Eaton 5SC 1500G Bedienungsanleitung

5SC 500G

5SC 500

5SC 750

5SC 1000

5SC 1500

User's guide

English - Français

Español - Português

5SC 750G

5SC 1500G

ENGLISH

5SC 500

5SC 750

5SC 1000

5SC 1500

5SC 500G

5SC 750G

5SC 1500G

Service and support:

Call your local service representative

Installation

619-00470-02 -us (en)

619-00470-02-us (en)

Page 2

619-00470-02-us (en) Page 3

ENGLISH

Special Symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol.

Important instructions that must always be followed.

Do not discard the UPS or the UPS batteries in the trash.

This product contains sealed lead acid batteries and must be disposed as it's explain in this manual.

For more information, contact your local recycling/reuse or hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE)

in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center.

Information, advice, help.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS. This manual contains important instructions

that should be followed during installation and maintenance of the UPS and batteries.

The 5SC models that are covered in this manual are intended for installation in an environment

within 0 to 35 °C / 32 to 95 °F, free of conductive contaminant.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment.This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

Certication Standards

• UPS directives: UL 1778 4th edition (UL listed).

• Performance: IEC 62040-3: 2001.

• Radiated emission: FCC CFR 47 part 15 subpart B, Class A, VCCI.

• Surges withstand ability: IEEE ANSI C62.41 Category A2 (UL Listed).

VCCI Notice

Page 4

Safety of Persons

• The system has its own power source (the battery). Consequently, the power outlets may be energized

even if the systems is disconnected from the AC power source.

• Dangerousvoltagelevelsarepresentwithinthesystem.Itshouldbeopenedexclusivelybyqualied

service personnel.

• The system must be properly grounded.

• The battery supplied with the system contains small amounts of toxic materials.

To avoid accidents, the directives listed below must be observed:

- servicing of batteries should be performed or supervised by personnel knowledgeable about betteries

and the required precautions.

- when replacing batteries, replace with the same type and number of batteries or battery packs.

-donotdisposeofbatteriesinare.Thebatteriesmayexplode.

- batteries constitute a danger (electrical shock, burns).The short-circuit current may be very high.

Precautions must be taken for all handling:

• Wear rubber gloves and boots.

• Do not lay tools or metal parts on top of batteries.

• Disconnect charging source prior to connecting or disconnecting battery terminals.

• Determine if battery is inadvertently grounded. If inadvertently grounded, remove source from ground.

Contact with any part of a grounded battery can result in electrical shock.The likelihood of such shock

can be reduced if such grounds are removed during installation and maintenance (applicable to

equipment and remote battery supplies not having a grounded supply circuit).

Product Safety

• The UPS connection instructions and operation described in the manual must be followed in

the indicated order.

• A protection circuit breaker must be installed upstream and be easily accessible.

The system can be disconnected from the AC power source by opening this circuit breaker.

• Check that the indications on the rating plate correspond to your AC powered system and to

the actual electrical consumption of all the equipment to be connected to the system.

• For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall

be easily accessible

• Never install the system near liquids or in an excessively damp environment.

• Never let a foreign body penetrate inside the system.

• Never block the ventilation grates of the system.

• Never expose the system to direct sunlight or source of heat.

• If the system must be stored prior to installation, storage must be in a dry place.

• The admissible storage temperature range is -15 to +40 ºC / 5 to 104 °F.

• The system is not for use in a computer room.

Special Precautions

• All handling operations will require at least two people (unpacking, installation in rack system).

• Before and after the installation, if the UPS remains de-energized for a long period, the UPS must be

energized for a period of 24 hours, at least once every 6 months (for a normal storage temperature

less than 25 °C / 77 °F).This charges the battery, thus avoiding possible irreversible damage.

• During the replacement of the Battery Module, it is imperative to use the same type and number of

element as the original Battery Module provided with the UPS to maintain an identical level of

performance and safety. In case of doubt, don’t hesitate to contact your EATON representative.

619-00470-02-us (en)

619-00470-02-us (en) Page 5

ENGLISH

Contents

1. Introduction....................................................................................... 6

1.1 Environmental protection...................................................................................................6

2. Presentation...................................................................................... 7

2.1 Standard installation ..........................................................................................................7

2.2 Rear panels........................................................................................................................7

2.3 Control panel .....................................................................................................................8

2.4 LCD description .................................................................................................................8

2.5 UPS setting through the LCD ............................................................................................9

3. Installation ...................................................................................... 10

3.1 Unpacking and contents check........................................................................................ 10

3.2 Battery module connection ............................................................................................. 10

3.3 Communication ports ..................................................................................................... 11

4. Operation......................................................................................... 12

4.1 Start-up and Normal operation......................................................................................... 12

4.2 Starting the UPS on Battery ............................................................................................ 12

4.3 UPS Shutdown ................................................................................................................ 12

4.4 Operation on Battery Power ............................................................................................ 12

4.5 Return of AC Input Power................................................................................................ 12

5. Maintenance ................................................................................... 13

5.1 Troubleshooting................................................................................................................ 13

5.2 Battery-module replacement ........................................................................................... 14

6. Appendices...................................................................................... 15

6.1 Technical specications.................................................................................................... 15

Page 6

1. Introduction

Thank you for selecting an EATON product to protect your electrical equipment.

The 5SC range has been designed with the utmost care.

We recommend that you take the time to read this manual to take full advantage of the many features

of your UPS (Uninterruptible Power System).

Before installing your 5SC, please read the booklet presenting the safety instructions.

Then follow the instructions in this manual.

To discover the entire range of EATON products and the options available for the 5SC range,

we invite you to visit our web site at www.eaton.com/powerquality or contact your EATON representative.

1.1 Environmental protection

EATON has implemented an environmental-protection policy.

Products are developed according to an eco-design approach.

Substances

This product does not contain CFCs, HCFCs or asbestos.

Packing

To improve waste treatment and facilitate recycling, separate the various packing components.

• The cardboard we use comprises over 50% of recycled cardboard.

• Sacks and bags are made of polyethylene.

• Packingmaterialsarerecyclableandbeartheappropriateidenticationsymbol 01

PET

Materials Abbreviations Number in

the symbols

Polyethylene terephthalat PET 01

High-density polyethylene HDPE 02

Polyvinyl chloride PVC 03

Low-density polyethylene LDPE 04

Polypropylene PP 05

Polystyrene PS 06

Follow all local regulations for the disposal of packing materials.

End of life

EATON will process products at the end of their service life in compliance with local regulations.

EATON works with companies in charge of collecting and eliminating our products at the end of

their service life.

Product

The product is made up of recyclable materials.

Dismantling and destruction must take place in compliance with all local regulations concerning waste.

At the end of its service life, the product must be transported to a processing center for electrical and

electronic waste.

Battery

The product contains lead-acid batteries that must be processed according to applicable local regulations

concerning batteries.

The battery may be removed to comply with regulations and in view of correct disposal.

PET

619-00470-02-us (en)

619-00470-02-us (en) Page 7

ENGLISH

2. Presentation

2.1 Standard installation

Description Weights

(lb/kg)

Dimensions (inch/mm)

D x W x H

5SC 500 15.0 / 6.8 9.4 x 5.9 x 8.3 / 240 x 150 x 210

5SC 750 23.6 / 10.7 13.4 x 5.9 x 8.3 / 340 x 150 x 210

5SC 1000 25.1 / 11. 4 13.4 x 5.9 x 8.3 / 340 x 150 x 210

5SC 1500 34.4 / 15.6 16.1 x 5.9 x 8.3 / 410 x 150 x 210

5SC 500G 14.6 / 6.6 9.4 x 5.9 x 8.3 / 240 x 150 x 210

5SC 750G 22.9 / 10.4 13.4 x 5.9 x 8.3 / 340 x 150 x 210

5SC 1500G 33.5 / 15.2 16.1 x 5.9 x 8.3 / 410 x 150 x 210

2.2 Rear panels

5SC 500 5SC 750

INPUT

OUTPUT

RS232 OR

Refer to the Bottom of

the unit for caution markings!

INPUT

OUTPUT

RS232 OR 5

Refer to the Bottom of

the unit for caution markings!

5SC 1000 5SC 1500

INPUT

OUTPUT

RS232 OR

Refer to the Bottom of

the unit for caution markings!

INPUT

OUTPUT

RS232 OR

Refer to the Bottom of

the unit for caution markings!

(1) USB communication port

(2) RS232 communication port

(3) Outlets for connection of critical equipment

(4) Attached 6 ft. input power cord for AC-power source

(5) Ground screw

Page 8

2. Presentation

2.2 Rear panels

5SC 500G 5SC 750G

INPUT

OUTPUT

Refer to the Bottom of

the unit for caution markings!

RS232 OR

INPUT

OUTPUT

Refer to the Bottom of

the unit for caution markings!

RS232 OR 5

5SC 1500G

INPUT

OUTPUT

Refer to the Bottom of

the unit for caution markings!

RS232 OR

(1) USB communication port

(2) RS232 communication port

(3) Outlets for connection of critical equipment

(4) Socket for connection to AC-power source

(5) Ground screw

2.3 Control panel

The UPS has a three-button LCD. It provides useful information about the UPS itself, load status, events,

measurements and settings.

AVR

Min

kVA

6ON/OFF button

7Scroll down

8Mute alarm

2.4 LCD description

912

9UPS ON

10 AVR mode

11 Battery mode

12 Internal fault

13 Output load level

14 Battery level

15 Input measurements

16 Output measurements

17 Measuring unit

619-00470-02-us (en)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Eaton UPS Handbücher

Eaton

Eaton Powerware 9125 Bedienungsanleitung

Eaton

Eaton 93E Handbuch

Eaton

Eaton Powerware 9390 IAC-B Bedienungsanleitung

Eaton

Eaton Powerware 9155 Bedienungsanleitung

Eaton

Eaton Powerware 9390 Bedienungsanleitung

Eaton

Eaton PowerRite XT PRXT-0400A Bedienungsanleitung

Eaton

Eaton Powerware 9390 Bedienungsanleitung

Eaton

Eaton 9PX 8000i RT6U HotSwap Netpack Bedienungsanleitung

Eaton

Eaton Ellipse PRO 850 Bedienungsanleitung

Eaton

Eaton 93PM IBC-L Konfigurationshandbuch

Eaton

Eaton Powerware 9395 550 kVA MBM Bedienungsanleitung

Eaton

Eaton SU700XLCD Bedienungsanleitung

Eaton

Eaton 93PR Series Bedienungsanleitung

Eaton

Eaton DIN500AC Installations- und Betriebsanleitung

Eaton

Eaton 93PM-50-1 Bedienungsanleitung

Eaton

Eaton 9390IT Bedienungsanleitung

Eaton

Eaton Ellipse PRO 650 Bedienungsanleitung

Eaton

Eaton 9PX1000IRTANZ-L Bedienungsanleitung

Eaton

Eaton 5E Gen2 Montageanleitung

Eaton

Eaton BladeUPS Series Bedienungsanleitung

Eaton

Eaton 1000H(XL) Bedienungsanleitung

Eaton

Eaton 9PXM Bedienungsanleitung

Eaton

Eaton Ellipse ECO 500 Montageanleitung

Eaton

Eaton Ellipse PRO 1600 FR Bedienungsanleitung

Beliebte UPS Handbücher anderer Marken

Pylontech

Pylontech Victron & Pylontech US5000 Bedienungsanleitung

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Bedienungsanleitung

Mecer

Mecer ME-1000-WTU Bedienungsanleitung

Mustek

Mustek PowerMust 530(B) Plus Installations- und Betriebshandbuch

Emerson

Emerson Liebert NXL series Bedienungsanleitung

MAKELSAN

MAKELSAN BOXER SERIES Bedienungsanleitung

Block

Block PC-0524-400-0 Bedienungsanleitung

CyberPower

CyberPower CP585LCD Bedienungsanleitung

CyberPower

CyberPower Office Tower Series UPS 1000 Bedienungsanleitung

CyberPower

CyberPower BM100 Bedienungsanleitung

Best Power

Best Power 610 Bedienungsanleitung

Best Power

Best Power Unity/I UT3K Bedienungsanleitung

Mustek

Mustek PowerMust 400 Offline Bedienungsanleitung

Xantrex

Xantrex Trace 512 UR-UPS Bedienungsanleitung

Forza

Forza SL-1501UL Bedienungsanleitung

LEGRAND

LEGRAND keor 310081 Bedienungsanleitung

ABB

ABB Conceptpower DPA 500 Bedienungsanleitung

ZincFive

ZincFive BC Series Bedienungsanleitung
