly out of control, ask for an

authorized servicing department.

Front cover

can't be

closed

䮦#

###

Check if no dust bag is put inside or

the front cover deformed without dust

bag in good position.

Put the dust bag in good position and then

take the appliance to the authorized

servicing department.

Dust full

indicator is

covered by red

indications

䮦#

###

Check if the floor brush, the hose or

the long connecting tube is blocked.

See if the dust bag is full and the air

filter is clogged.

Immediately remove obstructions away.

Clean or replace the dust bag. Clean the air

inlet filter.

Possible reason Solution
