INSTALLATION INSTRUCTIONS FOR PART 99-3300

99-3300

APPLICATIONS

MULTI KIT

(

see models list inside)

KIT FEATURES

•DIN Mount Radio Provisiion

•Shaft Mount Radio Provisiion

A) Radio Housing • Spacer

KIT COMPONENTS

Small Flat Blade Screwdriver/ Panel Removal Tool

•Phillips Screwdriver • Cutting Tool • Socket Set

1-800-221-0932

www.metraonline.com

TOOLS REQUIRED:

Dash Disassembly

Chevrolet

Blazer1998-2002 ...............................................

. . . . . . . .1

Camaro 1997-2002 ..............................................

. . . . . . . 2

-Caprice

1994-1996 ................................................

.. . . . .. 3

Cavalier1995-1999 ...............................................

. . . . . . . 4

Corvette1997-2004 ...............................................

. . . . . . . 5

-Impala

1994-1996 ................................................

.. . . . .. 3

Lumina1995-2001 ...... .........................................

. . . . . . . 6

-Malibu 1997-2000

...... ............................................

. . . . . . . 7

MonteCarlo1995-1999.............................................

. . . . . . . 6

S-10 Pickup 1998-2002. ...........................................

....... 1

Venture1997-1999 ...............................................

.. . . . .. 8

GMC

-Envoy 1998-2001

...........................................................

-Jimmy 1998-2002

.......................................................

. . . .1

-Sonoma Pickup 1998-2002

................................................

....1

Isuzu

-Hombre 1998-2001 . . .

...................................................

. . . . .1

Oldsmobile

Bravada1998-2001 .................................................

. . . . . 1

Silhouette1997-1999 .............................................

. . . . . . . 8

Pontiac

Montana1999 ....................................................

. . . . . . . 8

TransSport1997-1999..............................................

. . . . . . . 8

Kit Assembly

DIN Mount provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Shaft Mount provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Final Assembly .................................................................11

TABLE OF CONTENTS

99-3300

*Note:

Refer also to the instructions included with the aftermarket radio.

99-3300 DASH DISASSEMBLY

Chevrolet Blazer/S-10 Pickup,

GMC Jimmy/Sonoma 1998-2002, GMC Envoy,

Isuzu Hombre, Oldsmobile Bravada 1998-2001

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (2) 9/32” hex head screws

from the lower dash trim panel below

steering column.

Remove (2) 9/32” hex head screws

from bottom edge of instrument clus-

ter trim panel.

Remove (1) Phillips head screw from

above the instrument cluster.

Unclip and remove instrument cluster

trim panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Continue to kit assembly.

99-3300 DASH DISASSEMBLY

Chevrolet Camaro 1997-2002

Dash cavity

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove the radio trim

panel. (Figure A)

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio. (Figure A)

Cut and remove the rear support from

the back of radio cavity. (Figure B)

Continue to kit assembly.

99-3300 DASH DISASSEMBLY

Chevrolet Caprice, Impala 1994-1996

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (5) 9/32” hex head screws

from the ashtray cavity.

Remove (4) 9/32” hex head screws

from bottom edge of dash trim

panel.

Unclip fuse box cover and remove

(1) 9/32” hex head screw from fuse

box cavity.

Remove (2) 9/32” hex head screws

from above instrument cluster.

Engage parking brake and place

gear selector in “D1”.

Unclip and remove instrument cluster

trim panel.

Remove (1) 9/32” hex head screw

from the left edge of dash trim panel.

Unclip and remove dash trim panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Cut and remove the rear support from

the back of radio cavity. (Figure A)

Continue to kit assembly.

Dash cavity

99-3300 DASH DISASSEMBLY

Chevrolet Cavalier 1995-1999

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (3) 9/32” hex head screws

from along top edge inside of glove

box.

Remove (2) 9/32” hex head screws

from behind glove box. (Access

these screws thru cutout in rear of

glove box at top left corner.)

Remove (1) Phillips head screw from

defroster vent and remove the vent.

Remove (1) Phillips head screw from

inside defroster.

Unclip and remove the trim panel at

each of dash and remove (1) Phillips

head screw from behind panel.

Remove dash pad.

Remove (3) Phillips head screws from

top edge of instrument cluster/radio

trim panel. Unclip and remove dash

trim panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Cut and remove the rear support from

the back of radio cavity. (Figure A)

Continue to kit assembly.

Dash cavity

99-3300 DASH DISASSEMBLY

Chevrolet Corvette 1997-1999

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Using a panel removal tool pry out

on the “Ride Control” switch, unplug

and remove switch.

Unclip and remove switch trim

panel.

Remove (2) 10 MM hex head bolts

from behind panel.

Open center console door and

remove (4) screws from hinge to

remove door.

Open ashtray and remove (1) screw

securing ashtray.

Remove ashtray and remove (1)

screw from ashtray cavity.

Unclip and remove small grill to the

left of the ignition switch.

Remove one (1) screw from behind

grill. Unclip and remove dash trim

panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Continue to kit assembly.

99-3300 DASH DISASSEMBLY

Chevrolet Lumina/Monte Carlo 1995-2001

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove dash trim panel.

(It may be necessary to loosen the

lower dash trim panel below steer-

ing column.)

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Cut and remove the rear support from

the back of radio cavity. (Figure A)

Continue to kit assembly.

Dash cavity

99-3300 DASH DISASSEMBLY

Chevrolet Malibu 1997-2000

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove the radio trim

panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Continue to kit assembly.

99-3300 DASH DISASSEMBLY

Chevrolet Venture, Pontiac TransSport 1997-

1999, Oldsmobile Silhouette 1997-2000,

Pontiac Montana 1999

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove ashtray and remove (1)

Phillips head screw from ashtray

cavity.

Remove (1) Phillips head screw from

cigarette lighter cavity.

Unclip and remove the radio trim

panel.

Remove (2) 9/32” hex head screws

securing radio. Unplug and remove

radio.

Cut and remove the rear support from

the back of radio cavity. (Figure A)

Continue to kit assembly.

Dash cavity
