FeiYu Tech QING Bedienungsanleitung
Intelligent Gimbal for Camera
Instructions
EN V1.0
2
Catalogue
1. Overview ………………………………………………………… 2
2. Start to Use ……………………………………………………… 4
2.1 Charging……………………………………………………………………… 4
2.2 Unlock/Lock ………………………………………………………………… 5
2.3 Battery Installation ………………………………………………………… 5
2.4 Camera Installation and Balance ………………………………………… 6
2.5 Power On/O ……………………………………………………………… 8
3. Function & Operation …………………………………………… 9
3.1 Function/Modes Introduction …………………………………………… 9
3.2 Function Operation of Remote Control ………………………………… 12
3.3 Remote Control Touch Screen …………………………………………… 16
3.4 Modes Setting ……………………………………………………………… 17
3.5 Gimbal Initialization ………………………………………………………… 21
4. Accessories ……………………………………………………… 22
4.1 Brushless Follow Focus (AKF II) …………………………………………… 22
4.2 Wireless MIC Kit …………………………………………………………… 23
5. Specications …………………………………………………… 25
Compatible Cameras for Reference …………………………… 26
Disclaimer …………………………………………………………… 28
www.feiyu-tech.com 12
QING is a professional gimbal for DSLR/mirrorless camera. It is compatible with
popular DSLR camera on the market. It is available to install on the tripod or
other carrier to extend its shooting function.
It has a oversized touch screen on remote control, allows users to switch work
modes, control rotating direction and set up parameters on it directly and visibly.
Users can also control camera's follow focus and zooming after connecting
camera to QING via cable.
Suggestion
Feiyu Qing includes below information, please read
the information before using the gimbal:
1. Quick start guide
2. Online instruction
3. Tutorial
The tutorial videos can be watched at FeiyuTech ocial
website https://www.feiyu-tech.com/play/
or scan the QR code.
www.feiyu-tech.com 2
1. Overview
* The product is NOT included the camera.
www.feiyu-tech.com 32
www.feiyu-tech.com 4
2. Start to Use
TIPS
· Please install the camera and balance it before power on the gimbal.
· Please do not touch tilt motor and gears to avoid gripping.
· When the battery is low, please charge the battery.
· When not in use, power o the gimbal and then remove the batteries.
2.1 Charging
Please fully charge the dedicated battery before power on the gimbal
for the rst time.
Please choose the suitable charger when quickly charging.
2.1.1 Charging for the Gimbal
Using USB 2.0 to Type-C cable to charge the dedicated battery, support 5V/3A
input.
Battery Indicator: All the 3 indicators turn on when battery is full
Function Indicator:
quickly ashing: Low battery and please charge in time
slowly ashing: Pan mode
constant on: Lock mode
www.feiyu-tech.com 54
2.1.2 Charging for the Remote Control
Using USB 2.0 to Micro cable to charge the remote control, support 5V/3A input.
2.2 Unlock/Lock
There is a position lock on the tilt axis, which is convenient for locking the
position, installation, storage.
Unlock the gimbal before powering on it.
2.3 Battery Installation
Please fully charge the dedicated battery before power on the
gimbal for the rst time.
Install the battery: Push the battery in along the slot ①, and after that, the battery
lock ② will rebound to prevent battery from falling.
Remove the battery: Unlock the battery lock ② and pull the battery out.
www.feiyu-tech.com 6
①
②
2.4 Camera Installation and Balance
TIPS
· Make sure the battery and memory card are loaded before camera
installation.
· Before balancing the gimbal, the lens cover should be removed from
the camera and the memory card needs to be inserted to the camera to
complete all the cable connections to ensure that the camera is ready for
shooting.
· During balancing the gimbal, make sure the camera is power o and the
gimbal is turned o.
· If add accessories after the balance is completed, please re-balance.
In order to get ideal shooting, please balance the gimbal before using. And the
gimbal with perfect balance will have longer battery life.
Step 1: Keep the gimbal horizontal as the figure shows, then lock the position
lock ①.
www.feiyu-tech.com 76
Step 2: Mount camera on ARCA quick release plate ②, and tighten it.
Step 3: Install the ARCA quick release plate on the quick release plate, and tighten
the ARCA quick release plate safety lock ③. Install the lens holder ④ and tighten
the thumb screw ⑤ to hold the lens rmly.
Step 4: Unlock the position lock ①, and loose the thumb screw ⑥. Slide the
slide arm ⑦ to balance, and tighten the thumb screw ⑥ after the balancing is
completed.
If the camera can stay stable after moving your hand away, which means
balanced.
www.feiyu-tech.com 8
2.5 Power On/O
Please release the tilt motor lock before powering on.
Please do not touch tilt motor and gears to avoid gripping.
Steps:
(1) Gimbal:
Install the dedicated battery and long press the power button and release it when
the battery indicator and function indicator turn on together and hear the tone.
Long press again to power o.
(2) Remote Control:
Long press the power button, release it when the touch screen shows .
Long press again to power o.
