Metra Electronics 95-5818 Bedienungsanleitung

APPLICATIONS

REV. 11/4/2013 INST95-5818

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

INSTALLATION INSTRUCTIONS FOR PART 95-5818

• DoubleDINradioprovision

NOTE:

• Majorsubdashmodificationsarenecessaryto

use this dash kit. You will need to trim the sub dash

to gain suitable depth and height.

•A)(2)DoubleDINtrimplates•B)DoubleDINbrackets

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS(soldseparately)

WiringHarness:

•70-1770-Fordharness1985-2004

•70-1771-Fordharness1998-up

•70-5519-Fordampinterfaceharness1998-2011

•70-5603-Fordampinterfaceharness1995-2002

•70-5701-Fordampinterfaceharness1998-2011

AntennaAdapter:

•Notrequired

•Dremelorcuttingtool•Smallflatblade

screwdriver•Panelremovaltool•Socketwrench

•Metra86-5618removalkeys

TOOLS REQUIRED

Ford/Lincoln 1997-2002

95-5818

See application list inside

(a) (b)

Applications

Ford

Expedition.................................................1997-2002

F-150.......................................................1997-2003

F-150Heritage.................................................. 2004

F-250................................................................ 1998

Lincoln

Blackwood......................................................... 2002

Navigator..................................................1997-2002

Table of Contents

Dash Disassembly

– AllVehicles.......................................................... 2

Kit Assembly

– DoubleDINradioprovision................................... 3

All Vehicles

1. Unclipandremovethepanelsurroundingthe

radio.(FigureA)

2. UsingtheMetra86-5618removalkeys,slidethe

radiooutoftheradiocavity.Unplugandremove

theradio.(FigureB)

3. Removethe(4)7mmscrewsatthesidesofthe

factoryclimatecontrolandremovethefactory

climatecontrol.(FigureC)

4. Cutandremoveobstructionsindashcavity.

(FigureD)

Caution: Be careful not to cut into harnesses or

electronic components.

Continue to kit assembly

95-5818 Dash Disassembly

(Figure A)

Dash Disassembly

All Vehicles Double DIN radio provision

(Figure B) (Figure C)

(Figure D)

Kit Assembly

1. AttachthedoubleDINbrackets

totheradiousingthescrews

suppliedwiththeradio.(FigureA)

2. Locatethefactorywiringharness

inthedash.Metrarecommends

usingthepropermatingadapter

fromMetraorAXXESS.

3. Re-connectthenegativebattery

terminalandtesttheradiofor

properoperation.

4. SlidethedoubleDINradio

assemblyintothemodifiedsub

dashuntilitclicksintoplace.

5. AttachtheappropriatedoubleDIN

trimplateusingthetop(2)screw

positionsoftheclimatecontrol.

(FigureB)

6. Reassembletherestofthedashin

reverseorderofdisassembly.

(Figure A)

NOTE:Majorsubdashmodificationsarenecessarytousethisdashkit.

You will need to trim the sub dash to gain suitable depth and height.

(Figure B)

CUT OUT

TOP

CUT BAR CUT BAR

Cut bar Cut bar

REV. 11/4/2013 INST95-5818

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

INSTALLATION INSTRUCTIONS FOR PART 95-5818
