Metra Electronics 99-7328 Bedienungsanleitung

INSTALLATION INSTRUCTIONS FOR PART 99-7328

99-7328

KIT FEATURES

•Recessed DIN Radio Provision with Pocket

•ISO Mount Radio Provision with Pocket

A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate

KIT COMPONENTS

Flat Blade Screwdriver/ Panel Removal Tool

•Phillips Screwdriver

1-800-221-0932

www.metraonline.com

APPLICATIONS

KIA Sorento

2007-2009

B C

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Harness:

•70-7302 - Hyundai harness 2007-up

Antenna Adapter:

•Not required

TOOLS REQUIRED:

Dash Disassembly

-KIASorento2007-2009 ...........................................1

Kit Assembly

-Recessed DIN Mount Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . 2

-ISO Mount Radio Provision with Pocket . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 3

Final Assembly ..........................................4

TABLE OF CONTENTS

99-7328

*Note:

Refer also to the instructions included with the aftermarket radio.

NOWLEDGE IS

OWER

Enhanceyour installation and fabrication skills

by enrolling inthe most recognized andrespected

mobile electronics school in our industry.

Log onto www.installerinstitute.com

or call 800-354-6782 formore information

and take stepstoward abetter tomorrow.

99-7328 DASH DISASSEMBLY

KIA SORENTO 2007-2009

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove the side trim pan-

els. (Tip: start at the bottom of the

panels)

(Figure A)

Remove (2) Phillips head screws

securing the vent panels then unclip

and remove the (2) vent panels.

(Figure C)

Remove (4) Phillips screws securing

the radio. Unplug and remove radio.

Continue to kit assembly.

Remove (2) Phillips head screws

securing the radio trim panel. Unplug

and remove panel.

(Figure B)

99-7328 KIT ASSEMBLY

RECESSED DIN RADIO PROVISION WITH POCKET

Slide the DIN cage into the radio hous-

ing and secure by bending the metal

locking tabs outward.

(Figure A)

Slide the radio into the DIN cage/hous-

ing assembly until it snaps into place.

(Figure B)

Continue to final assembly.

Note: Refer also to the instructions included with the aftermarket radio.

99-7328 KIT ASSEMBLY

ISO MOUNT RADIO PROVISION WITH POCKET

Align the holes from the ISO snap in

brackets with the holes in the side of

the radio and mount the brackets to

the radio using screws supplied with

the radio.

(Figure A)

Slide the radio/bracket assembly into

the radio housing until the assembly

snaps into place.

(Figure B)

Snap the ISO Trim-plate onto the Radio

and housing assembly.

(Figure B)

Continue to final assembly.

Note: Refer also to the instructions included with the aftermarket radio.

99-7328 FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Locate the factory wiring harness in the dash. Metra recommends using the

proper mating adapter and making connections as shown. (Isolate and individ-

ually tape off the ends of any unused wires to prevent electrical short circuit.)

Re-connect the negative batteryterminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

FINAL WIRING CONNECTIONS

Make wiring connections using the EIA color code chart shown belowand the instructions included with the

head unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and

individually tape off ends of anyunused wires to prevent electrical short circuit.

METRA / EIA WIRING CODE

12V Ignition / Acc. . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground. . . . . . . . . . . . . . . . . . Black*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Black / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer.................Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Black

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Black

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Black

Left Rear (+) . . . . . . . . . . . . . Green

Left Rear (-) . . . . . . . . . . . . . . Green / Black

*NOTE: When a Black wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’s specifications.

99-7328

NOTES

99-7328 INSTRUCTIONS

1-800-221-0932

www.metraonline.com
