Hikvision Technical Manual

DS-7200HFI-ST/SN Series DVR

Technical Manual

Hikvision Technical Manual

Notices

The information in this documentation is subject to change without notice and does

not represent any commitment on behalf of HIKVISION. HIKVISION disclaims any

liability whatsoever for incorrect data that may appear in this documentation. The

product(s) described in this documentation are furnished subject to a license and

may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for

the purposes for which it is supplied. It may not be reproduced in whole or in

part, in any form, or by any means or be used for any other purpose without prior

written consent of HIKVISION and then only on the condition that this notice is

included in any such reproduction. No information as to the contents or subject

matter of this documentation, or any part thereof, or arising directly or indirectly

therefrom, shall be given orally or in writing or shall be communicated in any

manner whatsoever to any third party being an individual, firm, or company or any

employee thereof without the prior written consent of HIKVISION. Use of this

product is subject to acceptance of the HIKVISION agreement required to use this

product. HIKVISION reserves the right to make changes to its products as

circumstances may warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

overseasbusiness@hikvision.com

Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual

Overview

Developed on the basis of the latest technologies, DS-7200HFI-ST/SN Series Digital

Video Recorder combines with the advanced H.264 video encoding and decoding

standard and maintains high performance rock-solid reliability and longer recording

service time.

DS-7200HFI-ST/SN Digital Video Recorder can be used as a standalone video

surveillance product, as well as to build up a powerful surveillance network which is

suitable for home or small-scale business applications.

DS-7204HFI-ST/SN, DS-7208HFI-ST/SN

DS-7216HFI-ST/SN

Hikvision Technical Manual

Main Features

User-friendly GUI for easy operation

1280 × 1024 /1024 × 768 VGA output resolution

Simultaneous VGA and CVBS output

4CIF/2CIF/CIF resolution

Normal and event recording parameters configurable per

individual camera

Partial digital zoom by using mouse when in PTZ control mode

4/8 /16-ch synchronous playback

Support dual stream

Different recording storage period configurable for each channel

Sending of alarm images by Email

NTP, SADP, DHCP protocols supported

Hikvision Technical Manual

Functions & Performances

Compression

PAL/NTSC adaptive video inputs.

H.264 video compression with high reliability and superior definition.

G.711 audio compression standard.

Independent video encoding parameters, including frame rate,

resolution, bit rate, video quality, etc.

Scheduled and event recording parameters configurable for per

individual camera.

Support dual stream.

Encoding for both audio/video composite stream and video stream;

audio and video synchronization during composite stream encoding.

Compression, storage and network transmission of video image at

4CIF/2CIF/CIF resolution.

Watermark technology.

Local Monitoring

Up to 1280×1024 resolution for VGA output display.

Simultaneous VGA and CVBS output.

1/4/9/16-camera video live view, with the camera order adjustable.

Group switch, manual switch and automatic cycle modes selectable for

video live view, with the auto cycle period configurable.

Digital zoom in live view mode.

Shield of assigned channel for live view.

Privacy masking capability.

Multiple PTZ protocols supported, and settings and callup of presets,

patrols and patterns.

Video image zoom-in by clicking the mouse and tracing by dragging

mouse in PTZ control mode.

Hard Disk Management

Connection to 1 SATA hard disk for DS-7204HFI-ST/SN and

DS-7208HFI-ST/SN models and 2 SATA hard disks for

DS-7216HFI-ST/SN; each HDD with up to 2TB storage capacity.

S.M.A.R.T technology.

HDD standby function.

HDD file system is compatible with Windows. Use pre-allocating hard

disk management technology, and no disk fragments.

Recording

Cycle and non-cycle recording mode.

Hikvision Technical Manual

Normal and event video encoding parameters.

Multiple recording types, including manual, normal, motion detection,

etc.

8 recording time periods with separate recording types.

Pre-record and post-record time for motion detection, and pre-record

time for schedule and manual recording.

Lock and unlock of video files.

HDD property can be set to read-only.

Video data search and playback by channel number, recording type,

time etc.

Digital zoom function in playback mode.

Pause, play fast, play slow, skip forward, and skip backward when

playback, locating in progress bar by dragging the mouse.

4/8/16-channel synchronous playback.

Backup

Record files backed up via USB device.

Bunch backup by file or by time.

Record files edited for backup in playback.

Management and maintenance for backup devices.

Alarm & Exception

Various exception alarm types supported: alarms for video loss, motion

detection, video tempering, video signal abnormal, video in/out format

unmatched, illegal access, network disconnection, IP conflict, hard disk

error and hard disk full.

Various exception handling methods: pop-up alarm image on monitor,

audible warning, notify surveillance center, send Email, etc.

Auto recovery from exceptions.

Others

Control of DVR via mouse and IR remote control.

Three-level user management, each user with individual operating

permission for DVR and camera.

Powerful record and search for log of operation, alarm and exceptions.

Import/export of device configuration files.

Network

10/100M adaptive network interface.

TCP/IP protocol suites, PPPoE, DHCP, DNS, DDNS, NTP, SADP protocols,

etc.

Unicast and multicast supported; TCP and UDP protocols applicable in

unicast transmission.

Hikvision Technical Manual

Remote search, playback and download, lock/unlock of video files;

support breakpoint resume.

Remote access and configuration of parameters; remote import/export

of device configuration parameters.

Remote access of device running status, alarm and system log.

Remote formatting of hard disk, upgrade, reboot/shutdown and other

system maintenance operations.

RS-485 half-duplex transparent channel transmission.

Exceptions upload to remote management host.

Remote manual recording.

Remote video image capture in JPEG format.

Voice talk and broadcast.

Built-in WEB Server.

Development

Provision of SDK in Windows and Linux operating systems.

Application software source code of Demo.

Support and training service for application system development.

Hikvision Technical Manual

Rear Panel & Interfaces

Rear Panel of DS-7200HFI-ST/SN

①USB Interface

②VIDEO OUT

③VIDEO IN

④AUDIO IN

⑤AUDIO OUT

⑥VGA Interface

⑦LAN

⑧RS-485 Interface

⑨12VDC Power Supply Interface

⑩Alarm input and output

⑪POWER

⑫GND

Hikvision Technical Manual

Specifications

Model

DS-7204HFI-ST/SN

DS-7208HFI-ST/SN

DS-7216HFI-ST/SN

Video/Audio

input

Video

compression

H.264

Analog video

input

4-ch

8-ch

16-ch

Video input

interface

BNC connector (1.0 Vp-p, 75 Ω); PAL / NTSC adaptive

Audio

compression

G.711

Audio input

1-ch, RCA connector (2.0 Vp-p, 1 kΩ)

Voice talk

input

1-ch, RCA (2.0 Vp-p, 1 kΩ)

(Using AUDIO IN)

VGA output

1-ch, resolution: 1280 × 1024 / 60 Hz, 1024 × 768 / 60 Hz

CVBS output

1-ch, BNC connector (1.0 Vp-p, 75 Ω); Resolution: PAL: 704 × 576,

NTSC: 704 × 480

Audio output

1-ch, RCA connector (Linear, 1 kΩ)

Video/Audio

output

Recording

resolution

4CIF / 2CIF / CIF

Frame rate

25 fps (P) / 30 fps (N)

Video bit

rate

32 kbps ~ 2048 kbps, or user-defined (Max. 3072 kbps)

Stream type

Video/ Video & Audio

Audio bit

rate

64 kbps

Dual stream

Support (sub stream at CIF: 6fps, QCIF: 25 fps (P) / 30 fps (N))

Synchronous

playback

4-ch

8-ch

16-ch

Hard disk

Type

1 SATA interface

2 SATA interfaces

Capacity

Up to 2TB capacity for each interface

External

interface

Network

interface

1, RJ45 10 M / 100 M adaptive Ethernet interface

Serial

interface

1 RS-485 half-duplex interface

USB

interface

2, USB 2.0

Alarm in

Alarm out

Others

Power

supply

12 VDC

Consumption

≤10 W

(without hard disk or

DVD-R/W)

≤10 W

(without hard disk or

DVD-R/W)

≤15 W

(without hard disk or

DVD-R/W)

Working

temperature

-10 ºC ~ +55 ºC

Working

humidity

10% ~ 90%

Chassis

Stand-alone 1U

chassis

Stand-alone 1U

chassis

19-inch rack-mounted

1U chassis

Dimensions

(W x D x H)

315 × 230 × 45 mm

445 × 290 × 45 mm

Weight

≤2 kg (without hard

disk or DVD-R/W)

≤2 kg (without hard

disk or DVD-R/W)

≤4 kg (without hard

disk or DVD-R/W)
