Digi Connect® Family Application Guide

How to Create a VPN between a Connect Gateway

and WatchGuard

_______________________________________________________________________

5/14/2009 Digi International 1 of 5

Scenario

Digi Connect WAN is used for remote site connectivity. The primary site is using a

WatchGuard VPN appliance. The two networks need to be connected, and the data needs

to be encrypted between them.

Theory of Operation

A remote location needs to be able to build a secure tunnel between the main site and a

remote branch. One location is using a Digi Connect gateway to provide primary internet

connectivity. The other location is using a WatchGuard VPN appliance for primary site

connectivity. AVPN tunnel will be created to the Digi Connect gateway, creating a

secure connection for data to pass through.

Sample Diagram

Internet Cloud

PCs, PLCs, etc.

Servers, PCs, PLCs, etc.

ConnectPort WAN

WAN IP: 1.2.3.4

LAN IP: 192.168.1.1 WatchGuard

WAN IP: 5.6.7.8

LAN IP: 192.168.111.1

Carrier Plan and PC / VPN Appliance Requirements

Digi Connect Requirements: Firmware version must be 2.8 or later. To download the

latest firmware, go to http://www.digi.com/support.

GSM GPRS/EDGE APN Type needed: VPN and GRE end-points usually require static

(persistent) IP addresses and must support mobile terminated data connections. If mobile

termination is not an option with your current APN, you will need to acquire a new one

that does support mobile termination.

CDMA networks may also require special plans to provide static IP addresses and

support mobile terminated data connections.

Check with your wireless provider on the available plan types.

Digi Connect Family Application Guide –Connect Gateway to WatchGuard

5/14/2009 Digi International 2 of 5

Digi Connect Gateway Configuration

1. Read and follow the quick-start guide for the Digi Connect gateway.

2. Assign a static IP address to the Ethernet port (the default address is 192.168.1.1).

3. Configure the Digi Connect gateway settings

a. Navigate to Configuration > Network > VPN Settings.

b. Click VPN Policy Settings.

c. Click Add.

d. Fill in the appropriate settings, shown in the screenshots below:

Digi Connect Family Application Guide –Connect Gateway to WatchGuard

5/14/2009 Digi International 3 of 5

e. Click Apply to save the changes.

Digi Connect Family Application Guide –Connect Gateway to WatchGuard

5/14/2009 Digi International 4 of 5

WatchGuard VPN Configuration

1. Configure the WatchGuard VPN device

a. Log into the Web Interface of the WatchGuard device.

b. Navigate to VPN in the left hand panel.

c. Under the section titled 'Manual VPN Gateways', click Configure.

d. Click Add to add a new VPN policy.

e. Fill in the appropriate information shown in the screenshots below

f. Click Submit to save the changes.

Digi Connect Family Application Guide –Connect Gateway to WatchGuard

5/14/2009 Digi International 5 of 5

ADDITIONAL NOTES

1. This configuration will work with Dynamic IP addresses, using hostnames

established with DynDNS.org. When using a Dynamic IP address, you will need to

set the VPN tunnel to use Aggressive Mode to make the connection work.

2. This configuration will work with other VPN parameters than what is listed in the

screenshots. i.e. –DES, 3DES, AES 192-bit, AES 256-bit, etc.

3. This configuration will work with other Digi Cellular products, such as the Connect

WAN, Connect WAN 3G, and ConnectPort WAN VPN series of products that

support VPN connections.

Where to Get More Information

Refer to the Digi Connect gateway user documentation and Digi technical support

website at www.digi.com/support for more information. Technical assistance is available

at http://www.digi.com/support/eservice/eservicelogin.jsp.

For sales and product information, please contact Digi International at 952-912-3444 or

refer to the Digi Cellular pages at www.digi.com.
