PRIMERGY RX600 S3 SAS

Operating manual

Edition December 2006

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

RX600 S3 SAS Operating manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . 7

1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 15

1.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 16

2 Overview of installation steps . . . . . . . . . . . . . . . . 19

3 Important information . . . . . . . . . . . . . . . . . . . . . 21

3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 29

3.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 30

3.5 Notes on installing in the rack . . . . . . . . . . . . . . . . 31

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 32

4 Hardware installation . . . . . . . . . . . . . . . . . . . . . 35

4.1 Installation steps . . . . . . . . . . . . . . . . . . . . . . . . 36

4.2 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 36

4.3 Installing the server in the rack/removing the server from the

rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4.3.1 Installing the server in the PRIMECENTER Rack . . . . . . . . 41

4.3.2 Mounting in the DataCenter Rack . . . . . . . . . . . . . . . . 43

4.3.3 Installation in 3rd party racks . . . . . . . . . . . . . . . . . . 43

4.3.4 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 43

4.4 Connecting devices to the server . . . . . . . . . . . . . . . 46

4.5 Connecting the server to the mains . . . . . . . . . . . . . 48

4.6 Connecting the monitor . . . . . . . . . . . . . . . . . . . . 49

Operating manual RX600 S3 SAS

Contents

4.7 Notes on connecting/disconnecting cables . . . . . . . . . 50

5 Startup and operation . . . . . . . . . . . . . . . . . . . . . 51

5.1 Controls and displays . . . . . . . . . . . . . . . . . . . . . 51

5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 51

5.1.1.1 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

5.1.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 53

5.1.1.3 Indicators on the accessible drives/components . . . . . . 55

5.1.1.4 Indicators on the hard disk drives . . . . . . . . . . . . . . 58

5.1.1.5 Indicator on the hot-plug fan units . . . . . . . . . . . . . . 59

5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . 60

5.1.2.1 LAN indicators on the connection panel . . . . . . . . . . . 60

5.1.2.2 ID indicator and ID button . . . . . . . . . . . . . . . . . . 61

5.1.2.3 Indicators on the hot pluggable power supply units . . . . . 62

5.2 Switching the server on and off . . . . . . . . . . . . . . . . 63

5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 65

5.3.1 Configuring the PCI SAS RAID Controller . . . . . . . . . . . 65

5.3.2 Configuration with ServerStart . . . . . . . . . . . . . . . . . 66

5.3.3 Configuration without ServerStart . . . . . . . . . . . . . . . . 67

5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . 68

6 Property and data protection . . . . . . . . . . . . . . . . . 69

6.1 Mechanical Access Protection . . . . . . . . . . . . . . . . 69

6.2 BIOS Setup security functions . . . . . . . . . . . . . . . . 69

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . 71

7.1 Power on indicator remains unlit . . . . . . . . . . . . . . . 71

7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . 72

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . 72

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 73

7.5 No screen display or display drifts . . . . . . . . . . . . . . 73

7.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 74

7.7 Drives reported as “dead” when starting system . . . . . . 74

RX600 S3 SAS Operating manual

Contents

7.8 Added drive reported as defective . . . . . . . . . . . . . . 74

7.9 Error messages on screen . . . . . . . . . . . . . . . . . . 75

7.10 Error messages on the control panel (LocalView) . . . . . . 75

8 Hot plug components . . . . . . . . . . . . . . . . . . . . . 77

8.1 Replacing hot-plug power supply units . . . . . . . . . . . 77

8.2 Replacing hot-plug fan units . . . . . . . . . . . . . . . . . 79

8.3 Hot-plug hard disk drives . . . . . . . . . . . . . . . . . . . 80

8.3.1 Handling HDD modules . . . . . . . . . . . . . . . . . . . . . 81

8.3.2 Installing/removing HDD/dummy unit . . . . . . . . . . . . . . 82

8.4 Hot-plug memory boards . . . . . . . . . . . . . . . . . . . 86

8.4.1 Removing a hot-plug memory board . . . . . . . . . . . . . . 87

8.4.2 Removing the dummy unit . . . . . . . . . . . . . . . . . . . . 88

8.4.3 Installing a hot-plug memory board . . . . . . . . . . . . . . . 89

8.5 Hot-plug PCI boards . . . . . . . . . . . . . . . . . . . . . . 90

8.5.1 Removing hot-plug PCI boards . . . . . . . . . . . . . . . . . 92

8.5.2 Removing the dummy unit . . . . . . . . . . . . . . . . . . . . 96

8.5.3 Installing hot-plug PCI boards . . . . . . . . . . . . . . . . . . 98

8.6 Opening/closing the housing . . . . . . . . . . . . . . . . . 100

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

RX600 S3 SAS Operating manual 7

1Introduction

The PRIMERGY RX600 S3 SAS server is an Intel-based server for mid-size

and large companies. It is suitable for use both as a file server, and as an appli-

cation, information, or Internet server. It is used as a rack model.

Thanks to its highly developed hardware and software components, the server

offers a high level of data security and availability. These include hot-plug hard

disk drive modules, hot-plug system fans and power supply units, hot-plug PCI

slots, hot-plug memory boards, the server management software ServerView,

Prefailure Detection and Analyzing (PDA), and Automatic Server Reconfigu-

ration and Restart (ASR&R).

Security functions in the BIOS setup and on the system board protect the data on

the server against manipulation. Additional security is provided by the rack's

lockable door.

The server occupies 4 height units (HU) in the rack.

1.1 Documentation overview

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD. The ServerBooks DVD is part of the ServerStart Suite supplied with

every server.The PDF files of the manuals can also be downloaded free

of charge from the Internet.

The overview page showing the online documentation available on the

Internet can be found using the URL: http://manuals.fujitsu-siemens.com.

The PRIMERGY server documentation can be accessed using the

Industry standard servers navigation option.

8 Operating manual RX600 S3 SAS

Documentation overview Introduction

Concept and target group for this manual

This operating manual describes how to install, set up and operate your server.

This manual is intended for those people responsible for installing the hardware

and ensuring that the system runs smoothly. It contains all of the information

required to install and operate your system.

Knowledge of hardware and data transmission, as well as basic knowledge of

the operating system used, is necessary to understand fully the various

expansion options. You should also have a good working knowledge of the

English language.

Additional server documentation

The PRIMERGY RX600 S3 SAS documentation also includes:

– “Quick Start Hardware - PRIMERGY RX600 S3 SAS” (leaflet)

– “Quick Start Software - PRIMERGY ServerView Suite” (leaflet)

– “Warranty” manual (print version supplied with the system, PDF file available

on the ServerBooks DVD supplied)

– “Safety notes and other important information” manual (print version

supplied with the system, PDF file available on the ServerBooks DVD

supplied)

– “Ergonomics” manual (PDF file available on the ServerBooks DVD supplied)

– “Returning used devices” manual (PDF file available on the ServerBooks DVD

supplied)

– “Helpdesk” (leaflet with worldwide helpdesk telephone numbers)

– Technical Manual for the D2630 system board (PDF file available on the

ServerBooks DVD supplied)

– “BIOS Setup” (PDF file available on the ServerBooks DVD supplied)

– “PRIMERGY RX600 S3 SAS Server Options Guide” (PDF file available on

the ServerBooks DVD)

IThe “Options Guide” describes the server expansion and modifi-

cation options.

– “ServerView Suite” includes the ServerStart Disc 1, the ServerStart Disc 2

and the ServerBooks DVD. The PDF version of the “PRIMERGY ServerView

Suite - ServerStart” user manual is also available on the ServerBooks DVD.

IIf you need a replacement copy of the ServerBooks DVD, send the

details of your sever to the following e-mail address:

[email protected]

RX600 S3 SAS Operating manual 9

Introduction Documentation overview

– “MegaRAID 320 Storage Adapters” (PDF file available on the ServerBooks

DVD)

– “MegaRAID Device Driver Installation” (PDF file available on the ServerBooks

DVD)

– “MegaRAID Configuration Software” (PDF file available on the ServerBooks

DVD)

– “ServerView RAID 2.0 User Manual” (PDF file available on the ServerBooks

DVD)

Further sources of information:

– Technical Manual for the relevant rack

– Manual for the monitor

– Manual on ServerView Server Management

– Manual for the remote testing and diagnostic system RemoteView

– Documentation for boards and drives

– Documentation for your operating system

– Information files on your operating system

(See also “Literature” on page 109.)

10 Operating manual RX600 S3 SAS

Features Introduction

1.2 Features

System board

The features of the system board are described in the technical manual for the

system board D2630 for the hardware and in the “BIOS Setup” for the firmware

(see “Literature” on page 109).

Hot-plug PCI slots

In addition to two standard PCI slots, the server also has five hot-plug PCI slots.

Of these five hot-plug PCI slots, one is already contains the PCI SAS RAID

Controller and is not available, one is available for a PCI-X board, and three are

available for PCI Express boards. These hot-plug PCI slots allow you to install

and remove boards while the server is online, provided that the operating

system supports this functionality (for more details, see section “Hot-plug PCI

boards” on page 90).

Hard disk drives

The server has a drive slot on the front, in which up to eight SAS hard disk drive

modules can be inserted. Each hard disk drive (HDD) module can accept an

SAS hard disk drive with a maximum height of 1 inch. The module is connected

to the SAS backplane without cables. This allows you to simply plug in or pull

out the HDD modules (for more details, see section “Hot-plug hard disk drives”

on page 80).

The hard disk subsystem is designed for SAS, with one channel for each hard

disk drive.

If the server has a corresponding RAID configuration, faulty HDD modules can

also be replaced while the server is online (hot-plug).

An external SCSI interface is also offered optionally to allow external storage

subsystems to be connected. You will find further information in the Options

Guide (see “Literature” on page 109).
