Before using your new product, please read these instructions to prevent any damage.

4.4 Cu. Ft. Glass Door

Compact Refrigerator

NS-CF44GD3/NS-CF44GD3-C

USER GUIDE

www.insigniaproducts.com

Contents

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Refrigerator parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Before installing your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Reversing the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Adjusting the shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Adjusting the door racks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Removing the crisper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Cleaning the interior of your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Defrosting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Shutting down your refrigerator - long vacations (several months) . . . . . . .17

Moving your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Tips on storing food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

4.4 Cu. Ft. Glass Door Compact Refrigerator

www.insigniaproducts.com

IMPORTANT SAFETY

INSTRUCTIONS

WARNING: To reduce the risk of fire, explosion, electric shock, or injury when

using your refrigerator, follow these basic safety precautions:

1Read all instructions before using the refrigerator.

2WARNING--Risk or child entrapment. Never allow children to operate, play

with, or crawl inside the refrigerator.

3WARNING--Never clean the refrigerator parts with flammable fluids. The

fumes can create a fire hazard or explosion.

4WARNING--Do not store or use gasoline or any inflammable liquids inside or

in the vicinity of the refrigerator.

5WARNING--Keep ventilation openings in the appliance or in the built-in

structure clear of obstruction.

6WARNING--Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the manufacturer.

7WARNING--Do not damage the refrigerant circuit.

8WARNING--Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type recommended by

the manufacturer.

9WARNING--Do not place heavy objects on top of this refrigerator to avoid

injury from falling objects when the door is opened or closed.

10 WARNING--DANGER: Never allow children to play with, operate, or crawl

inside the refrigerator. Risk of child entrapment. Before you throw away your

old refrigerator:

• Take off the door

• Leave the shelves in place so that children may not easily climb inside.

11 This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.This refrigerator must be properly installed and located in

accordance with the Installation Instructions before it is used.

12 If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent, or a similar qualified person in order to avoid creating a hazard.

13 Please dispose of the refrigerator according to local regulations as the unit

contains flammable gas and refrigerant.

14 Follow local regulations regarding disposal of the appliance due to flammable

refrigerant and gas. All refrigeration products contain refrigerants, which

under the guidelines of federal law must be removed before disposal. It is the

consumer’s responsibility to comply with federal and local regulations when

disposing of this product.

4www.insigniaproducts.com

15 Do not use an extension cord or ungrounded, two-prong adapters with this

appliance. If the power cord is too short, have a qualified electrician install an

outlet near the appliance. Use of an extension cord can negatively affect the

unit’s performance.

16 Firmly grasp the plug and pull it out of the outlet to disconnect this appliance.

Do not pull on the cord.

17 Use a dedicated power outlet for this appliance and plug it in securely.

18 WARNING: In order to avoid electric shock, lamp replacement shall be done

by the manufacturer's designated service agency or qualified personnel.

Before doing any maintenance on this appliance, unplug the power cord and

wear personal protection. Please refer to the maintenance instructions for

details.

19 WARNING: Connect to a potable water supply only (for the ice maker).

20 WARNING: When positioning the appliance, make sure that the power cord is

not trapped or damaged.

21 WARNING: Do not locate multiple portable sockets, outlets, or portable

power supplies in back of the appliance.

22 WARNING: To avoid a hazard due to the instability, this appliance must be

secured in accordance with the instructions.

Additional safety instructions

• Disconnect the refrigerator from the main power supply at the rear of the unit,

remove the refrigerator circuit fuse, or turn off the circuit breaker before

making repairs or cleaning. Wait five minutes before reconnecting to prevent

damages to the compressor due to multiple, successive starts.

•NOTE: Power to the refrigerator cannot be disconnected by any setting on the

control panel.

•NOTE: Repairs must be performed by a qualified Service Professional.

• Replace all parts and panels before operating.

• Do not store explosive substances such as aerosol cans with a flammable

propellant in this appliance.

• To avoid serious injury or death, children should not stand on, or play in or

with the appliance.

• If doors or lids are fitted with locks, the keys must be kept out of the reach of

children and not in the vicinity of the appliance, in order to prevent children

from being locked inside.

• This appliance is intended to be used in household and similar applications,

such as staff kitchen areas in shops, offices, and other working environments.

In farm houses, and by clients in hotels, motels, bed & breakfasts, and other

residential environments, and catering and similar non-retail applications.

• Do not apply harsh cleaners to the refrigerator. Certain cleaners will damage

plastic which may cause parts such as the door or door handles to detach

unexpectedly. See Maintaining your refrigerator on page 16 for detailed

instructions.

4.4 Cu. Ft. Glass Door Compact Refrigerator

www.insigniaproducts.com

READ ALL INSTRUCTIONS BEFORE

USING

PROPER DISPOSAL OF YOUR OLD REFRIGERATOR

Grounding requirement

Your refrigerator must be grounded. Your refrigerator is equipped with a cord

having a grounding wire with a grounding plug. The plug must be inserted into an

outlet that is correctly installed and grounded.

Incorrect use of the grounding plug can result in a risk of electric shock. Consult a

qualified electrician or service person if the grounding instructions are not

completely understood, or if doubt exists as to whether your refrigerator is

correctly grounded. See Providing a proper power supply on page 9.

CAUTION: To reduce the risk of injury when using your refrigerator, follow these basic

safety precautions.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and

covers may break if exposed to sudden temperature changes or impact, such as bumping or

dropping. Tempered glass is designed to shatter into many small pieces if it breaks.

• Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are

necessarily small. Be careful closing the door when children are in the area.

WARNING-DANGER - RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT

USED.

• To be repaired only by trained service personnel. Do not puncture

refrigerant tubing.

• Consult repair manual/owner's guide before attempting to service this

product.

• All safety precautions must be followed.

• Dispose of property in accordance with the applicable federal or local regulations.

• Follow handling instructions carefully.

WARNING: SUFFOCATION AND ENTRAPMENT HAZARD

Failure to follow these disposal instructions can result in death or serious injury.

IMPORTANT: Child entrapment and suffocation are not problems of the past. Junked or

abandoned refrigerators are still dangerous even if they will sit for “just a few days.” If you are

getting rid of your old refrigerator, please follow the instructions below to help prevent

accidents.

Before You Throw Away Your Old Appliance

• Take off the door and remove the door seal.

• Leave the shelves in place so that children may not easily climb inside.

Refrigerant and Foam Disposal:

Dispose of refrigerator in accordance with Federal and Local Regulations. Flammable insulation

material used requires special disposal procedures. Contact your local authorities for the

environmentally safe disposal of your refrigerator.

6www.insigniaproducts.com

Features

• 4.4 cu ft (.1 cu m) storage capacity is ideal for dorm rooms, offices, and garages

• 3 adjustable glass shelves offer custom storage options

• Freestanding design, reversible door, and leveling feet provide flexible

placement options

• A range of 32° - 50° F (0° - 10° C) and a dial let you adjust your desired

temperature

• Interior lighting makes it easy to find the food you’re looking for

• Low-noise compressor emits less than 40 dB, maintaining a quiet atmosphere

• Manual defrost lets you remove excess frost buildup and maintain even

airflow

• Silver graphite covered with a glass finish adds a stylish look

Package contents

• 4.4 Cu. Ft. Glass Door Compact Refrigerator

• User Guide

Dimensions

33 13/16 in. (86 cm)

19 1/2 in. (49.5 cm)

20 15/16 in. (53.1

4.4 Cu. Ft. Glass Door Compact Refrigerator

www.insigniaproducts.com

Refrigerator parts

Installing your refrigerator

Before installing your refrigerator

• Remove the exterior and interior packing.

• Clean the interior surface with lukewarm water/baking soda solution (two

tablespoons in a quart of water) using a soft cloth, then wipe down with a

dry cloth.

CAUTION: Let your refrigerator stand upright for approximately four hours before connecting it

to power. This reduces the possibility of a malfunction in the cooling system from incorrect

handling during transportation.

Shelf

Temperature

control and

interior light Bottle

retainer

Crisper

Leveling foot

Pocket racks

Crisper cover

Shelf

Bottle

retainer

8www.insigniaproducts.com

Finding a suitable location

• Place your refrigerator on a floor that’s strong enough to support your

refrigerator when it is fully loaded.

• Allow at least 7 15/16 in. (20.1 cm) of space between the sides of your

refrigerator and any surrounding walls, and allow at least 3 15/16 in. (10 cm)

between the back of your refrigerator and the wall. Allow at least 11 13/16 in.

(30 cm) between the top of your refrigerator and any cabinet. This allows for

the correct air ventilation.

• Do not install your refrigerator on carpeting or a rug.

• Do not install your refrigerator in a garage or other outside location.

• Locate your refrigerator away from direct sunlight and sources of heat (stove,

heater, radiator, and so on). Direct sunlight may affect the acrylic coating and

heat sources may increase electrical consumption. Ambient temperature

below 50° F (10° C) or above 109° F (43° C) hinders the performance of your

refrigerator.

• Avoid locating your refrigerator in moist areas.

CAUTION: Your refrigerator is not designed for a recessed installation.

7 15/16 in.

(20.1 cm)

7 15/16 in.

(20.1 cm)

11 13/16 in. (30 cm)

3 15/16 in.

(10 cm)

4.4 Cu. Ft. Glass Door Compact Refrigerator

www.insigniaproducts.com

Providing a proper power supply

Check your local power source. This refrigerator requires a 110 V-120 V, 60 Hz

power supply.

This refrigerator should be properly grounded for your safety. The power cord of

this refrigerator is equipped with a three-prong plug which plugs into a standard

three-prong wall outlet to minimize the possibility of electrical shock.

• Do not, under any circumstances, cut or remove the third ground prong from

the power cord supplied.

• This refrigerator is not designed to be used with an inverter.

• The cord should be secured behind the refrigerator, and not left exposed or

dangling, to prevent accidental injury.

• Never unplug the refrigerator by pulling on the power cord. Always grip the

plug firmly and pull straight out from the receptacle.

• Do not use an extension cord with this appliance. If the power cord is too

short, have a qualified electrician or service technician install an outlet near

the appliance. Use of an extension cord can negatively affect the performance

of the unit.

WARNING: ELECTRICAL SHOCK HAZARD

Failure to follow these instructions can result in death, fire, or electrical shock.

• A 15-20 amp fused, grounded electrical supply is required. This provides the best

performance and also prevents overloading wiring circuits which could cause a

fire hazard from overheated wires.

• The refrigerator should always be connected to its own individual electrical

branch leading directly to the main voltage source or distribution panel.

• Immediately discontinue use if the main power supply line has been damaged. If

the supply line is damaged, it must be repaired by a qualified service professional.

• When removing the refrigerator away from the wall, be careful not to roll over or

damage the main power supply line.

3-prong receptacle

Receptacle box cover

3-prong plug

Grounding lead

Grounding adapter Receptacle box cover

Screw

Receptacle

Using a 3-prong plug and outlet Using a grounding adapter

10 www.insigniaproducts.com

Leveling your refrigerator

• Your refrigerator must be level in order to function correctly. If your

refrigerator isn’t leveled during installation, the door may not close or seal

correctly and cause cooling, frost, or moisture problems.

• To level your refrigerator, turn the leveling foot (front) clockwise to raise a side

of your refrigerator or turn it counter-clockwise to lower a side.

Reversing the door

You will need the following tools to reverse the door:

Note: Having someone push against the top of your refrigerator helps to take some weight off

the leveling foot and makes it easier to adjust.

CAUTION: If you lay your refrigerator on its back or side for any length of time, wait for six hours

after you stand it up again before you plug it in. Otherwise, you may cause damage.

Note: Illustrations are for reference only and may not reflect the actual configuration of your

refrigerator.

Raise

Lower

Leveling

foot

Door

Phillips screwdriver Socket wrench (5/8 in.) Putty knife or thin-blade

screw driver Masking tape

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Insignia Kühlschrank Handbücher

Insignia

Insignia NS-CF26PK7 Bedienungsanleitung

Insignia

Insignia NS-UZ17WH0 Bedienungsanleitung

Insignia

Insignia NS-RFD21CISS0 Bedienungsanleitung

Insignia

Insignia NS-RTM18WH2 Bedienungsanleitung

Insignia

Insignia NS-UZ14WH0 Bedienungsanleitung

Insignia

Insignia NS-RBM10BK8 Bedienungsanleitung

Insignia

Insignia NS-RTM10BK0 Bedienungsanleitung

Insignia

Insignia NS-RTM18BK8L Bedienungsanleitung

Insignia

Insignia NS-CF43SS7 Bedienungsanleitung

Insignia

Insignia NS-RTM10WH2 Bedienungsanleitung

Insignia

Insignia NS-RBM10WH7 Bedienungsanleitung

Insignia

Insignia NS-RBM18SS0-C Bedienungsanleitung

Insignia

Insignia NS-RFD21CXSS0 Bedienungsanleitung

Insignia

Insignia NS-RFD21SS9-C Bedienungsanleitung

Insignia

Insignia NS-RTM10BK2 Bedienungsanleitung

Insignia

Insignia NS-BC1ZSS9 Bedienungsanleitung

Insignia

Insignia NS-RTM18BS8 Bedienungsanleitung

Insignia

Insignia NS-RTM10WH7 Bedienungsanleitung

Insignia

Insignia NS-CF30SS9 Bedienungsanleitung

Insignia

Insignia NS-RTM21SS7 Bedienungsanleitung

Insignia

Insignia NS-CF17BK9 Bedienungsanleitung

Insignia

Insignia NS-RTM18WHD2 Bedienungsanleitung

Insignia

Insignia NS-RFD21SS7 Bedienungsanleitung

Insignia

Insignia NS-RFD26SS9-C Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
