Flashforge Inventor Bedienungsanleitung

SZ14-ZN/EN-A06

P18

Inventor 发明家

This guide is only applicable to FLASHFORGE Inventor 3D printer

本指南仅适用于闪铸科技发明家3D打印机

1. Open the carton and take out lid on top of the

printer. On the lid, there is one quick start, one

after-sales service, one SD card, one leveling

card and two build tapes.

3. Lift the printer out of the carton.

5. Tear off tapes at the printer bottom, remove

bubble bag outside the printer.

6. Take out the foam on the top of the printer.

4. You will find a tool bag and one USB cable.

2. Take the power cable out. Remove two top foam

sheets.

01

10. Remove the foam from the back of the logo

board.

11. Hold both sides of the printer, lift up the printer

slowly, thus removing filament under build

plate easily. Do not make build plate collide

with extruder.

8. Remove bubble bag outside the extruder, put

extruder on the extruder mounting base.

Notice: The extruder should be put as is shown

(extruder fan should towards the front of the

printer)

7. Open the paper box on the top of the printer,

there is an extruder, two side panels and an

extruder's accessory kit inside. Take the

extruder and the paper box out, notice that

the cable bunch connected with extruder is

short, do not hang the extruder in the air.

02

9. Shear three ties off on both sides of X-axis guide rod.

12. Take out the paper board. 13. Take out filament first and then remove foam.

15. Finally press build plate slowly to printer

bottom.

14. Notice: Do not miss either filament spool

holder on two pieces of foam.

16. Inventor unboxing completed.

Suggest keeping packing materials well for

follow-up storage and shipping.

03

Tool Bag Contents:

Graver / Tweezer / Scraper / Accessories box

( contents: Thumb screw / PTFE tubes*2 /

M3x16 Bolt / Nut ) / Tool bag ( contents: Allen

wrenches*2 / Phillips screwdriver /

Unclogging pin tool / Wrench / Grease)

Extruder’s Accessory Kit Contents:

M3x8 Bolts*2 / M3x6 Bolts / Turbofan baffle

Tool Bag

04

05

Getting to know Your Inventor

5. Build Plate

19. USB Cable Input

8. Thumb Screw

06

bag

07

08

into

For putting filament through guide tube easily, please install filament in a proper way.

1. Take out PLA filament, remove vacuum packing and put it beside the left fixed seat of the build plate.

Install Filament

2. For putting PLA filament through guide tube

easily, please install filament in a proper way.

3. Put filament through guide tube.

Filament

Guide tube

09

Filament

Guide tube

Filament

Guide tube

Correct Wrong

Correct

Filament

Guide tube

Left side

Wrong

Filament

Guide tube

Right side
