Fujitsu PRIMERGY Econel 100 Bedienungsanleitung

PRIMERGY

PRIMERGY Econel 100

Server System

Operating Manual

Jesús López

cognitas. Gesellschaft für Technik-Dokumentation mbH cognitas PC

Alte Landstraße 6

81730 Munich

e-mail: e-mail:[email protected]

Tel.: (089) 61001-137

Fax: (++49) 700 / 372 00000

Econel 100

Sprachen: De

Edition November 2005

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

Econel 100 Operating Manual

Content

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview of the Documentation . . . . . . . . . . . . . . . . . . 5

1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 9

1.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2 Installation Steps: Overview . . . . . . . . . . . . . . . . . 13

3 Important Notes . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.2 CE Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . . 22

3.4 Transporting the Server . . . . . . . . . . . . . . . . . . . . . 23

3.5 Environment Protection . . . . . . . . . . . . . . . . . . . . . 23

4 Hardware Installation . . . . . . . . . . . . . . . . . . . . . 25

4.1 Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . 26

4.2 Unpacking the Server . . . . . . . . . . . . . . . . . . . . . . 26

4.3 Setting up the Server . . . . . . . . . . . . . . . . . . . . . . 27

4.4 Connecting Devices to the Rack Model . . . . . . . . . . . . . 28

4.5 Connecting the Server to the Line Voltage . . . . . . . . . . . 29

4.6 Instructions: Connecting/disconnecting wires . . . . . . . . . . 30

5 Preparation for Use and Operation . . . . . . . . . . . . . . 31

5.1 Operating and Indicator Elements . . . . . . . . . . . . . . . . 31

5.1.1 The Front Side . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5.1.2 The Rear Side . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5.2 Switching the Server ON and OFF . . . . . . . . . . . . . . . 34

5.3 Configuring the Server . . . . . . . . . . . . . . . . . . . . . 36

5.3.1 Configuring the SATA RAID Controller . . . . . . . . . . . . . 36

5.3.2 Configuration with ServerStart . . . . . . . . . . . . . . . . . 36

5.3.3 Configuration without ServerStart . . . . . . . . . . . . . . . . 37

5.4 Cleaning the Server . . . . . . . . . . . . . . . . . . . . . . . 37

6 Property and Data Protection . . . . . . . . . . . . . . . . . 39

6.1 Mechanical access protection . . . . . . . . . . . . . . . . . . 39

6.2 BIOS Setup Security Functions . . . . . . . . . . . . . . . . . 40

Operating Manual Econel 100

Content

7 Troubleshooting and Tips . . . . . . . . . . . . . . . . . . . 41

7.1 Power-On Indicator Remains Dark . . . . . . . . . . . . . . . 41

7.2 Screen Remains Blank . . . . . . . . . . . . . . . . . . . . . 42

7.3 Flickering Stripes on the Monitor Screen . . . . . . . . . . . . 43

7.4 No Screen Display or the Display Drifts . . . . . . . . . . . . . 43

7.5 No Mouse Pointer Displayed on Screen . . . . . . . . . . . . . 44

7.6 Floppy Disk Cannot be Read and/or Written . . . . . . . . . . 44

7.7 Incorrect Time and/or Date . . . . . . . . . . . . . . . . . . . 45

7.8 Drives Are Reported as “Dead” . . . . . . . . . . . . . . . . . 45

7.9 Added Drive Reported Defective . . . . . . . . . . . . . . . . 45

7.10 Error Messages on the Screen . . . . . . . . . . . . . . . . . 45

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Bibliography . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Econel 100 Operating Manual 5

1Introduction

The PRIMERGY Econel 100 server is an Intel-based server for workgroups and

small networks. The server is suitable for use as a file server and also as an

application, information or Internet server.

The PRIMERGY Econel 100 server offers a high level of reliability and avail-

ability through highly developed hardware and software components.

Security functions in the BIOS Setup and on the system board protect the data

on the server against manipulation. The supported RAID levels allow the hard

disk controllers to offer error tolerance, through data redundancy, for users who

want to provide complete protection for valuable data.

1.1 Overview of the Documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks CD.

The ServerBooks CD is part of the ServerStart Suite delivered with each

server system.

The PDF files for the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available in the Internet can be found via the URL: http://manuals.fujitsu-

siemens.com. The PRIMERGY server documentation can be accessed via

the industry standard servers navigation point.

Concept and target group of this manual

This operating manual describes how to install, how to set up and how to

operate your server.

This manual is intended for those responsible for installing the hardware and

ensuring that the system runs smoothly. The manual contains all the information

required for installing and operating your PRIMERGY Econel 100.

To understand the manual, you will need knowledge of hardware and data trans-

mission, as well as basic knowledge of the operating system used. You should

also have a good working knowledge of the English language.

6 Operating Manual Econel 100

Overview of the Documentation Introduction

Additional server documentation

To the PRIMERGY Econel 100 documentation set belong the following

additional manuals:

– “Quick Start Hardware - PRIMERGY Econel 100” (poster)

– “Quick Start Software - PRIMERGY ServerView Suite” (poster)

– “Warranty” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD)

– “Warranty” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD)

– “Ergonomics” manual (PDF file available on the ServerBooks CD)

– “Returning used devices” manual (PDF file available on the ServerBooks CD)

– “Help Desk” (supplement with worldwide help desk telephone numbers)

– Technical Manual for the system board D2179 (PDF file available on the

ServerBooks CD)

– “BIOS Setup” manual (PDF file available on the ServerBooks CD)

– “PRIMERGY Econel 100 Server System Options Guide” (PDF file available

on the ServerBooks CD)

IIn the “Options Guide”, the server extension and modification possi-

bilities are described.

– The “ServerView Suite” contains the ServerStart CD, the ServerBooks CD and

the ServerSupport CDs. The PDF version of the “PRIMERGY ServerView

Suite - ServerStart” user manual is also available on the ServerBooks CD.

– “LSI SATA Software RAID User’s Guide” (PDF file available on

theServerBooks CD)

IIf you need a backup of the ServerBooksCD send the details of your server

via email address:

Reklamat-PC-LO[email protected]

Further sources of information:

– manual for the monitor

– manual for ServerView server management

– documentation for the boards and drives

– operating system documentation

– information files of your operating system

(see also “Bibliography” on page 55).

Econel 100 Operating Manual 7

Introduction Features

1.2 Features

System board

The features of the system board can be found in the technical manual of the

system board D2179 for the hardware and in the BIOS Setup for the firmware

(see “Bibliography” on page 55).

Hard disk drives

Up to four SATA hard disk drives, each with a maximum height of 1 inch, are built

into the drive rack. There is a wire connection to the controller.

Onboard SATA RAID controller

A SATA RAID controller is integrated on the system board; up to four SATA hard

disk drives can be connected to the controller. RAID levels 0, 1 and 10 are

supported for each LSI SATA software RAID.

IThe controller has its own configuration utility. More detailed information

may be found in the “LSI SATA Software RAID User’s Guide” manual (on

the ServerBooks CD under “Controller”).

Accessible drives

The first (top) bay contains the server's DVD drive. The fourth (bottom) bay can

be used for a 3.5" disk drive (1.44 Mbyte).

The two middle 5.25" bays are available for additional usable drives (CD/DVD

drives or a magnetic tape drive).

The accessible drives cannot be replaced during operation.

Power supply

The server has a built-in power supply unit, which automatically sets itself to a

mains voltage in the range of 100 V - 240 V.

High level of availability and reliability

When memory data is accessed, 1-bit errors in the main memory are recog-

nized and automatically corrected with the ECC (Error Correcting Code)

method.

8 Operating Manual Econel 100

Features Introduction

Server management

Server management is implemented with the aid of the supplied ServerView

software and PDA (Prefailure Detection and Analyzing) technology from Fujitsu

Siemens. PDA reports the threat of a system error or overloading early on so

that preventative measures can be taken.

ServerView enables the management of all PRIMERGY servers in the network

via a central console. Here ServerView supports the following functions:

●Remote power-on (Wake On LAN)

●Intrusion detection

●Temperature monitoring of the CPU and the surrounding area

●Power monitoring

●Fan monitoring

●Watchdog timer for monitoring the operating system and applications

Further information on ServerView server management is provided in the

associated documentation (see “Bibliography” on page 55).

ServerStart

You can configure the PRIMERGY server quickly and purposefully with the

ServerStart software provided. User-guided menus are available for installing the

server operating system.

Service and Support

PRIMERGY servers are service-friendly and modular, thus enabling quick and

simple maintenance. The flash EPROM program supplied with the Fujitsu

Siemens Computers utilities supports a fast BIOS update.

Econel 100 Operating Manual 9

Introduction Notational conventions

1.3 Notational conventions

The following notational conventions are used in this manual:

text in italics indicate commands, menu items or software programs.

“Quotation marks” indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown

VCAUTION! Pay particular attention to texts marked with this

symbol. Failure to observe this warning may endanger

your life, destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips

Table 1: notational conventions

10 Operating Manual Econel 100

Technical data Introduction

1.4 Technical data

Electrical data (standard and redundant power supply)

National and international standards

Rated voltage range 100 V - 240 V

Frequency 50 Hz - 60 Hz

Rated current in basic configuration 100 V - 240 V / 1.5 A - 0.6 A

Max. rated current: 100 V - 240 V / 7.5 A - 3.5 A

Effective power 216 W

Apparent power 227 VA

Heat dissipation 778 kJ/h (737 btu/h)

Main power fuse 16 A

Protection class I

Product safety and ergonomics IEC 60950 / EN 60950 / UL 60950,

CSA 22,2 No. 60950

Electromagnetic Compatibility FCC class A

VCCI class A

AS/NZS 3548 class A

CNS 13438

Interference emission EN 55022

Harmonic current EN 6100-3-2 JEIDA

flicker EN 61000-3-3

Interference immunity EN 55024

CE label according to EU directives Low-Voltage Directive 73/23/EEC

Electromagnetic Compatibility

89/336/EEC (Product safety)

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu PRIMERGY CX400 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY MX130 S2 Upgrade and maintenance... Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX620 S6 Bedienungsanleitung

Fujitsu

Fujitsu SPARC M10-1 Bedienungsanleitung

Fujitsu

Fujitsu Primergy TX300 S4 Leitfaden

Fujitsu

Fujitsu PRIMERGY TX100 S2 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX300 S2 Leitfaden

Fujitsu

Fujitsu PRIMERGY SX980 S1 Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY Econel 200 S2 Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY BX900 Benutzerhandbuch

Fujitsu

Fujitsu PRIMEQUEST 2800B3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY GX2570 M6 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX400 S1 Bedienungsanleitung

Fujitsu

Fujitsu BS2000/OSD Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX4770 M4 Bedienungsanleitung

Fujitsu

Fujitsu 2737 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX300 S4 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M4000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX100 S7 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
