Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

ABOUT MANUAL

06212011

User Manual

Vandal Dome Camera

V1362DIR / V1363TIR / V1382TIR

GGDonot open or modify.

GGDonot open the case except during maintenanceand installation,

for it may bedangerous and can cause damages.

GDonot put objects into the unit.

GGGG

Keep metal objects and ammablesubstances from entering the camera. Itcan cause re, short- circuits,

or other damages.

GGGBe careful when handling the unit.

Toprevent damages, do not drop the camera or subjectit to shockor vibration.

Donot install near electric or magnetic elds.

Protectfrom humidity and dust.

Protectfrom high temperature.



Be careful when installing near the ceiling of akitchen or aboiler room, as the temperature may rise to

high levels.

Cleaning

GGGGGToremovedirt from the case, moisten asoft cloth with asoft detergent solution and wipe.

Mounting Surface

GGGGGThe material of the mounting surfacemust bestrong enough to support the camera.

PRECAUTIONS

Before sending your camera out for repair, check the items below.

If the problem persists after checking these items, contact your service

center.

No Video

Is the coaxial cable attached securely?

Is there adequate illumination?

Out-of-Focus Video

Is the lens in focus?

Is the lens dirty?

(commercially available) and a soft cloth or lens cleaning paper.

WARNING :TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

TROUBSHOOTING

DIMENSIONSIN MILLIMETERS*

6.5

41.3

103.1

109.6

91.0

85.0

ø145

ø4.5

ø5.0

117.0

125.0

85.0

91.0

VIDEO (YELLOW)

DC 12V or AC24V

5mm TWIST SOLDERING

L= 300mm

BNCJACK

BLACK

RED

INSTALLATION*

the Fixing Screws (D).

2. Separate the Upper Case (A) and the Base (E).

3. Detach the Gimbal (C) from the Base (E).

4. Cut a hole in the ceiling for routing the cables.

5. Place the Base (E) horizontally against the ceiling and

drill the screwholes at the two marked positions.

6. Pass the Power Cable (F) and Video Cable (G) from the

camera unit through the cable hole in the ceiling.

7. Align the screwholes of the camera unit with the

holes in the ceiling. Secure the camera to the ceiling

with the two screws.

8. FixGimbal (C) to the Base (E).

9. Install and adjust the camera unit.

10. Adjust the dome liner to showthe lens through the

11. Attach the Upper Case (A) with the Base (E) and tighten

Loosen the Fixing Screw(D), using a screwdriver.

camera window, and then x it to the Base (E).

CONNECTION*

CAUTION : CHECK FOR POLARITY WHENUSING ADC12VPOWER SUPPLY.

DC12V

DC12V/ AC24V

300.0

CAMERASETTINGS*

1. Set the zoom level to the desired position by moving the Zoom Lever.

2. Set the focus, using the Focus Lever.

GLENSADJUSTMENT

1. Focus Lever

2. Zoom Lever

CAMERA SETTING FORSIDEOSD CONTROL BOARD

V1362DIR, V1363TIR, V1382TIR

RIGHT

LEFT

UPDOWN

CON1

CON2

FUNCTIONAL OF CONTROL BOARD

[1] SW

Functional control of O.S.D(On Screen Display)

[2] CON1

Second Video output connector

[3] CON2

RS-485 connector

NOTE:

PRESS

EFAULT IS“001”FOR

GGGGGGGGGGPRESS TO ACCESS THE MENU

NOTE : THE CAMERA ID IS A DIGIT NUMBER.

REMOTECONTROL*

1. Set the Camera iDin the OSD menu. The default

setting is 001. NOTE:

you must reset the power for the newsettings to

apply. Once you reset the power, the camera will

recognize the newCamera ID.

2. If you press the KEY Button, the camera display

will turn into the standby image. NOTE:The LED

3. Input the same number used as the Camera ID to

the Remote Controller. After the number has been

input, the LEDlight will turn on, and the remote

controller will be ready to use. NOTE:The ID

number is 3digits.

4. The ZOOMIn (+) and ZOOMOut (-) Keys are used

to control the zoom of your camera lens and to

select the zoom area of alarm function. Select the

area where you wish to observe the movement of

objects.

5. Select the zoom range by pressing the WIDE (7)

Key. Save the zoom range by pressing the TELE (8)

Key. NOTE: If the zoom range is smaller than the

alarm standby range, the zoom range setting will

not be saved.

Menu Access and Control

Motion Alarm

ON / OFF

Key Button

ID Buttons

Zoom Function Control

GREMOTECONTROL Instructions

MODULEOSD MENU*(V1362DIR)

EXPOSURE COLORDAY&NIGHT

BRIGHTNESS

SHUTTER

BLC

AGC

WB MODED&N MODE

FUNCTION MOTION PRIVACY

MIRROR

SHARPNESS

GAMMA

SLC

HME

DRC

ALARMMASK 1

MASK 2

MASK 3

MASK 4

COLOR SET

SYNCSETUPEXIT

SYNCCAMERA ID

TITLE EDIT

TITLE RESET

TITLE POSITION

DPC SET

LANGUAGE

PC CONT.

EXIT

SAVE & EXIT

FACTORY RESET
