Dirt Devil SD20000RED Bedienungsanleitung

Dirt Devil® 3-in-1

Stick Vacuum

Model # SD20000RED /

SD22010 / SD22015

USER MANUAL

#961152154 / R3

Français - page 16

Español - página 30

REPLACEMENT PARTS

• FILTER TYPE

SD22010 / SD22015 F113

SD20000RED F25

THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.

IF USED COMMERICALLY WARRANTY IS VOID.

HI. WELCOME.

PRODUCT

REGISTRATION

For quick reference, please record your product information below.

Model #:

Mfg. Code:

(Mfg. code located on the back or bottom of product)

Warranty Registration

Be sure to register your product online at www.DirtDevil.com or

call 1-800-321-1134 to register by phone.

Hint: Attach your sales receipt to this Owner’s manual. Verification of date of purchase may be

required for warranty service of your Dirt Devil®product.

Congrats on purchasing your new Dirt Devil®3-in1

Stick Vacuum. Inside, you'll ﬁnd everything you'll

need to know about your latest purchase.

So what are you waiting for? LET’S GO.™

Find GENUINE Replacement Parts at www.dirtdevil.com

This product uses the following parts:

FILTER TYPE _____________________ F113 / F25

Quick Start Assembly 6-7

How to 8-11

Troubleshooting 12

Limited Warranty 13

Replacement Parts 14

TABLE OF

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INTRUCTIONS!

READ ALL SAFETY WARNINGS AND INSTRUCTIONS BEFORE USING THIS PRODUCT.

When you use an appliance, basic precautions should always be followed, including the following:

• READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

• ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS.

• BRING VACUUM CLEANER TO UPRIGHT POSITION WHEN USING THE HOSE AND ATTACHMENTS.

• DO NOT LEAVE VACUUM CLEANER UNATTENDED WHEN PLUGGED IN.

• REGULARLY CHECK THE FILTER TO CLEAN OR REPLACE.

• WARNING: FULLY ASSEMBLE CLEANER BEFORE OPERATING.

• WARNING: DO NOT USE SHARP OBJECTS TO CLEAN OUT THE HOSE SINCE THEY COULD CAUSE DAMAGE.

• OCCASIONALLY REMOVE BRUSH AND CLEAN DEBRIS FROM END CAPS TO KEEP BRUSH ROTATING

SMOOTHLY.

WARNING: TO REDUCE THE RISK OF FIRE,

ELECTRIC SHOCK OR INJURY:

• Fully assemble product prior to use.

• Do not leave appliance when plugged in. Unplug from outlet when not in use

and before cleaning or servicing.

• Do not use outdoors or on wet surfaces. Electrical shock could occur.

• Do not allow to be used as a toy. Not intended for use by children age 12 and under. Close

supervision is necessary when used by or near children. To avoid injury or damage, keep children

away from product, and do not allow children to place fingers or other objects into any openings.

• Use only as described in this manual. Use only manufacturer’s recommended attachments and

products.

• Do not use product with damaged cord or plug. If product is not working as it should, has been

dropped, damaged, left outdoors, or dropped into water, call customer service at 1-800-321-1134

prior to continuing use.

• Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp

edges or corners. Do not place product on cord. Do not run appliance over cord. Keep cord away

from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any objects into openings. Do not use with any opening blocked; keep free of dust, lint,

hair, and anything that may reduce air flow.

• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

• Do not use without dirt cup and filters in place.

• Turn off all controls before unplugging.

• Look on your vacuum cleaner and follow all label and marking instructions.

• Use extra care when cleaning on stairs. To avoid personal injury or damage, and to prevent the

cleaner from falling, always place cleaner at bottom of stairs or on floor. Do not place cleaner on

stairs or furniture, as it may result in injury or damage.

• Do not use to pick up flammable or combustible liquids, such as gasoline, or fine wood sandings,

or use in areas where they may be present.

WARNING:

To reduce the risk of electric shock, this appliance has a polarized plug (one blade is

wider than the other). This plug will fit in a polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet. Do not change the plug in any way.

CAUTION: TO REDUCE THE RISK OF DAMAGE:

• Avoid picking up hard, sharp objects with this product, as they may cause damage.

• Store appropriately indoors in a dry place. Do not expose machine to freezing temperatures.

• Brush roll continues to turn while product is turned on and handle is in upright position unless

vacuum is in "Suction Only" mode (available on select models) .To avoid damage to carpet, rugs,

and flooring, avoid tipping cleaner or setting it on furniture, fringed area rugs, or carpeted stairs

during tool use.

SAVE THESE INSTRUCTIONS

• Keep the vacuum cleaner on the floor. Only the hand-held vacuum cleaners may be set on

furniture.

• Vacuum cleaner must be in the upright position to lift the rotating brush off the carpet when

doing above floor cleaning.

• Do not use an extension cord with this vacuum cleaner.

• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent tripping

accidents.

• Operate cleaner only at voltage specified on date plate on back of cleaner.

QUICK START

*Not all models have this feature.

ATTACH FIXED HANDLE*

SURROUND HANDLE TUBE

WITH THE TWO HANDLE

GRIP PIECES AND PRESS

TOGETHER UNTIL YOU HEAR A

CLICK. USE SCREWDRIVER TO

INSERT THE TWO SCREWS. BE

SURE THE TUBE IS BETWEEN

THE HANDLES BEFORE

SCREWING IN SCREWS.

INSERT HANDLE TUBE INTO

HAND VAC.

TOOL REQUIRED:

PHILLIPS OR FLAT HEAD

SCREWDRIVER

FULLY ASSEMBLE OR INSTALL PRODUCT

PRIOR TO USE.

YOUR DIRT DEVIL

IS READY

TO CLEAN!

NEED HELP?

Go to dirtdevil.com/support or

contact our Customer Service

Department at 1 (800) 321-1134

9:00 a.m. - 6:00 p.m. EST Mon. - Fri.

Pick up the conversation on...

Twitter@DirtDevil

Facebook.com/DirtDevil

QUICK START

3 4

ATTACH FLOOR NOZZLE TO

UNIT.

WHEN FINISHED, WRAP

CORD AROUND HOOKS FOR

CONVENIENT STORAGE. ATTACH

THE PLUG END TO THE CORD.

HOW TO

OPE RATE

1 2

TO TURN ON: SLIDE THE

POWER SWITCH TO THE ON

POSITION.

TO TURN UNIT OFF: SLIDE THE

POWER SWITCH TO THE

OFF POSITION.

OFF SUCTION

NOTE: Filter is rinseable with water. Do not use soap/detergent. Let filter air dry for 24 hours or until completely dry.

For replacement filter F113 / F25 visit dirtdevil.com or call us at (800) 321-1134.

HOW TO

OPERATE HAND VAC

NEED HELP?

Go to dirtdevil.com/support or

contact our Customer Service

Department at 1 (800) 321-1134

9:00 a.m. - 6:00 p.m. EST Mon. - Fri.

Pick up the conversation on...

Twitter@DirtDevil

Facebook.com/DirtDevil

1 2

SLIDE RELEASE BUTTON BACK

THEN REMOVE HANDLE

FROM UNIT.

REMOVE NOZZLE BY PULLING

ON REAR OF NOZZLE AND

PULL FROM UNIT.

NOT TO BE USED FOR GROOMING A PET

CAUTION

HOW TO

REMOVE AND

REPLACE THE FILTER

TO REDUCE THE RISK OF INJURY, TURN POWER

SWITCH OFF BEFORE CLEANING OR SERVICING.

WARNING

1 2

DEPRESS THE DIRT CUP RE

LEASE BUTTON WHERE IT

SAYS FILTER.

HOLD DIRT CUP OVER A WASTE

BASKET. GRASP FILTER AND

GENTLY PULL OUT FILTER BASKET.

3 4

SHAKE DIRT AND DEBRIS OUT

OF DIRT CUP.

REMOVE THE FILTER

FROM THE

FILTER BASKET.

BRUSH THE DUST

AND DIRT OFF THE FILTER, OR

SHAKE THE FILTER INSIDE OF

THE WASTEBASKET.

FOR REPLACEMENT FILTER F113 / F25 VISIT DIRTDEVIL.COM OR CALL US AT (800) 321-1134.

TIP: To maintain performance, filter should be changed

every 3-6 months, or as needed.

LUBRICATION:

The motor is equipped with bearings which contain sufficient lubrication for its lifetime. The addition of lubricant could cause damage.

Do not add lubricant to motor
