Interlogix TruVision DVR 44HD Bedienungsanleitung

TruVision DVR 44HD User

Manual

P/N 1072968-EN • REV B • ISS 11AUG15

Interlogix is part of UTC Building &

Industrial Systems, a unit of United

Technologies Corporation

Trademarks and patents

Trade names used in this document may be trademarks or registered trademarks of

the manufacturers or vendors of the

respective products.

Manufacturer

Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

FCC compliance

Class A:

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the

equipment is operated i

n a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in

ccordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment

in a residential area is likely to cause

harmful interference in which case the user will be required to correct the

interference at his own expense.

Canada

This Class A digital apparatus complies with Canadian ICES

-003.

Cet appareil mumérique de la cla

sse A est conforme à la norme NMB-003 du

Canada.

ACMA compliance

Notice!

This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take adequate

measures.

Certification

N4131

EU directives

2004/108/EC (EMC directive)

: Hereby, UTC Fire & Security declares that this

device is in compliance or with the essential requirements and other relevant

provisions of Directive 2004/108/EC

2012/19/EU (WEEE directive):

Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon the purchase of equivalent

new equipment, or dispose of it at designated collect

ion points. For more

information see: www.recyclethis.info.

2006/66/EC (battery directive):

This product contains a battery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentation for specific battery

information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your supplier or to a designated

collection point. For more information see:

www.recyclethis.info.

Contact information

For contact information

, see www.interlogix.com or www.utcfssecurityproducts.eu

TruVision DVR 44HD User Manual 1

Content

Important information 5

Chapter 1 Product introduction 6

Product overview 6

Default settings to access the device 6

Chapter 2 Physical installation 8

Installation environment 8

Unpacking the recorder and its accessories 8

Back panel 9

Monitor connections 11

Rack mounting 11

Chapter 3 Getting started 12

Power on the recorder 12

The startup wizard 13

Chapter 4 Operating instructions 17

Controlling the recorder 17

Using the front panel 17

Using the mouse 21

Using the IR remote control 22

Menu overview 24

Chapter 5 Live view 27

Description of live view 27

Video output 28

Live view mouse menu 28

Single and multiview display mode 30

Sequencing cameras 30

Live view toolbar 30

Digital zoom 32

PTZ preset and tours 32

Chapter 6 Playback functionality 35

Overview of the playback view 35

Playback mouse menu 38

Instant playback 38

24-hour playback 39

Playback speed and skip time 40

Play back frame-by-frame 41

Digital zoom in playback 41

Create bookmarks 41

2 TruVision DVR 44HD User Manual

Chapter 7 Searching files 43

Search video menu 43

Search for motion events in playback 44

Search and play back recordings by time and video type 45

Search and playback recordings by event 46

Search bookmarked recordings 47

Search snapshots 47

Log search 48

Disk analysis 48

Chapter 8 Archiving files 49

Archive files 49

Searching and playing back recorded video 51

Exporting video recordings 51

Exporting video recordings via TruVision Navigator 53

Using TruVision Player 53

Chapter 9 Display settings 55

Display settings 55

Layout 56

Chapter 10 Camera setup 58

Analog camera setup 58

IP camera status 59

Camera recording settings 61

Snapshots 63

Camera OSD 63

Image settings 64

Motion detection 65

Line crossing detection 66

Intrusion detection 68

Privacy mask 70

Camera tamper 71

Restricted access camera 72

Configure PTZ settings 73

PTZ presets and tours 73

V-stream encoding 76

Chapter 11 Network settings 78

Network settings 78

PPPoE settings 80

DDNS settings 81

NTP server settings 82

E-mail settings 83

Configure an FTP server to store snapshots 84

SNMP settings 84

UPnP settings 84

Network status 85

TruVision DVR 44HD User Manual 3

Export network packet data 87

Network statistics 87

Chapter 12 Recording 88

Recording schedule 88

Modify the instant replay duration 90

Manual recording 91

Chapter 13 Alarm and event setup 92

Set up alarm inputs 92

Set up alarm outputs 93

Manual trigger 94

Buzzer settings 95

Alarm notification types 95

Detect video loss 96

Alarm host setup 97

Chapter 14 Device management 98

Time and date settings 98

General recorder settings 100

Configuration files 101

Upgrade system firmware 102

Holiday schedules 102

Text insertion 103

Chapter 15 Storage management 105

HDD information 105

HDD redundancy 106

Managing eSATA 107

Storage mode 107

S.M.A.R.T. settings 109

Bad sector detection 110

Install HDDs 111

Add a network storage system 112

Chapter 16 User management 114

Add a new user 114

Customize a user’s access privileges 115

Local configuration settings 115

Remote configuration settings 116

Camera configuration settings 116

Delete a user 117

Modify a user 117

Change the Admin password 117

Chapter 17 System information 118

View system information 118

Search the system log 121

4 TruVision DVR 44HD User Manual

Chapter 18 Using the web browser 124

Windows 7 and Windows 8 users 124

Access the web browser 125

Web browser live view 125

Control a PTZ dome camera via the web browser 127

Play back recorded video 127

Search for event logs 129

Configure the recorder via the browser 130

Text overlay 133

Appendix A Specifications 135

Appendix B PTZ protocols 137

Appendix C Port forwarding information 138

Seeking further assistance 138

Appendix D Connect a PTZ dome camera 140

Configuring the PTZ protocols for Interlogix cameras 140

Appendix E KTD-405 keypad 144

Supported firmware 144

Wiring the keypad 144

Setting the keypad to work with the recorder 145

Recorder and keypad functions 146

Operating the keypad 147

Recorder mapping to the KTD-405 keypad 148

Controlling a camera 150

Connecting a KTD-405 keypad and dome camera to the recorder 151

Appendix F Maximum pre-recording times 153

Appendix G Supported PTZ commands 155

Appendix H Default menu settings 157

Index 169

TruVision DVR 44HD User Manual 5

Important information

Advisory messages

Advisory messages alert you to conditions or practices that can cause unwanted results. The

advisory messages used in this document are shown and described below.

WARNING: Warning messages advise you of hazards that could result in injury or loss

of life. They tell you which actions to take or to avoid in order to prevent the injury or

loss of life.

Caution: Caution messages advise you of possible equipment damage. They tell you which

actions to take or to avoid in order to prevent damage.

Note: Note messages advise you of the possible loss of time or effort. They describe how to

avoid the loss. Notes are also used to point out important information that you should read.

6 TruVision DVR 44HD User Manual

Chapter 1

Product introduction

Product overview

This recorder is a full featured and scalable digital video recording system that can store,

display, search, export and manage video from up to 16 analog, HD analog, or IP cameras. The

recorder utilizes HD-TVI technology to record up to 1080P resolution. HD-TVI (Transport Video

Interface) is an open standard meaning it can record any camera using the TVI standard. It

provides integration with the UTC portfolio of security solutions, and offers a seamless product

experience within the TruVision brand.

The recorder can fully integrate with the license-free TruVision Navigator software, which is

ideal for the most commercial applications. Its easy and intuitive-to-use web browser interface

enables remote configuration and secure viewing, searching, and playing back of video from

computers connected via the Internet.

Note: Models are shipped with the power cords for their region.

Default settings to access the device

Default user names and passwords

See Table 1 on page 7 for the list of default user names and passwords. Go to Chapter 16

“User management” on page 114 for further information.

Chapter 1: Product introduction

TruVision DVR 44HD User Manual 7

Table 1: Default user names and passwords

User

Description

Administrator

There can only be one administrator.

The user name is “admin”. The name cannot be modified.

The default password is 1234.

Operator

The default user name is “operator”.

The default password is 2222.

Guest

The default user name is “guest”.

The default password is 3333.

Note: The default passwords should be changed for security reasons.

Default network settings

The network settings are:

• IP address - 192.168.1.82

• Subnet mask - 255.255.255.0

• Gateway address - 192.168.1.1

• Ports:

When using the browser:

RTSP port: 554

HTTP port: 80

When using TruNav:

RTSP port: 554

Server/Client software port: 8000

Go to “Using the web browser” on page 124 for further information.

8 TruVision DVR 44HD User Manual

Chapter 2

Physical installation

This section describes how to install the recorder.

Installation environment

When installing your product, consider these factors:

• Ventilation

• Temperature

• Moisture

• Chassis load

Ventilation: Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Ensure that the location planned for the installation of the unit is

well ventilated.

Temperature: Consider the unit’s operating temperature (-10 to +55 ºC, 14 to 131 °F) and

noncondensing humidity specifications (10 to 90%) before choosing an installation location.

Extremes of heat or cold beyond the specified operating temperature limits may reduce the life

expectancy of the recorder. Do not install the unit on top of other hot equipment. Leave 44 mm

(1.75 in.) of space between rack-mounted DVR units.

Moisture: Do not use the unit near water. Moisture can damage the internal components. To

reduce the risk of fire or electric shock, do not expose this unit to rain or moisture.

Chassis: Equipment weighing less than 15.9 kg (35 lb.) may be placed on top of the unit.

Unpacking the recorder and its accessories

When you receive the product, check the package and contents for damage, and verify that all

items are included. There is an item list included in the package. If any of the items are

damaged or missing, please contact your local supplier.

Items shipped with the product include:

Andere Handbücher für TruVision DVR 44HD

Inhaltsverzeichnis

Andere Interlogix DVR Handbücher

Interlogix

Interlogix TruVision NVR 70 Bedienungsanleitung

Interlogix

Interlogix TruVision Line Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 45HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 15HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 12 Bedienungsanleitung

Interlogix

Interlogix TVR 15HD Bedienungsanleitung

Interlogix

Interlogix TVN 11 Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 71 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 42 Bedienungsanleitung

Interlogix

Interlogix TruVision TVR-1116D-2T Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 20 Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 50 Bedienungsanleitung

Interlogix

Interlogix TVR 60 series Bedienungsanleitung

Interlogix

Interlogix TVR 11c Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 21 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 40 Bedienungsanleitung

Interlogix

Interlogix TVR-1004-250 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 41 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 45HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 12HD Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 21 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 11 Bedienungsanleitung

Interlogix

Interlogix TVR 12HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 44HD Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
