INSTALLATION INSTRUCTIONS FOR PART 99-9009

86-9001 Radio Removal Tools (2 sets) • Flat Blade Screwdriver

1-800-221-0932 www.metraonline.com

KIT FEATURES

•DIN Head Unit Provision with Pocket

•ISO DIN Head Unit Provision with Pocket

A) Radio Housing • B) ISO Snap-In Brackets • C) Trim Plate

KIT COMPONENTS

TOOLS REQUIRED:

99-9009

APPLICATIONS

VW Touareg/Touareg2

2004-2010

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Wiring Harness:

•70- 9003 - VW Toureg Harness 2004-up

Antenna Adapter:

•40-EU55 Amplified VW Antenna Adapter

99-9009

Dash Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Kit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

TABLE OF CONTENTS

NOWLEDGE IS

OWER

Enhanceyour installation and fabrication skillsby

enrolling in the most recognizedandrespected

mobile electronics school in our industry.

Log onto www.installerinstitute.comor call

800-354-6782 for more informationandtake steps

toward abetter tomorrow.

99-9009

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Insert the long ends of the 86-9001

into the slots on the factory radio

and pull out to remove.

(Figure A)

2004-2010 VW TOUAREG

NOTE:

Flat edge of key should point outward.

DASH DISASSEMBLY

99-9009

KIT ASSEMBLY

Slide the DIN cage into the Radio

Housing and secure by bending the

metal locking tabs down.

(Figure A)

Slide the aftermarket head unit into

the cage and secure.

(Figure B)

DIN HEAD UNIT PROVISIONS

99-9009

KIT ASSEMBLY

Mount the ISO Brackets to the head

unit with the screws supplied with

the unit.

(Figure A)

Slide the head unit into the radio

opening until the side clips engage.

(Figure B)

ISO DIN HEAD UNIT PROVISIONS

Snap the Trim plate into the Radio

Housing.

(Figure B)

99-9009

FINAL ASSEMBLY

Locate the factorywiring harness in the

dash. Metra recommends using the

proper mating adapter and making the

connections as shown. (Isolate and indi-

vidually tape off the ends of any unused

wires to prevent electrical short circuit)

Re-connect the negative battery terminal

and test the unit for proper operation.

Reassemble radio and dash assemblies in

reverse order of disassembly.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

99-9009

NOTES

INST99-9009

1-800-221-0932 www.metraonline.com
