Kenmore Progressive DU2001 Bedienungsanleitung

Use & Care Guide

Manuel d'entretien et d'utilisation

Model/Modèle: DU2001

ProgressiveTM

Bagless Upright Vacuum

Cleaner

Aspirateur Vertical Sans Sac

www.kenmorefloorcare.com

Vacuum Cleaner Help Line:

1-877-531-7321 (US) / 1-844-608-3081 (CA)

8:00am-5:00pm EST, M-F

- 2 -

Before Using Your New Vacuum Cleaner ........................................................................2

Packing List .....................................................................................................................2

Important Safety Instructions........................................................................................3-4

Vacuum Cleaner Warranty ..............................................................................................5

Parts and Features...........................................................................................................6

Assembly Instructions...................................................................................................7-8

Operating Instructions .................................................................................................9-13

Performance/Safety Features .........................................................................................14

Vacuum Maintenance and Care.................................................................................15-20

Troubleshooting.........................................................................................................21-22

Requesting Assistance or Service......................................................................Back Cover

TABLE OF CONTENTS

PACKING LIST

Your KENMORE VACUUM CLEANER is packaged with the following parts and components

assembled separately in the carton:

1 Upright Vacuum Cleaner

1 3-in-1 Combination Tool

1 Extension Wand

1 Flexible Hose

Read this Use & Care Guide. It will help you assemble and operate your new Kenmore

vacuum cleaner in the safest and most effective way.

For more information about vacuum cleaner care and operation, call the Vacuum Cleaner

Help Line at 1-877-531-7321 (US) / 1-844-608-3081 (CA). You will need the complete model

and serial numbers when requesting information.

Your vacuum cleaner’s model and serial numbers are located on the Model and Serial

Number Plate. Use the space below to record the model number and serial number of your

new Kenmore vacuum cleaner.

Model No.____________________________________________

Serial No. ____________________________________________

Date of Purchase ______________________________________

Keep this book and your sales check (receipt) in a safe place for future reference.

BEFORE USING YOUR NEW VACUUM CLEANER

1 Handle

1 Screw Bolt

1 Use & Care Guide

- 3 -

WARNING!

Your safety is important to us. To reduce the risk of fire, electrical shock, injury to persons

or damage when using your vacuum cleaner, follow basic safety precautions including the

following:

IMPORTANT SAFETY INSTRUCTIONS

• Use your vacuum cleaner only as

described in this Use & Care Guide.

Use only manufacturer’s recommended

attachments.

• Disconnect electrical supply before

servicing or cleaning out the brush area.

Failure to do so could result in the brush

unexpectedly starting, causing personal

injury from moving parts.

• Do not leave vacuum cleaner when

plugged in. Unplug from outlet when

not in use and before performing

maintenance.

• To reduce the risk of electrical shock - Do

not use outdoors or on wet surfaces.

• Do not allow to be used as a toy. Close

attention is necessary when used by or

near children.

• Do not use with a damaged cord or plug.

If vacuum cleaner is not working as it

should, has been dropped, damaged,

left outdoors, or dropped in water,

immediately discontinue use and call

1-877-531-7321 (US) / 1-844-608-3081

(CA) for assistance.

• Do not pull or carry by cord, use cord as

a handle, close a door on cord, or pull

cord around sharp edges or corners. Do

not run vacuum cleaner over cord. Keep

cord away from heated surfaces.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Do not handle plug or vacuum cleaner

with wet hands.

• Do not put any objects into openings.

• Do not use with any opening blocked;

Read all instructions in this guide before assembling or using your vacuum cleaner.

keep free of dust, lint, hair, and anything

that may reduce air flow.

• Keep hair, loose clothing, fingers, and all

parts of body away from openings and

moving parts.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not put on chairs, tables, etc. Keep on

floor.

• Do not use vacuum cleaner to pick

up flammable or combustible liquids

(gasoline, cleaning fluid, perfumes,

etc.), or use in areas where they may be

present. The fumes from these substances

can create a fire hazard or explosion.

• Do not pick up anything that is burning or

smoking, such as cigarettes, matches, or

hot ashes.

• Do not use vacuum cleaner without dust

cup and/or filters in place.

• Always clean the dust cup after

vacuuming carpet cleaners or freshener,

powders, and fine dust. These products

clog the filters, reduce airflow and can

cause damage to the vacuum cleaner.

Failure to clean the dust cup could cause

permanent damage to the vacuum

cleaner.

• Do not use the vacuum cleaner to pick

up sharp hard objects, small toys, pins,

paper clips, etc. They may damage the

vacuum cleaner or dust cup.

• You are responsible for making sure

that your vacuum cleaner is not used by

anyone unable to operate it properly.

- 4 -

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Proper assembly and safe use of your vacuum cleaner are your responsibilities. Your vacuum

cleaner is intended for Household Use. Read this Use & Care Guide carefully for important

use and safety information. This guide contains safety statements under warning and caution

symbols.

- 5 -

VACUUM CLEANER WARRANTY

LIMITED WARRANTY

FOR ONE YEAR from the date of sale this product is warranted against defects in material

or workmanship.

WITH PROOF OF SALE a defective product will be replaced free of charge.

The Kenmore brand is used under license. Direct all claims for warranty service to:

1-877-531-7321 (US) / 1-844-608-3081 (CA).

This warranty does not cover filters or belts, which are expendable parts that can wear

out from normal use within the warranty period.

This warranty is void if this product is ever used for other than private household purposes.

This warranty gives you specific legal rights, and you may also have other rights which

vary from state to state.

Cleva North America, Inc., Greenville SC 29607

- 6 -

PARTS AND FEATURES

It is important to know your vacuum cleaner’s parts and features to assure its proper and

safe use. Review these before using your vacuum cleaner.

To order a replacement part, call 1-877-531-7321 (US) / 1-844-608-3081 (CA).

REPLACEMENT PARTS

Item Part No.(US) Part No.(CA)

Foam Filter 561055105 561055105

Felt Filter 561055106 561055106

Exhaust Filter 571017106 571017106

3-in-1 Combination Tool 561055134 561055134

Extension Wand 561055128 561055128

Flexible Hose 571017110 571017110

Screw Bolt 561072105 561072105

Handle

Dust Cup

Release Button

Carrying

Handle

Dust Cup Lid

Release Button

Dust Cup On/Off

Switch

Lower Hose

Storage

Motorized

Nozzle

Brushroll

Indicator

Light

Lower Cord

Hook

Extension

Wand

Power

Cord

Upper

Cord Hook

Upper

Hose

Storage

Flexible

Hose

Accessory

Storage

Connection

Hose

Exhaust Filter Cover

(Exhaust Filter Inside)

3-in-1

Combination Tool

- 7 -

1. Insert the handle into the main body and

secure with one screw bolt provided.

NOTE:Tighten the screw bolt with a

screwdriver or a coin. Ensure that the screw

bolt is secured.

2.Insert the larger end of the extension

wand into the top of the connection hose

through the bracket until the wand is

fully seated on the post.

Ⅰ

Ⅱ

Ⅲ

Ⅳ

3. Insert the end of the flexible hose into

the main body by aligning marks as

shown in UNLOCKED (for cleaning).

Rotate the hose until marks align as

shown in LOCKED (for use). Then run the

flexible hose over the lower hose storage

and the upper hose storage. Insert the

other end onto the top of the extension

wand.

Before assembling the vacuum cleaner, check the PACKING LIST (page 2). Use this list to

verify that you have received all the components of your new Kenmore Bagless Upright

Vacuum Cleaner.

Please pay special attention to these hazard alert boxes, and follow any

instructions given. WARNING statements alert you to such hazards as fire,

electric shock, burns and personal injury. CAUTION statements alert you to

such hazards as personal injury and/or property damage.

ASSEMBLY INSTRUCTIONS

- 8 -

5.Make sure the upper and lower cord

hooks are in the proper position as

shown. Wrap the power cord loosely

around the upper and lower cord hooks.

NOTE:Make sure to wrap the power

cord around the upper cord hook first, and

then around the lower cord hook to avoid

damaging the power cord.

WARNING

Electrical Shock and Personal Injury

Hazard.

Wrapping the cord too tightly with

excessive stress on the cord may cause

cord damage. A damaged cord is an

electrical shock hazard and could cause

personal injury or damage.

ASSEMBLY INSTRUCTIONS

Upper Cord

Hook

Lower Cord

Hook

6.Lock power cord plug onto the power

cord.

Power Cord Plug

Power Cord

4.Insert the combination tool onto the

accessory storage post located on the

back of the main body.

1. Turn the upper cord hook to either side

to release the power cord.

- 9 -

CAUTION

Moving parts! To reduce the risk of personal injury, DO

NOT touch the brushroll when vacuum is on. Contacting the

brushroll while it is rotating can cut, bruise or cause other

injuries. Always turn off before servicing. Use caution when

operating near children or pets.

OPERATING INSTRUCTIONS

POWER CORD - RELEASE & USE

Upper Cord Hook

Upper Locking Notch

WARNING

To reduce the risk of electric shock, this

appliance has a polarized plug (one

blade is wider than the other). This plug

will fit in a polarized outlet only one

way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does

not fit, contact a qualified electrician to

install the proper outlet. Do not change

the plug in any way.

2.Detach the power cord plug from the

power cord.

3. Be sure the power cord is locked into

the upper locking notch as shown. This

will help manage the power cord when

operating the vacuum cleaner.

UPRIGHT MODE

NOTE:Make sure the vacuum cleaner

is completely assembled and the dust cup

is empty before using. Do not operate

vacuum cleaner without filters in place.

1. Release the handle by placing foot on

the nozzle and pull back to change

handle position.

2.Turn on the vacuum cleaner by pressing

the On/Off switch to the “I” position

for cleaning bare floors and small area

rugs.

NOTE:The brushroll does not rotate

when the vacuum cleaner is in the “I”

position.

- 10 -

POWER CORD - RELEASE & USE

OPERATION MODES

On/Off Switch

WARNING

Personal Injury and Product Damage

Hazard

· When any abnormality/failure occurs,

stop using the product immediately and

disconnect the power plug.

· DO NOT use outlets above counters.

Damage from cord to items in

surrounding area could occur.

WARNING

Electrical Shock and Personal Injury

Hazard

Wrapping the cord too tightly puts stress

on the cord and can cause cord damage.

A damaged cord is an electrical shock

hazard and could cause personal injury

or damage.

4.Plug the power cord plug into an outlet

located near the floor.

5.Press the On/Off switch to turn the

vacuum cleaner on.

6.Once you have completed vacuuming,

press the On/Off switch; unplug the

power cord plug from the outlet.

7. To restore power cord after use, turn the

upper cord hook to the upright position.

Then wrap cord loosely around cord

hooks.

Inhaltsverzeichnis

Andere Kenmore Staubsauger Handbücher

Kenmore

Kenmore 116.33728 Bedienungsanleitung

Kenmore

Kenmore 116.9815 Bedienungsanleitung

Kenmore

Kenmore 116.33725 Bedienungsanleitung

Kenmore

Kenmore AllergenSeal DU2109 Bedienungsanleitung

Kenmore

Kenmore 125.10340 Bedienungsanleitung

Kenmore

Kenmore 26823 - Progressive Bagless Canister Vacuum Bedienungsanleitung

Kenmore

Kenmore POWER-MATE 116.24614 Bedienungsanleitung

Kenmore

Kenmore 721.33078 Bedienungsanleitung

Kenmore

Kenmore 116.36922 Bedienungsanleitung

Kenmore

Kenmore 116.23105C Bedienungsanleitung

Kenmore

Kenmore BC3005 Bedienungsanleitung

Kenmore

Kenmore BC4027 Bedienungsanleitung

Kenmore

Kenmore 216.31703 Bedienungsanleitung

Kenmore

Kenmore 3911 - Upright Vacuum Bedienungsanleitung

Kenmore

Kenmore CROSSOVER MAX Bedienungsanleitung

Kenmore

Kenmore REVITALITE KW4070 Bedienungsanleitung

Kenmore

Kenmore 116.31100 Bedienungsanleitung

Kenmore

Kenmore 116.20212 Bedienungsanleitung

Kenmore

Kenmore SEARS 116.25512 Bedienungsanleitung

Kenmore

Kenmore 116.23108C Bedienungsanleitung

Kenmore

Kenmore 116.31810 Bedienungsanleitung

Kenmore

Kenmore 116.38099 Bedienungsanleitung

Kenmore

Kenmore 116.36720 Bedienungsanleitung

Kenmore

Kenmore DS4090.01 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
