INSTALLATION GUIDE

277CAN

Trouble Sounder

277CAN Installation and Programming Guide | Digital Monitoring Products 1

GET STARTED

The Model 277CAN Trouble Sounder is an audible trouble alert.

What’s Included

▶277CAN Trouble Sounder

Processor Fail Alert

The 277CAN Trouble Sounder monitors the keypad bus to sound an alert whenever the keypad bus is faulted. The

sounder also sounds a trouble alert whenever the panel processor is reset using the RESET header or the processor

stops functioning.

INSTALLATION

1 Install the Sounder

Ground yourself before handling the panel. To discharge static, touch any grounded metal, such as the enclosure,

before touching the panel. Also remove all AC and Battery power from the panel before installing or connecting

any modules, cards, or wires to the panel.

Slide the connector on the sounder onto the panel 893A or 277 connector.

Figure 2: 277CAN Trouble Sounder to Panel Connections

893A or 277

Figure 1: 277CAN Trouble Sounder

Front and Rear Views

18205

Designed, engineered, and

manufactured in Springﬁeld, MO

using U.S. and global components.

LT-1304CAN 21393

INTRUSION • FIRE• ACCESS• NETWORKS

2500 North Partnership Boulevard

Springﬁeld, Missouri 65803-8877

800.641.4282 | DMP.com

© 2021

SPECIFICATIONS

Operating Voltage 12 VDC from the panel

Current Draw 16 mA

CERTIFICATIONS

▶ULC - S545 Household Fire

▶ULC - S559 Equipment for Fire Receiving Centres and Systems
