Kärcher NT 70/1 Bedienungsanleitung

www.kaercher.com

NT 70/1

NT 70/2

NT 70/2 Me

NT 70/3

59659460 02/13

Deutsch 5

English 11

Français 17

Italiano 23

Nederlands 29

Español 35

Português 41

Dansk 47

Norsk 53

Svenska 59

Suomi 65

Ελληνικά 71

Türkçe 77

Русский 83

Magyar 90

Čeština 96

Slovenščina 102

Polski 108

Româneşte 114

Slovenčina 120

Hrvatski 126

Srpski 132

Български 138

Eesti 144

Latviešu 150

Lietuviškai 156

Українська 162

14 10

911121315

NT 70/1

NT 70/2

NT 70/3

21 20 19

“Click”

– 1

Please read and comply with

these original instructions prior

totheinitialoperationofyourapplianceand

store them for later use or subsequent own-

ers.

–Before first start-up it is definitely nec-

essaryto readthe safetyindications Nr.

5.956-249!

–The non-compliance of the operating

and safety instructions may lead to

damages of the appliance and to dan-

gers for the operator and other persons.

–Incaseof transport damageinform ven-

dor immediately

Notes about the ingredients (REACH)

You will find current information about the

ingredients at:

www.kaercher.com/REACH

Danger

Immediate danger that can cause severe

injury or even death.

몇Warning

Possible hazardous situation that could

lead to severe injury or even death.

Caution

Possible hazardous situation that could

lead to mild injury to persons or damage to

property.

몇Warning

Theapplianceisnotsuitableforvacuuming

dust which endangers health.

–The machine is meant for dry and wet

cleaning of floors and walls.

–Thisapplianceis suited forthe commer-

cial use, e.g. in workshops, industrial

companies, schools and hotels.

–Room temperature should not exceed

40 °C.

–The appliance should never weigh

more than 100 kg with additional loads.

Contents

Environmental protection . . EN . . .1

Symbols in the operating in-

structions . . . . . . . . . . . . . . EN . . .1

Proper use . . . . . . . . . . . . . EN . . .1

Device elements. . . . . . . . . EN . . .2

Start up. . . . . . . . . . . . . . . . EN . . .2

Operation . . . . . . . . . . . . . . EN . . .3

Transport . . . . . . . . . . . . . . EN . . .3

Storage. . . . . . . . . . . . . . . . EN . . .3

Maintenance and care . . . . EN . . .3

Troubleshooting . . . . . . . . . EN . . .4

Warranty. . . . . . . . . . . . . . . EN . . .4

Accessories and Spare Parts EN . . .4

EC Declaration of Conformity EN . . .5

Technical specifications . . . EN . . .6

Environmental protection

The packaging material can be

recycled. Please do not throw

the packaging material into

householdwaste;pleasesendit

for recycling.

Oldappliancescontainvaluable

materials that can be recycled;

these should be sent for recy-

cling. Batteries, oil, and similar

substances must not enter the

environment. Please dispose of

your old appliances using ap-

propriate collection systems.

Symbols in the operating

instructions

Proper use

11EN

– 2

1 Star screw

2 Cartridge filter

3 Mechanical overflow protection

4 Suction head

5 Suction hose

6 Push handle

7 Cable hook

8 Wheel

9 Suction head lock

10 Dirt receptacle

11 Suction support

12 Steering roller

13 Chassis

14 Chassis handle

15 Floor nozzle

16 Suction tube

17 Carrying handle

18 Bender

19 Appliance switch suction turbine 2

20 Appliance switch suction turbine 1

21 Appliance switch suction turbine 3

22 Storage for floor nozzle

23 Drain hose

24 Holder for suction pipes

25 Holder for crevice nozzle

26 Power cord

27 Nameplate

Caution

The highest allowed net impedance at the

electrical connection point (refer to techni-

cal data) is not to be exceeded. In case of

confusion regarding the power impedance

presenton yourconnection, pleasecontact

your utilities provider.

Caution

The cartridge filter must never be removed

during vacuuming.

–When vacuuming fine dust, you may

alsouseanadditionalpaperfilterbagor

a membrane filter (special accessory).

Illustration

Release and remove the suction head.

Insert the paper filter bag or the mem-

brane filter (special attachment).

Insert and lock the suction head.

Illustration

Remove the brush strips.

Install the rubber lips.

Note: The structured side of the rubber lips

must point outwards.

–If the appliance is used to vacuum wet

dirt the paper filter bag or the mem-

brane filter (special accessory) must al-

ways be removed.

–Itis recommendedtouse aspecial filter

bag (wet) (see Filter systems).

Caution

The cartridge filter must never be removed

during vacuuming.

–After the wet vacuuming: Clean the me-

chanical overflow protection and the

container with a damp rag and dry

them.

–If you change immediately from wet to

dry vacuuming, then replace the wet

cartridge filter with a dry one.

Release and remove the suction head.

Unscrew the star scew and pull out the

cartridge filter.

Device elements

Start up

Dry vacuum cleaning

Inserting the paper filter bag (option)

Wet vacuum cleaning

Inserting the rubber lips

Remove the paper filter bag

Wet vacuuming with cartridge filter

Wet vacuuming with wet filter (optional)

12 EN

– 3

Illustration

Tighten the star screw.

Install the wet filter.

Insert and lock the suction head.

Caution

The wet filter must never be removed dur-

ing the vacuuming.

–After the wet vacuuming: Clean the me-

chanical overflow protection and the

container with a damp rag and dry

them.

–If you change immediately from wet to

dry vacuuming, replace the wet filter

with a cartridge filter.

Caution

Please observe the local provisions regard-

ing the wastewater treatment.

Appliance with metal container:

Illustration

Appliance with plastic container:

Illustration

Drain off dirty water through the drain-

age hose.

Illustration

The suction hose is equipped with a clip

system. All C-40/C-DN-40 accessories can

be connected.

Plug in the main plug.

Turn on the appliance.

–Thevacuum channelis equippedwith a

float.

–Whenthedirtwaterreachesthehighest

permissible level in the container, the

suction power is interrupted.

Turn off the appliance.

Empty the container.

Turn off the appliance.

Pull out the mains plug.

Empty the container.

Vacuum and wipe the appliance inside

and outside with a damp cloth.

Wind the suction hose and the mains ca-

ble and hang it over the pushing handle.

Place the appliance in a dry room and

secure it from unauthorized use.

Caution

Risk of injury and damage! Observe the

weight of the appliance when you transport

it.

Remove the suction pipe with the floor

nozzle from the holder. Hold the appli-

ance by the handle and at the suction

pipe to transport it, not by the push han-

dle.

Pull the device behind you at the carry-

inghandlefortransportingitoverlonger

distances

When transporting in vehicles, secure

the appliance according to the guide-

lines from slipping and tipping over.

Caution

Risk of injury and damage! Note the weight

of the appliance in case of storage.

This appliance must only be stored in inte-

rior rooms.

Danger

Firstpull outthe plugfrom themains before

carrying out any tasks on the machine.

Drain off dirt water

Clip connection

Operation

Turning on the Appliance

Emptying the dirt container

Turn off the appliance

After each operation

Storing the Appliance

Transport

Storage

Maintenance and care

13EN

– 4

Release and remove the suction head.

Unscrew the star screw, pull out the

cartridge filter and replace with a new

one.

Tighten the star screw.

Insert and lock the suction head.

Release and remove the suction head.

Unscrew the star scew and pull out the

cartridge filter.

Clean the mechanical overflow protec-

tion with a moist cloth.

Replace the cartridge filters.

Tighten the star screw.

Insert and lock the suction head.

Danger

Firstpull outthe plugfrom themains before

carrying out any tasks on the machine.

Check the receptacle and the fuse of

the power supply.

Check power cable, mains plug and

mechanical overflow protection.

Turn on the appliance.

Empty the container.

Turn off the appliance and wait for 5

seconds, turn it on again after 5 sec-

onds.

Remove choking of suction nozzle, suc-

tion tube, suction hose, or cartridge filter.

Replace the washer between the suc-

tion head and the container.

Exchange the paper filter bag.

Clean or replace the membrane filter

(special accessory) under running water.

Change cartridge filter.

Check drain pipe for leaks.

Check the proper installation of the car-

tridge filter.

Change cartridge filter.

Check swimmer for easy accessibility;

clean with a moist rag or replace as

need be.

The warranty terms published by the rele-

vant sales company are applicable in each

country. We will repair potential failures of

your appliance within the warranty period

free of charge, provided that such failure is

caused by faulty material or defects in man-

ufacturing. In the event of a warranty claim

please contact your dealer or the nearest

authorized Customer Service centre.

Please submit the proof of purchase.

–Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and trouble free.

–At the end of the operating instructions

youwillfindaselectedlistofspareparts

that are often required.

–For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

Change cartridge filter

Cleaning the mechanical overflow

safeguard

Troubleshooting

Suction turbine does not run

Suction turbine turns off

Suction turbine does not start again

after the container has been

emptied

Suction capacity decreases

Dust comes out while vacuuming

Mechanicaloverflowsafeguard(wet

suction) does not function

Warranty

Accessories and Spare Parts

14 EN

– 5

We hereby declare that the machine de-

scribed below complies with the relevant

basicsafety andhealthrequirements ofthe

EU Directives, both in its basic design and

construction as well as in the version put

into circulation by us. This declaration shall

cease to be valid if the machine is modified

without our prior approval.

5.957-702

The undersigned act on behalf and under

the power of attorney of the company man-

agement.

Authorised Documentation Representative

S. Reiser

Alfred Kärcher GmbH Co. KG

Alfred-Kärcher-Str. 28 - 40

71364 Winnenden (Germany)

Phone: +49 7195 14-0

Fax: +49 7195 14-2212

Winnenden, 2010/09/01

EC Declaration of Conformity

Product: Wet and dry vacuum cleaner

Type: 1.667-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)

2004/108/EC

Applied harmonized standards

EN 55014–1: 2006+A1: 2009+A2: 2011

EN 55014–2: 1997+A1: 2001+A2: 2008

EN 60335–1

EN 60335–2–69

EN 61000–3–2: 2006+A1: 2009+A2: 2009

EN 61000–3–3: 2008

EN 62233: 2008

Applied national standards

CEO Head of Approbation

15EN

– 6

Technical specifications

NT 70/1 NT 70/2 NT 70/3

Mains voltage V 220-240 220-240 220-240

Frequency Hz 1~ 50/60 1~ 50/60 1~ 50/60

Max. performance W 1200 2400 3600

Rated power W 1050 2100 3150

Maximum allowed net imped-

ance Ohm -- (0.282+j0.176) (0.195+j0.122)

Container capacity l 71 71 71

Filling quantity (liquid) l 57 57 57

Air volume (max.) l/s 56 2x 56 3x 56

Negative pressure (max.) kPa (mbar) 20,8 (208) 20,8 (208) 20,8 (208)

Type of protection -- IPX4 IPX4 IPX4

Protective class II II II

Suction hose connection

(C-DN/C-ID) mm 40 40 40

Length x width x height mm 720 x 510 x

975 720 x 510 x

975

Typical operating weight kg 22,9 25,2 27,6

kg -- 25.6 (Me) --

Max. ambient temperature °C +40 +40 +40

Values determined to EN 60335-2-69

Sound pressure level LpA dB(A) 73 75 79

Uncertainty KpA dB(A) 1 1 1

Hand-arm vibration value m/s2<2,5 <2,5 <2,5

Uncertainty K m/s20,2 0,2 0,2

Power cord H05VV-F 2x1,5 mm2

Part no.: Cable length

EU 6.647-069.0 10 m

GB 6.649-803.0 10 m

16 EN

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kärcher Staubsauger Handbücher

Kärcher

Kärcher SC 5 EasyFix Premium Bedienungsanleitung

Kärcher

Kärcher NT 35/1 Tact Bedienungsanleitung

Kärcher

Kärcher VAPORAPID 1501 Bedienungsanleitung

Kärcher

Kärcher EWM 2 Bedienungsanleitung

Kärcher

Kärcher VC 6300 Bedienungsanleitung

Kärcher

Kärcher SC 2.500 C Bedienungsanleitung

Kärcher

Kärcher 2000 E Bedienungsanleitung

Kärcher

Kärcher BRC 40/22 C Bedienungsanleitung

Kärcher

Kärcher SE 4002 Bedienungsanleitung

Kärcher

Kärcher NT 65/2 Eco ME Bedienungsanleitung

Kärcher

Kärcher NT 361 ECO M A Bedienungsanleitung

Kärcher

Kärcher A 2504 Bedienungsanleitung

Kärcher

Kärcher A 2701 Bedienungsanleitung

Kärcher

Kärcher SC 4 Bedienungsanleitung

Kärcher

Kärcher SE 2001 Bedienungsanleitung

Kärcher

Kärcher IVC 60/24-2 Tact2 Bedienungsanleitung

Kärcher

Kärcher NT 72/2 ECO TC Bedienungsanleitung

Kärcher

Kärcher NT 65/2 ECO TC Bedienungsanleitung

Kärcher

Kärcher Puzzi 8/1 C Installations- und Betriebshandbuch

Kärcher

Kärcher SE 4002 Betriebsanleitung

Kärcher

Kärcher VC 5300 Bedienungsanleitung

Kärcher

Kärcher VC 6200 Bedienungsanleitung

Kärcher

Kärcher WD 3.800 M eco!ogic Bedienungsanleitung

Kärcher

Kärcher BRS 43/500 C Carpet Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
