Ikan PT4100 Bedienungsanleitung

PT4100

20” Teleprompter QUICKSTART GUIDE

What’s included

www.ikancorp.com 713-272-8822

Checked by

�

24 x PhillipsHead Screw

�

24 x T-Slot Nut

�

4 x 1/4-20 Mounting Screw

�

ELE-DBLPT

�

Quick Release Plate

�

2 x Mounting Bracket

(One for monitor mount and one

for optional pro battery mount)

�

Hood

�

PrompterPro Software

�

Prompter Glass Frame

�

Camera Lift

�

15” Monitor & AC Power Adapter

�

24” T-Slot Bar

�

4 x M4 X 8mm

Mounting Screw

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach six Phillips Head screws and six T-Slot nuts to Double Cheese Plate, ELE-DBLPT.

Slide the Double Cheese Plate, ELE-DBLPT onto T-Slot bar.

** Tiny hole side facing front.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach your own tripod skid plate.

Attach Mounting Bracket onto the monitor with four 4mm Mounting Screw.

.ikancorp.com

713-272-8822

Then, attach four Phillips Head screws and four T-Slot nuts.

** Note: Heavy Duty tripod only.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Slide the Monitor onto the T-Slot Bar.

Attach four Phillips Head screws and four T-Slot nuts on the Prompter Glass Frame.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Slide the Prompter Glass Frame onto the T-Slot Bar.

Slide the Prompter Glass Frame upon the monitor.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach four Phillips Head screws and four T-Slot nuts on the Camera Lift.

Slide the Camera Lift onto the T-Slot Bar.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach the Quick Release Plate onto the Camera Lift with four 1/4-20 Mounting Screws.

Slide the Camera Lift upon the Prompter Glass Frame.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach velcro on three sides of the Prompter Glass Frame.

Attach the Hood.

PT4100

20” Teleprompter QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Attach tripod plate to your camera.

Slide your camera onto the Camera Lift. Adjust the Camera Lift’s height that fits your camera.

PT4100

20” Teleprompter QUICKSTART GUIDE

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (** Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
