Grizzly H8232 Bedienungsanleitung

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TS9957 PRINTED IN CHINA

MODEL H8232

3-PIECE FRAMING/FINISH/PALM

NAILER KIT

OWNER'S MANUAL



































 

 

 











Model H8232 3-Piece Framing/Finish/Palm Nailer Kit -1-

Safety Instructions for Pneumatic Tools

1. KEEP ALL SAFETY DEVICES IN

PLACE and in working order.

2. REMOVE ADJUSTING KEYS AND

WRENCHES. Form habit of checking

to see that keys and adjusting

wrenches are removed from tool

before operation.

3. KEEP WORK AREA CLEAN.

Cluttered areas and benches invite

accidents.

4. DO NOT USE IN DANGEROUS

ENVIRONMENT. Do not use

pneumatic tools in damp or wet

locations, or where any flammable

or noxious fumes may exist. Keep

work area well lighted.

5. KEEP CHILDREN AND VISITORS

AWAY. All children and visitors

should be kept at a safe distance

from work area.

6. MAKE WORKSHOP CHILD PROOF

by locking your shop and shutting off

air valves.

7. DO NOT FORCE TOOL. It will do

the job better and safer at the rate for

which it was designed.

8. USE THE RIGHT TOOL. Do not

force tool or attachment to do a job

for which it was not designed.

9. DO NOT USE UNDER THE

INFLUENCE OF DRUGS OR

ALCOHOL.

For Your Own Safety Read Instruction Manual

Before Operating This Equipment

The purpose of safety symbols is to attract your attention to possible hazardous

conditions. This manual uses a series of symbols and signal words which

are intended to convey the level of importance of the safety messages. The

progression of symbols is described below. Remember that safety messages by

themselves do not eliminate danger and are not a substitute for proper accident

prevention measures.

Indicates a potentially hazardous situation which, if

not avoided, MAY result in minor or moderate injury.

It may also be used to alert against unsafe practices.

Indicates a potentially hazardous situation which, if

not avoided, COULD result in death or serious injury.

Indicates an imminently hazardous situation which,

if not avoided, WILL result in death or serious injury.

This symbol is used to alert the user to useful

information about proper operation of the equipment.

SAFETY

NOTICE

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit

-2-

10. USE PROPER AIR HOSE for

the tool. Make sure your air hose

is in good condition and is long

enough to reach your work without

stretching.

11. WEAR PROPER APPAREL. Do

not wear loose clothing, gloves,

neckties, rings, bracelets, or other

jewelry which may get caught in

moving parts. Non-slip footwear is

recommended. Wear a protective

hair covering to contain long hair.

12. ALWAYS USE SAFETY

GLASSES. Also use a face or

dust mask if cutting operation is

dusty. Everyday eyeglasses only

have impact resistant lenses, they

are NOT safety glasses.

13. WEAR APPROVED HEARING

PROTECTION. Air escaping from

pneumatic tools can exceed safe

exposure limits and may cause

hearing damage with prolonged

exposure.

14. SECURE WORK. Use clamps or a

vise to hold work when practical. It

is safer than using your hand and

frees both hands to operate tool.

15. MAINTAIN TOOLS WITH CARE.

Keep tools lubricated and clean

for best and safest performance.

Follow instructions for lubricating

and changing accessories.

16. REDUCE THE RISK OF

UNINTENTIONAL FIRING. Do not

carry tool with hand on trigger and

always disconnect from air when

not in use.

17. DISCONNECT TOOLS before

servicing, changing accessories, or

moving to another location.

18. DO NOT OVERREACH. Keep

proper footing/balance at all times.

19. USE THE RECOMMENDED

ACCESSORIES. Consult owner’s

manual for recommended

accessories. The use of improper

accessories may cause risk of

injury.

20. CHECK FOR DAMAGED PARTS

BEFORE USING. Check for binding

and alignment of parts, broken

parts, part mounting, loose bolts,

and any other conditions that may

affect machine operation. Repair or

replace damaged parts.

21. NEVER LEAVE UNATTENDED

TOOL CONNECTED TO AIR.

Disconnect the air hose and do not

leave tool until it is relieved of any

built up pressure.

22. NEVER ALLOW UNTRAINED

USERS TO USE THIS TOOL

WHILE UNSUPERVISED.

23. IF YOU ARE UNSURE OF THE

INTENDED OPERATION, STOP

USING TOOL. Seek formal training

or research books or magazines

that specialize in pneumatic tools.

24. BE AWARE OF HOSE LOCATION

WHEN USING PNEUMATIC

TOOLS. Hoses can easily become a

tripping hazard when laid across the

floor or spread out in a disorganized

fashion.

Safety Instructions for Pneumatic Tools

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit -3-

Additional Safety Instructions for Nailers

1. HAND INJURIES: Do not place your

hands near the nail point of entry. A

nail can deflect and tear through the

surface of the workpiece, puncturing

your hand or fingers.

2. COMBUSTIBLE GASES: Never con-

nect the nailer to pressurized oxygen

or other combustible gases as an air

source. Only use filtered, lubricated,

and regulated compressed air.

3. SAFE HANDLING: Never point the

nailer at others! Do not keep the trig-

ger pulled when loading fasteners,

carrying, or holding tool. Carry the

nailer only by the handle, never by

any other part. Do not carry the nailer

by the air hose. Disconnect the nailer

from the air hose when going up and

down ladders.

4. MODIFICATIONS: DO NOT modify

this tool or bypass the safety nose

mechanism.

5. CHECK VALVE: Do not use a check

valve or any other fitting that allows

air to remain in the tool.

6. HOSE USAGE: Make sure your air

hose is designed for the tool in use, is

in good condition, and is long enough

to reach your work without stretching.

However, an overly long air hose in

the work area may be a tripping haz-

ard.

7. OPERATING QUESTIONS: If you

are not sure about the intended oper-

ation, stop using the nailer. Seek

formal training.

8. CLEANING: Never use gasoline or

other flammable liquids to clean the

nailer; vapors in the nailer will ignite

by a spark and cause it to explode.

9. MAINTENANCE: Always disconnect

air from the nailer when servicing or

installing nails. During maintenance,

a nailer connected to air may fire acci-

dentally, causing serious personal

injury.

10. COMPRESSED AIR RATING: Do

not connect the nailer to compressed

air that exceeds 120 PSI.

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit

-4-

Operating these nailers can propel

objects into the air, causing imme-

diate eye damage. To protect your-

self, always wear American National

Standards Institute (ANSI) approved

safety glasses or goggles when

operating this equipment. In addi-

tion, these nailers discharge at up

to 85-90 decibels. To protect your

hearing, always wear ANSI approved

ear protection when operating these

nailers.

Never point these nailers at yourself

or another person! Always pay atten-

tion to the direction these nailers are

pointed. Use these tools with respect

and caution to lessen the possibil-

ity of operator or bystander injury.

Ignoring this warning may result in

serious personal injury.

Nailer accidents routinely happen

while moving the gun to another

location, such as up ladders, to

another room, or even another job

site. Always disconnect the gun

immediately after use and never

transport the gun while connected

to the air—even if the air compres-

sor is disconnected from its power

source!

No list of safety guidelines can be

complete. Every shop environment

is different. Always consider safe-

ty first, as it applies to your indi-

vidual working conditions. Use this

and other tools with caution and

respect. Failure to do so could result

in serious personal injury, damage to

equipment or poor work results.

Read the manual before operation.

Become familiar with these nailers,

their safety instructions, and their

operation before beginning any work.

Serious personal injury may result if

safety or operational information is

not understood or followed.

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit -5-

INTRODUCTION

Foreword Tool Data

Framing Nailer

Nail Size ...................... 1⁄8" Shank Diameter

Nail Strip Angle .................34º Round Head

Nail Length ......................................2"–3½"

Magazine Capacity ........................ 60 Nails

Air Inlet Fitting ................................¼" NPT

Weight .............................................81⁄2 lbs.

Operating Air Pressure ............ 80–110 PSI

Maximum Air Pressure .................. 120 PSI

Finish Nailer

Nail Size ..................................... 16 Gauge

Nail Length ...................................11⁄4"–21⁄2"

Magazine Capacity ........................ 74 Nails

Air Inlet Fitting ................................1⁄4" NPT

Weight ................................................5 lbs.

Operating Air Pressure ............ 60–100 PSI

Maximum Air Pressure .................. 120 PSI

Palm Nailer

Nail Size ......................................... 5d–70d

Blows Per Minute ............................... 1000

Average Air Consumption ............... 5 CFM

Air Inlet Fitting ................................1⁄4" NPT

Weight .............................................1.9 lbs.

Operating Air Pressure ............ 70–100 PSI

Maximum Air Pressure .................. 120 PSI

The specifications, details, and photo-

graphs in this manual represent the Model

H8232 as supplied when the manual was

prepared. However, owing to Grizzly’s pol-

icy of continuous improvement, changes

may be made at any time with no obliga-

tion on the part of Grizzly.

If you have any comments regarding this

manual, please write to us at the following

address:

Grizzly Industrial, Inc.

C/O Technical Documentation

P.O. Box 2069

Bellingham, WA 98227-2069

E-Mail: manuals@grizzly.com

Most importantly, we stand behind our

tools. If you have any service questions or

parts requests, please call or write us at

the location listed below.

Grizzly Industrial, Inc.

1203 Lycoming Mall Circle

Muncy, PA 17756

Phone: (570) 546-9663

Fax: (800) 438-5901

E-Mail: techsupport@grizzly.com

Web Site: http://www.grizzly.com

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit

-6-

SET UP

Inventory

After you open the nailer case, you should

find the following.

Model H8232 Inventory (Figure 1) Qty

A. 16 Gauge Finish Nailer ...................... 1

B. Palm Nailer ........................................ 1

C. 34° Framing Nailer ............................. 1

D. Hex Wrenches 3, 4, 5, 6mm ..... 1 Each

E. Safety Goggles .................................. 1

F. Carrying Case .................................... 1

G. Leather Palm Nailer Pouch ................ 1

H. Tool Oil Bottle .................................... 1

Your new nailer kit was carefully pack-

aged for safe shipping. If you discover any

damage after you have signed for deliv-

ery, immediately call Customer Service at

(570) 546-9663 for advice.

Save the containers and all packing mate-

rials for possible inspection by the car-

rier or its agent. Otherwise, filing a freight

claim can be difficult.

When you are completely satisfied with

the condition of the shipment, you should

inventory the contents.

Unpacking

Figure 1. Model H8232 inventory.

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit -7-

The Model H8232 is designed to be oper-

ated at the following air pressures using

clean, dry, regulated, compressed air:

Nailer Operating Air Pressure

Framing ................................... 80–110 PSI

Finish ....................................... 60–100 PSI

Palm ........................................ 70–100 PSI

DO NOT exceed the 120 PSI maximum

operating pressure for your nailer.

Before using your new nailers, regulate the

air pressure to find the optimum setting

within the specified operating range. Start

by testing the nailer at a low setting, then

increase the air pressure as needed for

satisfactory results.

An in-line filter/lubricator/regulator unit can

be installed, as depicted in Figure 2.

This filter/lubricator/regulator unit will

protect your tool from damaging water

build-up, allow you to adjust and maintain

constant air pressure to your tool, and

save you the inconvenience of having to

manually lubricate your tool every time

you use it.

Compressed Air

System

Check the current Grizzly catalog for avail-

ability of this unit. If you plan on install-

ing a filter/lubricator/regulator unit in your

compressed air system, always follow the

connection instructions that come with

the unit.

Exceeding the maximum permissible

operating pressure may damage the

nailers and cause them to malfunc-

tion. To protect yourself from per-

sonal injury, DO NOT allow the air

pressure to exceed the recommended

pressure for these nailers!

Quick

Connector

Quick

Coupler

Air Hose Quick

Coupler

Quick

Connector

Lubricator

Filter

Regulator

Air

Compressor

Your

Tool

Figure 2. Typical filter/lubricator/regulator installation order.

Model H8232 3-Piece Framing/Finish/Palm Nailer Kit

-8-

A safety mechanism on the nose of the

framing/finish nailer protects against acci-

dental firing. When the trigger is pressed,

the nailer will not fire until the safety nose

mechanism is depressed.

Before you use your nailers for the first

time, perform these safety checks to

ensure the safety nose mechanisms are

operating properly.

Safety Check #1

1. DISCONNECT NAILER FROM THE

AIR SUPPLY!

2. Make sure the magazine is empty and

contains no nails.

3. Make sure the trigger and the safety

nose mechanism move up and down

without sticking.

4. Connect the nailer to the air supply.

5. Without pressing the trigger, depress

the safety nose mechanism against a

scrap piece of wood that is clean and

free of any knots, nails, or other foreign

objects.

— If the nailer does not fire, then the

safety nose mechanism is working

correctly. Proceed to Safety Check

#2.

— If the nailer does fire when you

do this, immediately disconnect the

nailer from the air supply and call

Grizzly Technical Support at (570)

546-9663 for help.

Framing/Finish

Nailer Safety Nose

Mechanism

Note: If you find that the safety nose

mechanism is not moving up and

down properly, check the lubrication

of its sliding components.

Safety Check #2

1. Lift the nailer from the scrap piece of

wood so that the safety nose is not

depressed, point the nailer down and

away from yourself and others, then

pull the trigger.

— If the nailer does not fire when the

trigger is pulled without the safety

nose mechanism being depressed,

then the nailer is working properly.

— If the nailer does fire when you

do this, immediately disconnect the

nailer from the air supply and call

Grizzly Technical Support at (570)

546-9663 for help.

The safety mechanism is a mechanical

device that can fail. Never rely on this

mechanism as an excuse to point the

framing/finish nailer at yourself or any

bystanders. Serious injury may occur.

DO NOT attempt to modify or bypass

the safety nose mechanism to make

the framing/finish nailer fire without

pushing the safety nose down.

Inhaltsverzeichnis

Andere Grizzly Nagelpistole Handbücher

Grizzly

Grizzly T20644 Bedienungsanleitung

Grizzly

Grizzly G6048 Bedienungsanleitung

Grizzly

Grizzly H2910 Bedienungsanleitung

Grizzly

Grizzly H2911 Bedienungsanleitung

Grizzly

Grizzly H2912 Bedienungsanleitung

Grizzly

Grizzly G1847 Bedienungsanleitung

Grizzly

Grizzly H7665 Betriebsanleitung

Grizzly

Grizzly H6144 Bedienungsanleitung

Grizzly

Grizzly H2911 Bedienungsanleitung

Grizzly

Grizzly G6048 Bedienungsanleitung

Grizzly

Grizzly G2413 Bedienungsanleitung

Grizzly

Grizzly G3690 Bedienungsanleitung

Grizzly

Grizzly 1 1/4" Brad Nailer T20568 Bedienungsanleitung

Grizzly

Grizzly H5570 Bedienungsanleitung

Grizzly

Grizzly G6050 Bedienungsanleitung

Grizzly

Grizzly H7826 Bedienungsanleitung

Grizzly

Grizzly G6050 Bedienungsanleitung

Grizzly

Grizzly H6146 Bedienungsanleitung

Grizzly

Grizzly H5527 Bedienungsanleitung

Grizzly

Grizzly H6146 Kurzanleitung

Grizzly

Grizzly G2420 Bedienungsanleitung

Grizzly

Grizzly H7945 Bedienungsanleitung

Grizzly

Grizzly H7665 Bedienungsanleitung

Grizzly

Grizzly G6049 Bedienungsanleitung

Beliebte Nagelpistole Handbücher anderer Marken

Performance Tool

Performance Tool M643 Bedienungsanleitung

Hitachi

Hitachi VH650 - Fencing Nailer, Full Head Bedienungsanleitung

Parkside

Parkside PET 25 B1 Bedienungsanleitung

Senco

Senco Fusion Technology F-35XP Bedienungsanleitung

Ryobi

Ryobi R18N18G Bedienungsanleitung

Black & Decker

Black & Decker 492848-00 Bedienungsanleitung

HOLZMANN MASCHINEN

HOLZMANN MASCHINEN TN90 Bedienungsanleitung

Metabo HPT

Metabo HPT NR 3690DC Bedienungsanleitung

Surtek

Surtek CN650 Abmessungen und Installationsanleitung

Makita

Makita GF600 Bedienungsanleitung

Parkside

Parkside PET 25 B1 Bedienungsanleitung

Senco

Senco AirFree 25 Bedienungsanleitung

Freeman

Freeman P50LSLW Bedienungsanleitung

Aicon PRO

Aicon PRO DAC4507 Bedienungsanleitung

DAJ

DAJ XR150A Bedienungsanleitung

Makita

Makita AN923 Bedienungsanleitung

Black & Decker

Black & Decker 90514937 Bedienungsanleitung

Alfamacchine

Alfamacchine Minigraf 4 Handbuch
