TruVision DVR 11 and

DVR 11c User Manual

P/N 1072595B-EN • REV 1.0 • ISS 28JAN13

2013 UTC Fire & Security Americas Corporation, Inc.

Interlogix is part of UTC Climate Controls & Security, a unit of United

Trademarks and patents

e TruVision name and logo are trademarks of UTC Fire & Security.

Other trade names used in this document may be trademarks or registered

trademarks of the manufacturers or vendors of

the respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance

Class B:

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. T

his equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications.

There is no guarantee that interference will not occur in a pa

rticular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the followin

g measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

European Union

directives

12004/108/EC (EMC directive):

Hereby, UTC Fire & Security declares that

this device is in compliance

or with the essential requirements and other

relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon the purchase of

equivalent new equ

ipment, or dispose of it at designated collection points.

For more information see: www.recyclethis.info.

2006/66/EC (battery directive):

This product contains a battery that cannot

be disposed of as unsorted municipal waste in the European Union. See

the

product documentation for specific battery information. The battery is

marked with this symbol, which may include lettering to indicate cadmium

(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to

your supplier or to a designat

ed collection point. For more information see:

www.recyclethis.info.

Contact information

For contact information

, see www.utcfireandsecurity.com or

www.utcfssecurityproducts.eu

TruVision DVR 11 and DVR 11c User Manual i

Content

Chapter 1 Product introduction 1

Product overview 1

Chapter 2 Installation 3

Installation environment 3

Unpacking the DVR and its accessories 3

Back panel 4

Monitor connections 6

Audio inputs and output 6

RS-485 port 7

RS-232 port 7

PTZ dome camera set up 7

Connecting a KTD-405 keypad and dome camera to the

DVR 12

Brackets 13

Chapter 3 Getting started 15

Turning on and off the DVR 15

Using the setup wizard 16

Chapter 4 Recording 19

Initializing the recording settings 19

Defining a recording schedule 21

Daily schedules 22

Holiday schedules 23

Motion detection schedules 23

External alarm schedules 23

Protecting recorded files 24

Capturing text insertions 25

Chapter 5 Alarm settings 27

Description of alarm notification types 27

Setting up motion detection 27

Setting up external alarms 30

Triggering or clearing alarm outputs manually 32

Setting up system notifications 32

Detecting video loss 33

Detecting video tampering 34

Chapter 6 Network settings 35

Configuring general network settings 35

Configuring PPPoE 36

Configuring DDNS 37

Configuring an NTP server 38

ii TruVision DVR 11 and DVR 11c User Manual

Configuring email 38

Configuring SNMP 39

Configuring a remote alarm host 40

Configuring multicast 40

Configuring the server and HTTP ports 41

Configuring the RTSP service port 41

Checking network status 41

Exporting network packet data 43

Chapter 7 HDD management 45

Initializing HDDs 45

Setting the HDD quota 45

Setting the HDD property 46

Checking HDD status 46

Configuring HDD alarms 47

Checking the S.M.A.R.T. information 47

Chapter 8 Operating instructions 49

Controlling the DVR 49

Using the front panel 49

Using the mouse 51

Using the IR remote control 52

Menu overview 55

Chapter 9 Live view 59

Description of live view 59

Video output 60

Controlling live view 60

Single and multiview display formats 61

Sequencing cameras 62

Accessing frequently used commands 63

Configuring live view 65

Configuring time and date 67

General settings 68

V-stream encoding 71

Chapter 10 Controlling a PTZ camera 73

Configuring PTZ settings 73

Calling up presets, tours and shadow tours 74

Setting and calling up presets 75

Setting and calling up preset tours 77

Setting and calling up a shadow tour 79

Chapter 11 Playing back a recording 81

Overview of the playback window 81

Instant playback 83

All-day playback 84

Searching recorded video 85

TruVision DVR 11 and DVR 11c User Manual iii

Playing back recordings by time and video type 86

Playing back recordings by event 87

Slideshow of snapshots 88

Playing back recordings from the system log 88

Motion search 90

Playing back frame-by-frame 91

Digital zoom in playback 91

Chapter 12 Archiving recorded files 93

Archiving files 93

Creating and archiving video clips 95

Archiving snapshots 96

Managing backup devices 97

Playing back archived files on a PC 97

Chapter 13 DVR management 99

Configuring the RS-232 port 99

Updating system firmware 100

Restoring default settings 100

Viewing system information 101

Searching system logs for events 102

Chapter 14 Camera settings 105

Configuring the OSD settings 105

Setting up privacy masking 106

Adjusting video image settings 107

Chapter 15 User management 109

Adding a new user 109

Customizing a user’s access privileges 110

Deleting a user 112

Modifying a user 112

Changing the Admin password 112

Chapter 16 Using the web browser 113

Windows Vista and 7 users 113

Accessing the web browser 114

Web browser overview 114

Using the web browser to configure the device 116

Searching and playing back recorded video 117

Searching for event logs 119

Controlling a PTZ dome camera in the web browser 119

Capturing text insertions 120

iv TruVision DVR 11 and DVR 11c User Manual

Appendix A Specifications 123

Appendix B PTZ protocols 125

Appendix C KTD-405 keypad 127

Supported firmware 127

Wiring the keypad 127

Setting up the keypad to work with the TVR 11 128

Operating the keypad 130

Appendix D Maximum pre-recording times 135

Appendix E Supported PTZ commands 137

Appendix F Default menu settings 139

Glossary 147

Index 149

TruVision DVR 11 and DVR 11c User Manual 1

Chapter 1

Product introduction

Product overview

This is the TruVision DVR 11(TVR 11) and TruVision DVR 11c (TVR 11c) User

Manual for models:

Table 1: Product codes for TVR 11

Americas

Description

TVR

-1108-1T TruVision DVR 11, H.264, 8 ch, 1 TB Storage

TVR

-1108-2T TruVision DVR 11, H.264, 8 ch, 2 TB Storage

TVR

-1116-2T TruVision DVR 11, H.264, 16 ch, 2 TB Storage

TVR

-1116-4T TruVision DVR 11, H.264, 16 ch, 4 TB Storage

EMEA

TVR

-1104-500/EA TruVision DVR 11, H.264, 4 ch, 500 GB Storage

TVR

-1104-1T/EA TruVision DVR 11, H.264, 4 ch, 1 TB Storage

TVR

-1104-2T/EA TruVision DVR 11, H.264, 4 ch, 2 TB Storage

TVR

-1108-1T/EA TruVision DVR 11, H.264, 8 ch, 1 TB Storage

TVR

-1108-2T/EA TruVision DVR 11, H.264, 8 ch, 2 TB Storage

TVR

-1116-2T/EA TruVision DVR 11, H.264, 16 ch, 2 TB Storage

TVR

-1116-4T/EA TruVision DVR 11, H.264, 16 ch, 4 TB Storage

TVR

-1104D-500/EA TruVision DVR 11, H.264, 4 ch, DVD/CD, 500 GB Storage

TVR

-1104D-1T/EA TruVision DVR 11, H.264, 4 ch, DVD/CD, 1 TB Storage

TVR

-1104D-2T/EA TruVision DVR 11, H.264, 4 ch, DVD/CD, 2 TB Storage

TVR

-1108D-1T/EA TruVision DVR 11, H.264, 8 ch, DVD/CD, 1 TB Storage

TVR

-1108D-2T/EA TruVision DVR 11, H.264, 8 ch, DVD/CD, 2 TB Storage

TVR

-1116D-1T/EA TruVision DVR 11, H.264, 16 ch, DVD/CD, 1 TB Storage

TVR

-1116D-2T/EA TruVision DVR 11, H.264, 16 ch, DVD/CD, 2 TB Storage

0BChapter 1: Product introduction

2 TruVision DVR 11 and DVR 11c User Manual

Table 2: Product codes for TVR 11c

TVR

-1104c-500 TruVision DVR 11c, H.264, 4 ch, 500 GB Storage

TVR

-1104c-1T TruVision DVR 11c, H.264, 4 ch, 1 TB Storage

Note: Models are shipped with the power cords for their region.

For regions not listed in Table 1 or Table 2 above, please contact your local

supplier.

The TVR 11 and TVR 11c are versatile, user-friendly embedded digital video

recorders (DVR).

The TVR 11 allows end-users to record 4, 8 or 16 analog cameras at CIF in real

time (25/30 fps), while providing integration with the UTC portfolio of security

solutions, and offering a seamless product experience within the TruVision

brand.

The TVR11c is a four-channel version of the TVR11 that allows end users to

record four channel analog cameras at CIF in real time.

The dual streaming functionality allows the user to set up different settings for

recording and streaming video in live view mode.

Both DVRs can fully integrate with the license-free TruVision Navigator software,

which is ideal for the most commercial applications. Their easy and intuitive-to-

use web browser interface enables remote configuration and secure viewing,

searching, and playing back of video from computers connected via the Internet.

TruVision DVR 11 and DVR 11c User Manual 3

Chapter 2

Installation

This section describes how to install the DVR unit.

Installation environment

When installing your product, consider these factors:

• Ventilation

• Temperature

• Moisture

• Chassis load

Ventilation: Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Ensure that the location planned for the installation

of the unit is well ventilated.

Temperature: Consider the unit’s operating temperature (-10 to +55 ºC, 14 to

131 °F) and noncondensing humidity specifications (10 to 90%) before choosing

an installation location. Extremes of heat or cold beyond the specified operating

temperature limits may reduce the life expectancy of the DVR. Do not install the

unit on top of other hot equipment. Leave 44 mm (1.75 in.) of space between

rack-mounted DVR units.

Moisture: Do not use the unit near water. Moisture can damage the internal

components. To reduce the risk of fire or electric shock, do not expose this unit to

rain or moisture.

Chassis: Equipment weighing less than 15.9 kg (35 lb.) may be placed on top of

the unit.

Unpacking the DVR and its accessories

When you receive the product, check the package and contents for damage, and

verify that all items are included. There is an item list included in the package. If

any of the items are damaged or missing, please contact your local supplier.

1BChapter 2: Installation

4 TruVision DVR 11 and DVR 11c User Manual

Items shipped with the product include:

• IR (infrared) remote control

• Two AAA batteries for the remote control

• AC power cords

• USB mouse

• DVR

• Video loop through cable (TVR 11 only)

• CD with software and manuals

• TruVision DVR 11 Quick Start Guide or TruVision DVR 11c Quick Start Guide

• TruVision DVR 11 User Manual or TruVision DVR 11c User Manual (on CD)

Back panel

The figures on the next page show the back panel connections and describe

each connector on typical TVR 11 and TVR 11c digital video recorders. Details

may vary for specific models.

Before powering up the DVR, connect the cameras and a main monitor for basic

operation. Once all required connections are done, enter the relevant data in the

setup wizard (see page 16).

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Interlogix DVR Handbücher

Interlogix

Interlogix MobileView 3000 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 44HD Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 50 Bedienungsanleitung

Interlogix

Interlogix TruVision SVR Bedienungsanleitung

Interlogix

Interlogix TVR 45HD Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 22 Bedienungsanleitung

Interlogix

Interlogix TruVision NVR 71 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 42 Bedienungsanleitung

Interlogix

Interlogix TVR 12HD Bedienungsanleitung

Interlogix

Interlogix TruVision TVN 21 Bedienungsanleitung

Interlogix

Interlogix truVision DVR 31 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 20 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 42 Bedienungsanleitung

Interlogix

Interlogix TruVision TVR 1516DHD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 45HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 60 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 45HD Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 12 Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 15HD Bedienungsanleitung

Interlogix

Interlogix TVR 60 series Bedienungsanleitung

Interlogix

Interlogix TVR-1004-250 Bedienungsanleitung

Interlogix

Interlogix TVR 12 Bedienungsanleitung

Interlogix

Interlogix TruVision Line Bedienungsanleitung

Interlogix

Interlogix TruVision DVR 40 Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
