Dynojet Power commander III Bedienungsanleitung

2000 Ducati Monster 900 - PCIII - 1i703-211

2000 Ducati Monster 900

US Models Only

Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 (800) 992-4993 www.powercommander.com

Installation Instructions

Parts List

1 Power Commander

1 CD-ROM

1 Installation Guide

3 Zip Ties

2 Power Commander Decals

2 Dynojet Decals

1 Velcro®Strip

1 Alcohol Swab

You can also download the Power Commander software

and latest maps from our web site at:

www.powercommander.com

The ignition MUST be turned OFF before installation!

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

4 Plug male connector from PCIII

into ECU (Fig. B).

5 Plug female connector from

PCIII into male connector from

original harness (Fig. C).

6 Run PCIII cable under fuel tank

and along frame rail to the area

under the seat.

1 Remove the seat.

2 Lift fuel tank.

3 Unplug connector from ECU

(Fig. A).

Fig. AFig. B

Fig. C

2000 Ducati Monster 900 - PCIII - 2i703-211 www.powercommander.com

Stock Connector

ECU

7 Mount PCIII unit to rear most

area under seat using provided

self adhesive velcro (Fig. D).

Fig. D

2000 Ducati Monster 900 - PCIII - 3i703-211 www.powercommander.com

PCIII user’s guide.

Adjusting Your Power Commander

Your Power Commander has been programmed with a base

map for your application. You can adjust the base map or

install an alternate map using your computer. Please refer to

the supplied CD-Rom for more information.

You can also adjust your Power Commander using the face

plate buttons as described below.

NOTE: On some models, the injectors are powered down

shortly after turning the ignition on. To send a map, adjust the

throttle position or adjust the buttons you will need to use the

Power Adaptor (#66116001 or 76423001).

Plug the power adapter up to the Power Commander. Then

plug the 9 pin serial cable to the other side of the power

adapter (see figure).

The latest software and maps can be found at

www.powercommander.com

To adjust the buttons follow these steps:

1. Hold all three buttons down firmly.

2. While holding the buttons down connect the

battery to the power up adapter.

3. Release the buttons.

4. Select the range you wish to adjust: Low, Med,

High, by pushing the corresponding button

once.

5. At this point holding that button down will move

the lights down (leaning out the mixture).

6. Pushing the button repeatedly will move the light up (richening the mixture).

7. When the two center lights are lit up this is the “0” setting.

www.powercommander.com

PCIII User’s Guide

PCIII User’s Guide - A

Hold these buttons and start the bike

to adjust the Power Commander III

Trouble Shooting

If you feel that you are having any problems at all with the Power Commander III, disconnect it

from your motorcycle. This will allow the motorcycle to run directly off of the stock ECU.

The lights don’t come on when I turn the ignition switch on.

Check to make sure connectors are seated and the kill switch is in the “run” position.

The on-board adjustment buttons do not hold their settings.

Be sure to wait 20-30 seconds after making adjustments before starting or turning off the bike.

Can not upload to or download from the Power Commander III.

Check to see that the serial cable is firmly in place. Verify that ignition switch is on and the kill

switch is in the “run” position.

My mouse uses the same serial port.

If your computer has a PS/2 port purchase a DB9 to PS/2 adapter for your mouse.

I get a “verify failed....” message when I upload a map to the Power Commander III.

Programs running in the background or fluctuations in supply voltage (from outlet) can some-

times cause this error. In most cases, the information was sent properly to the Power

Commander III. Pushing the “upload all” button again should produce a “tables sent and veri-

fied” message.

I typed in notes, but they didn’t save.

You need to first push the “accept” button in the notes window and then the “save file” button.

www.powercommander.com

PCIII User’s Guide

PCIII User’s Guide - B
