De Agostini Model Space MiG-29 Bedienungsanleitung

PACK 16PACK 16

STAGE PAGE

76 Installing the wiring 179

77 Fuselage assembly 182

78 Battery box 185

79 Port tail n 187

80 The port rudder 189

Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ.

Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue • New York, New York 10171.

Warning: Not suitable for children under the age of 14.

is product is not a toy and is not designed or intended for use in play.

Items may vary from those shown.

179

Your parts

1. P214 - External fuel tank upper

2. X018 - Electrical wires

3. X019 - Electrical wires

4. P215 - External fuel tank pylon half

5. P216 - External fuel tank pylon half

FP, MM and CM screws

P214

X018

P215 P216 FP MM CM

X019

1 Fit the two halves of the external

fuel tank pylon (P215 and P216)

together, as shown. Secure them

with an FP screw.

Assembly

2 Insert the assembled pylon into the recess at the front of the

external fuel tank upper (P214) and secure from the inside with

an FP screw.

P215 P214 P214

P216

P216 P215

Stage 76:

Installing the wiring

180

3 Now take out the wall covering the port mainwheel

by removing the screws indicated.

5 Then take out the starboard mainwheel wall by

removing the screws indicated.

7 Pass electrical wires X018 through the central

section of the frame, as shown. Make sure ends

A and B are in the correct positions.

4 Remove the port mainwheel from the frame by

loosening the screws in the order shown.

6 Loosen the screws in the order shown to remove the

starboard mainwheel.

8 Then install wires X019, as shown. Pay attention to

the location of ends C and D.

D016

X018

X019

181

9 Lay electrical wire C (X019) into the cutout at the

side of the frame, and place the port mainwheel

back into position.

11 Lay the electrical wire D (X019) into the cutout

in the side of the frame and place the starboard

mainwheel back into position.

13 Put the port mainwheel wall back in place and

secure with the two CM screws.

10 Fix the port mainwheel back in place with the

two MM and two FP screws.

12 Fix the starboard mainwheel back in place with

the two MM and two FP screws.

14 Fix the starboard mainwheel wall back in position

with the two CM screws.

D031

D016

D046D037

P069

P068

DD FP

FP MM

182

Stage 77: Fuselage assembly

Your parts

1. P217 - External fuel tank lower

2. P218 - External fuel tank end

HP, MP, BM, DM and CM screws

1 Retrieve the external fuel

tank assembly from Stage

76. Fix the external fuel

tank end (P218) into the

end of the fuel tank with

an HP screw.

Assembly

2 Install the

assembled port

engine onto the

upper fuselage.

Fix in place on

the outside with

a BM screw.

3 Fit the assembled

starboard engine

onto the upper

fuselage, and ﬁx

in place with a

BM screw.

P218

P217

P218

P164D046

P214

P128D046

183

4 Carefully align

the upper and

lower halves of

the fuselage.

Pass the wiring

(X018 and X019)

through the hole

in the lower

fuselage, as

shown.

5 Connect the ends of the port landing light wiring.

7 Connect the starboard landing light wiring and hide

the wires in the same way.

6 Then hide the wires as shown.

8 Begin securing the fuselage halves together, starting

at the nose. Tighten two DM screws into the

indicated holes.

P192

X018

X019

X018

X019

X015

X018

X016

X015

P211

X018

184

9 Then tighten a further four DM

screws in the indicated locations

in the lower fuselage.

11 Tighten another six DM screws

into the indicated holes.

13 Pass the two wires in the centre of the fuselage through

the hole in the external fuel tank upper (P214).

10 Tighten two more DM screws

into the lower fuselage.

12 Tighten two MP screws into the locations

shown above.

14 Tighten a CM screw into the indicated hole on the

outside of the port engine. 15 Then tighten a CM screw into the matching hole

on the outside of the starboard engine.

P214

D046P203

P211 D076 D076

P192

P207

P205

D046

185

Stage 78: Battery box

Your parts

1. P219 - Battery box cover

2. P220 - Battery box

VM and KR screws

1 Retrieve the fuselage

assembly and the external

fuel tank lower (P217). Secure

the external fuel tank upper

to the lower fuselage with a

BM screw.

2 Connect the wiring from

the battery box (P220) to

the wires in the fuel tank.

Assembly

P220

P219

P214

P220

186

3 Carefully place the wires

inside the external fuel tank,

as shown.

4 Position the battery box

in the fuel tank and secure

to the posts with two

KP screws.

5 Fix the battery box switch

to the posts behind the box

with two KP screws.

7 Push the battery box cover

(P219) into position, closing

the battery box.

6 Mount the external fuel

tank lower (P217) over the

battery box, and secure to

the fuel tank upper with

three KP screws. Make

sure no wires get trapped

between the two halves.

P214 P220

P220

P219P217

P217
