PRIMERGY

PRIMERGY H250

Server System

Günter Benkelberg

Fujitsu Siemens Computers GmbH cognitas PS

85521 Ottobrunn

e-mail: e-mail:[email protected]

Tel.: (0?5251) 8?14?-891

Fax: 0 700 / 372 00001

U41271-J-Z156-2-76

Sprachen: De

Edition September 2002

This manual is printed on

paper treated with

chlorine-free bleach.

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

Introduction

Important Notes

Insta ation

Preparation for use and operation

Opening and C osing the Server

Property and Data Protection

Prob em So utions and Tips

System Components and Expansions

SCSI Configurations

Re ated Pub ications and Index

U41271-J-Z156-2-76

Contents

1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 Notational Conventions . . . . . . . . . . . . . . . . . . . . . . 4

1.3 Target Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Notes on Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 CE Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.3 FCC Class A Compliance Statement . . . . . . . . . . . . . . 12

2.4 Notes on Installing into the Rack . . . . . . . . . . . . . . . . 14

2.5 Transporting the Server . . . . . . . . . . . . . . . . . . . . . 14

2.6 Environmental Protection . . . . . . . . . . . . . . . . . . . . 15

3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.1 Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . 17

3.2 Unpacking the Server . . . . . . . . . . . . . . . . . . . . . . 18

3.3 Setting Up the Floorstand Model . . . . . . . . . . . . . . . . 19

3.3.1 Mounting the Doors . . . . . . . . . . . . . . . . . . . . . . . 20

3.4 Installing the Rack Model in the Rack . . . . . . . . . . . . . . 21

3.4.1 Requirements of the Rack . . . . . . . . . . . . . . . . . . . . 21

3.4.2 Mounting in the PRIMECENTER Rack . . . . . . . . . . . . . 24

3.4.3 Mounting in the DataCenter Rack . . . . . . . . . . . . . . . . 27

3.4.4 Mounting in the Classic Rack . . . . . . . . . . . . . . . . . . 31

3.4.5 Mounting in 3rd-Party Racks . . . . . . . . . . . . . . . . . . . 36

3.5 Installing the Server . . . . . . . . . . . . . . . . . . . . . . . 38

3.6 Connecting Devices to the Server . . . . . . . . . . . . . . . . 40

3.6.1 Leads Routing . . . . . . . . . . . . . . . . . . . . . . . . . . 42

3.7 Connecting the Server to the Mains . . . . . . . . . . . . . . . 43

3.8 Instructions on Connecting and Disconnecting Cables . . . . . 44

4 Preparation for use and operation . . . . . . . . . . . . . . 45

4.1 Unlocking the Floorstand Model . . . . . . . . . . . . . . . . . 45

4.2 The Control Panel . . . . . . . . . . . . . . . . . . . . . . . . 46

4.2.1 Operating Elements . . . . . . . . . . . . . . . . . . . . . . . 47

4.2.2 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4.2.3 Indicators Hot-Plug PCI . . . . . . . . . . . . . . . . . . . . . 49

4.2.4 Indicators on the Drives . . . . . . . . . . . . . . . . . . . . . 50

4.2.5 System Display . . . . . . . . . . . . . . . . . . . . . . . . . 51

4.3 Switching the Server ON/OFF . . . . . . . . . . . . . . . . . . 53

4.4 Configuring the Server . . . . . . . . . . . . . . . . . . . . . . 54

U41271-J-Z156-2-76

Contents

4.4.1 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 54

4.4.2 Configuration without ServerStart . . . . . . . . . . . . . . . . 54

4.4.3 Installing the Operating System . . . . . . . . . . . . . . . . . . 55

4.5 Cleaning the Server . . . . . . . . . . . . . . . . . . . . . . . . 55

5 Opening and Closing the Server . . . . . . . . . . . . . . . . 57

5.1 Removing/Mounting the Doors . . . . . . . . . . . . . . . . . . 57

5.2 Removing/Mounting the Top Cover . . . . . . . . . . . . . . . . 58

5.3 Mounting/Removing the Side Cover . . . . . . . . . . . . . . . 59

6 Property and Data Protection . . . . . . . . . . . . . . . . . . 61

6.1 BIOS Setup Security Functions . . . . . . . . . . . . . . . . . . 61

7 Problem Solutions and Tips . . . . . . . . . . . . . . . . . . 63

7.1 Power-on Indicator Remains Dark . . . . . . . . . . . . . . . . 63

7.2 The Server Switches itself OFF . . . . . . . . . . . . . . . . . . 64

7.3 The Monitor Remains Dark . . . . . . . . . . . . . . . . . . . . 64

7.4 Flickering Stripes Across the Monitor . . . . . . . . . . . . . . . 65

7.5 No Monitor Display or Display Drifts . . . . . . . . . . . . . . . 65

7.6 No Mouse Pointer Displayed on the Monitor . . . . . . . . . . . 66

7.7 The Floppy Disk cannot be Read or Written . . . . . . . . . . . 66

7.8 Time and/or Date are Incorrect . . . . . . . . . . . . . . . . . . 66

7.9 System Fails to Boot . . . . . . . . . . . . . . . . . . . . . . . 67

7.10 Drives “dead” at System Boot . . . . . . . . . . . . . . . . . . 67

7.11 Added Drive Defective . . . . . . . . . . . . . . . . . . . . . . 67

7.12 Error Messages on the Monitor . . . . . . . . . . . . . . . . . . 68

7.13 Error Messages on the Control Panel . . . . . . . . . . . . . . . 68

8 System Components and Expansions . . . . . . . . . . . . . 71

8.1 The HDD Subsystem . . . . . . . . . . . . . . . . . . . . . . . 71

8.1.1 Handling Hard Disk Drives/HDD Modules . . . . . . . . . . . . 72

8.1.2 Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.1.3 Replacement of the HDD Module During Operation . . . . . . . 75

8.1.4 Installing/removing a hard disk drive module . . . . . . . . . . . 76

8.2 chipDISK for RemoteView . . . . . . . . . . . . . . . . . . . . 78

8.3 Accessible Drives . . . . . . . . . . . . . . . . . . . . . . . . . 78

8.4 Power Supply Units . . . . . . . . . . . . . . . . . . . . . . . . 78

8.4.1 Removing/Installing Power Supply Unit . . . . . . . . . . . . . . 79

8.5 Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

8.5.1 Replace the Fan Module . . . . . . . . . . . . . . . . . . . . . 80

9 SCSI Configurations . . . . . . . . . . . . . . . . . . . . . . . 83

9.1 Addresses for SCSI Devices . . . . . . . . . . . . . . . . . . . 83

9.2 Internal SCSI Configurations . . . . . . . . . . . . . . . . . . . 84

U41271-J-Z156-2-76

Contents

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

U41271-J-Z156-2-76 1

1 Introduction

The PRIMERGY H250 server is an Intel-based server for mid-size and large

companies. The server is suitable for use as a file server as well as an appli-

cation, information, or internet server. It can be used as a floorstand model as

well as a rack model. The floorstand model can be converted to a rack model

with an optionally available conversion kit.

The H250 server offers a high level of reliability and availability through highly

developed hardware and software components. These include hot-swappable

hard disk drive modules, hot-plug fans, hot-plug power supply units, the

ServerView server management software, Prefailure Detection and Analysing

(PDA) and Automatic Server Reconfiguration and Restart (ASR&R). In addition,

the remote service functionality is made available by the onboard service

processor.

Security functions in the BIOS Setup and on the system board protect the data

on the server against manipulation. The door of the floorstand model can be

monitored centrally. As a rack model, the lockable front door of the rack offers

additional security.

This operating manual tells you how to put your server into operation, how to

operate it in daily use, and how to expand your server.

IWork steps which are the same for the floorstand and rack models are

described only for the floorstand model.

Further information is provided:

– in the “Safety, Warranty and Ergonomics” manual

– in the technical manual for the system board

– in the manual for the BIOS Setup

– in the technical manual for the 19-inch rack

– in the manual for the monitor

– in the manual for the ServerView server management

– in the manual for the Remote Test and Diagnostic System RemoteView

– in the documentation for the boards and drives

– in your operating system documentation

– in the information files of your operating system

(see also section “Related publications” on page 85).

2 U41271-J-Z156-2-76

Features Introduction

1.1 Features

System Board

The features of the system board can be found in the technical manual of the

system board for the hardware and in the BIOS Setup for the firmware (see

“Related publications” on page 85).

The HDD Subsystem

SCSI hard disk drives are exclusively installed in the H250 servers. The HDD

subsystem can accommodate up to 12 hard disk drive modules and up to two

SCSI backplanes.

Each hard disk drive module can accommodate a SCSI hard disk drive with an

SCA (Single Connector Attachment) interface and a maximum height of 1 inch.

The module is connected to the SCSI backplane without cables via the SCA

interface. This allows hard disk drives to be simply plugged in or pulled out.

The HDD subsystem is designed for Ultra-3-SCSI. The hard disk drives can be

controlled by the onboard controller (default) or by a RAID controller. If the

server is equipped with a RAID controller, defective hard disk drives can also be

replaced during operation (hot swap). For details, please see section

“Replacement of the HDD Module During Operation” on page 75.

Accessible Drives

The H250 is equipped with a floppy disk drive and a CD-ROM/DVD drive. Two

additionally drives (e. g. tape drives for saving data) can be installed (optional).

For details, please see section “Accessible Drives” on page 78.

Power Supply

Only in its basic configuration level the server has a fixed power supply unit.

Corresponding to the system configuration a second or a third hot plug power

supply unit can be added to achieve redundant power supply. In a redundant

configuration, if one power supply unit fails, the other power supply units

ensures unimpaired continued operation. The defective power supply unit can

be replaced during operation (hot-plug power supply units).

Andere Handbücher für primergy h250

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu Primergy TX120 Leitfaden

Fujitsu

Fujitsu PRIMERGY CX270 S1 Bedienungsanleitung

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Montageanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX400 S1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Bedienungs- und Wartungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 3800E Bedienungsanleitung

Fujitsu

Fujitsu Primepower200 Bedienungsanleitung

Fujitsu

Fujitsu GP 7000F Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX600 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX300 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S7 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Service-Handbuch

Fujitsu

Fujitsu BS2000/OSD Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2520 M5 Bedienungsanleitung

Fujitsu

Fujitsu M10 Series Service-Handbuch

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M6 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M1 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Installationsanleitung

Fujitsu

Fujitsu BX630 - PRIMERGY - S2 Dual Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY TX150 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX220 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Fujitsu primergy h250 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken
