PROAIM TP-ULTM-01 Bedienungsanleitung

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Ultra Modular Teleprompter (TP-ULTM-01)

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Collapsible hood Beam Splier Glass

Quick Release

I -Pad Plaorm

Vesa Mount

Upper Spacer

Hood Spacer

Adjustable Arms

4 x Knobs

2x Cleaning Cloth

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Female Mounng rods

4 x bush

Spacer

Hand Gloves

Side Flaps

Male Mounng rods

Belt

L-type (Size:7/32mm)

T-type (Size:4mm)

Bag Packing

Glass protecve Case

• Remove the plate from tripod.

Ultra Modular Teleprompter Setup

• Aach universal base plate to the Quick release and

secure it with the help of screw driver.

• Here is the quick release ready to be mount

on tripod.

• Slide quick release while Press the buon to

mount it on tripod and loose all four cornered

knobs of quick release.

• Now add Female mounng rods to the quick

release plate.

• Now mount Hood Spacer on the rods then

secure it by use screw allen key.

• Here is hood spacre aached

• Loose the knobs of I-pad plaorm

• Now latch the I-pad plaorm to the hood

spacer.

• Now secure it by ghten the knobs back

again.

• Loose both the knobs which is in the boom

of I-pad plaorm.

• Extend the I-pad holder the ght knob to

secure it.

• Now mount spacer to the other end of rods

then secure it by using screw and allen key.

• Here is the spacer aached.

• Now aach male mounng rods on hood

spacer.

• Here is male mounng rods aached.

• Open collapsible hood .

• Now past it on Velcro tape to provide the

collapsible hood a shape.

• Loose both the knobs which is on the back of

hood.

• Close tha buckles and ght it.

• Now mount Upper spacer on male rods and

ght the knobs then add screw on rods.

• Lose the middle knob of quick release and

remove camera plate while pressing buon.

• The hood would look like this aer pasng all

Velcro tape.

• Insert male rods into it and close the knobs

back again.

• Cover the camera lens with the provide hood

and Tight it.

• Open Velcro from the front of collapsible

hood pull out metal frame.

• Now slide metal frame on glass then insert it

in collapsible hood.

• Now secure it with velcro.

• Aach camera plate to camera and secure it by

using screw driver.

• Mount camera on quick release by sliding and

close knob.

• Mount vesa mount on the back side of screen

(Not included) and secure it by adding screws

with allen key.

• Aach the screen (Not included) to

adjustable arm and secure it with knob.

• Past side aps on collapsible hood.

• Remove knob and place adjustable arm on

I-pad plaorm.

• Now secure the arm by aaching knob back

again.

YOUR PROAIM ULTRA MODULAR TELEPROMPTER

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
