INSTALLATION INSTRUCTIONS FOR PART 99-9305

Flat Blade Screwdriver • Phillips Screwdriver • Drill

1-800-221-0932 www.metraonline.com

KIT FEATURES

•ISO DIN Head Unit Provision

A) Radio Housing • B) ISO Brackets • C) (4) Phillips Screws • D) (4) Phillips ISO Screws

KIT COMPONENTS

TOOLS REQUIRED:

99-9305

APPLICATIONS

BMW X3

2004-2010

(NON-NAV MODELS)

WIRING AND ANTENNA CONNECTIONS

(Sold Separately)

• 40-EU10 - European antenna adapter

• 70-9003 - European wire harness

Dash Disassembly

2004-2010 BMW X3........................................................................... 1

Kit Assembly ..................................................................................... 2

Final Assembly ................................................................................. 3

99-9305

TABLE OF CONTENTS

99-9305 DASH DISASSEMBLY

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Unclip and remove the hazard/door

lock switch.

(Figure A)

BMW X3 2004-2010

(NON-NAV MODELS)

Unclip and remove the a/c vents

above the radio.

( Figure B)

Remove (2) Phillips screws on top of

the radio/climate control panel fac-

ing down.

(Figure C)

Unclip and remove the radio/climate

control panel.

(Figure D)

Remove (2) Phillips screws securing

the radio.

(Figure D)

Secure the corresponding bracket to

the aftermarket radio using the

hardware supplied with the radio.

(Figure A)

Using a drill screw the radio/bracket

assembly into the dash using the

supplied (4) Phillips screws.

(Figure B)

Position the radio housing over the

radio face and secure using the fac-

tory hardware.

(Figure C)

NOTE:

If the ISO screws supplied with

the aftermarket radio are too big, use

the supplied (4) Phillips ISO screws.

ISO DIN HEAD UNIT PROVISION

99-9305

KIT ASSEMBLY

FINAL ASSEMBLY

Locate the factory wiring harness in the dash and make the connection as shown.

Metra recomends using the proper mating adapter and making the connections as

shown. (Isolate and individually tape off the ends of any unused wires to prevent

electrical short circuit.)

Re-connect the negative battery terminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Make wiring connections using the EIA color code chart shown below and the instructions included with the head

unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually

tape off ends of any unused wires to prevent electrical short circuit.

12V Ignition / Acc . . . Red

12V Batt / Memory . . Yellow

Ground . . . . . . . . . . . Black*

Power Antenna . . . . . Blue

Amp Turn-On . . . . . . Blue / White

Amp Ground . . . . . . . Black / White

Illumination. . . . . . . . Orange

Dimmer . . . . . . . . . . Orange / White

Right Front (+) . . . . . Gray

Right Front (-). . . . . . Gray / Black

Left Front (+) . . . . . . White

Left Front (-) . . . . . . . White / Black

Right Rear (+). . . . . . Violet

Right Rear (-) . . . . . . Violet / Black

Left Rear (+). . . . . . . Green

Left Rear (-) . . . . . . . Green / Black

*NOTE: When Black a wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’s specifications.

METRA / EIA WIRING CODE

FINAL WIRING CONNECTIONS

99-9305

FINAL ASSEMBLY

99-9305

NOTES

99-9305

NOTES

99-9305 INSTRUCTIONS

1-800-221-0932 www.metraonline.com

REV. 04/26/09
