Metrohm 930 Compact IC Flex SeS/PP Bedienungsanleitung

930 Compact IC Flex

930 Compact IC Flex SeS/PP

Manual

8.930.8009EN / v4 / 2023-03-31

Metrohm AG

CH-9100 Herisau

Switzerland

+41 71 353 85 85

[email protected]

www.metrohm.com

930 Compact IC Flex

930 Compact IC Flex SeS/PP

2.930.1500

Manual

8.930.8009EN / v4 / 2023-03-31

Technical Communication

Metrohm AG

CH-9100 Herisau

This documentation has been prepared with great care. However, errors

can never be entirely ruled out. Please send comments regarding possible

errors to the address above.

Disclaimer

Deficiencies arising from circumstances that are not the responsibility of

Metrohm, such as improper storage or improper use, etc., are expressly

excluded from the warranty. Unauthorized modifications to the product

(e.g. conversions or attachments) exclude any liability on the part of the

manufacturer for resulting damage and its consequences. Instructions and

notes in the Metrohm product documentation must be strictly followed.

Otherwise, Metrohm's liability is excluded.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Table of contents

930 Compact IC Flex SeS/PP (2.930.1500) ￭￭￭￭￭￭￭￭ III

Table of contents

1 Introduction 1

1.1 Instrument description ......................................................... 1

1.2 Accessories and additional information ............................. 3

1.3 Symbols and conventions .................................................... 3

2 Safety 5

2.1 Intended use ......................................................................... 5

2.2 Responsibility of the operator ............................................. 5

2.3 Requirements for operating personnel ............................... 6

2.4 Safety instructions ................................................................ 6

2.4.1 General notes on safety ........................................................... 6

2.4.2 Electrical safety ........................................................................ 6

2.4.3 Tubing and capillary connections ............................................. 7

2.4.4 Flammable solvents and chemicals ........................................... 8

2.4.5 Recycling and disposal ............................................................. 8

3 Overview of the device 9

3.1 Front ...................................................................................... 9

3.2 Rear ...................................................................................... 10

3.3 Feed-throughs for capillaries and cables .......................... 12

4 Installation 15

4.1 Setting up the instrument .................................................. 15

4.1.1 Packaging .............................................................................. 15

4.1.2 Checks .................................................................................. 15

4.1.3 Location ................................................................................ 15

4.2 Capillary connections in the IC system ............................. 15

4.3 Removing transport locking screws .................................. 18

4.4 Connecting the drainage tubing and leak sensor ............ 19

4.4.1 Installing the drainage tubing ................................................ 19

4.4.2 Connecting the leak sensor .................................................... 21

4.5 Connecting the eluent bottle ............................................. 21

4.6 Installing the high-pressure pump .................................... 25

4.7 Installing an inline filter ..................................................... 26

4.8 Installing the pulsation absorber ...................................... 27

4.9 Injection valve ..................................................................... 28

Table of contents ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭

IV ￭￭￭￭￭￭￭￭ 930 Compact IC Flex SeS/PP (2.930.1500)

4.10 Metrohm Suppressor Module (MSM) ............................... 30

4.10.1 Inserting the rotors ................................................................ 30

4.10.2 Connecting the Metrohm Suppressor Module (MSM) ............. 33

4.11 Peristaltic pump .................................................................. 38

4.11.1 Installing the peristaltic pump ................................................ 38

4.11.2 Mode of operation for the peristaltic pump ........................... 42

4.12 Metrohm CO2 Suppressor (MCS) ....................................... 43

4.12.1 General information on the MCS ........................................... 43

4.12.2 Connecting the MCS ............................................................. 43

4.12.3 Installing the adsorber cartridge ............................................. 45

4.13 Installing the conductivity detector .................................. 47

4.14 Installing the amperometric detector ............................... 48

4.15 Connecting the instrument to a computer ....................... 48

4.16 Connecting the instrument to the power grid ................. 49

4.17 Initial start-up ..................................................................... 50

4.18 Connecting and rinsing the guard column ....................... 52

4.19 Connecting and rinsing the separation column ............... 54

4.20 Conditioning ........................................................................ 57

5 Operation 59

6 Operation and maintenance 60

6.1 IC system ............................................................................. 60

6.1.1 Operation .............................................................................. 60

6.1.2 Care ...................................................................................... 60

6.1.3 Maintenance by Metrohm Service .......................................... 60

6.1.4 Shutting down and recommissioning ..................................... 61

6.2 Capillary connections ......................................................... 62

6.3 Servicing the door .............................................................. 62

6.4 Handling the eluent ............................................................ 62

6.4.1 Manufacturing eluent ............................................................ 63

6.4.2 Changing the eluent .............................................................. 63

6.5 Notes on operating the high-pressure pump ................... 64

6.6 Servicing the high-pressure pump .................................... 64

6.7 Servicing the inline filter .................................................... 78

6.8 Servicing the pulsation absorber ...................................... 81

6.9 Injection valve ..................................................................... 81

6.10 Metrohm Suppressor Module (MSM) ............................... 81

6.10.1 Notes for operating the Metrohm Suppressor Module

(MSM) ................................................................................... 81

6.10.2 Taking care of the suppressor housing ................................... 82

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Table of contents

930 Compact IC Flex SeS/PP (2.930.1500) ￭￭￭￭￭￭￭￭ V

6.10.3 Servicing the Metrohm Suppressor Module (MSM) ................. 82

6.11 Peristaltic pump .................................................................. 90

6.11.1 Notes on operating the peristaltic pump ................................ 90

6.11.2 Servicing the peristaltic pump ................................................ 90

6.12 Maintenance on the Metrohm CO2 Suppressor (MCS) .... 92

6.12.1 Replacing the CO2 adsorption cartridge CW ........................... 92

6.13 Detector maintenance ........................................................ 93

6.14 Rinsing the sample path .................................................... 93

6.15 Separation column ............................................................. 94

6.15.1 Separating efficiency .............................................................. 94

6.15.2 Protecting the separation column .......................................... 95

6.15.3 Storing the separation column ............................................... 95

6.15.4 Regenerating the separation column ...................................... 95

7 Troubleshooting 96

7.1 ............................................................................................. 96

8 Technical specifications 101

8.1 Reference conditions ........................................................ 101

8.2 Instrument ......................................................................... 101

8.3 Ambient conditions .......................................................... 101

8.4 Housing ............................................................................. 102

8.5 Weight ............................................................................... 102

8.6 Leak sensor ....................................................................... 102

8.7 High-pressure pump ......................................................... 102

8.8 Injection valve ................................................................... 103

8.9 Metrohm Suppressor Module (MSM) ............................. 103

8.10 Peristaltic pump ................................................................ 103

8.11 Metrohm CO2 Suppressor (MCS) ..................................... 104

8.12 Detector ............................................................................ 104

8.13 Power connection ............................................................. 104

8.14 Interfaces .......................................................................... 105

Index 106

Table of figures ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭

VI ￭￭￭￭￭￭￭￭ 930 Compact IC Flex SeS/PP (2.930.1500)

Table of figures

Figure 1 Front ................................................................................................. 9

Figure 2 Rear ................................................................................................ 10

Figure 3 Feed-throughs on the door .............................................................. 12

Figure 4 Openings for capillaries and cables .................................................. 13

Figure 5 Ducts for capillaries ......................................................................... 14

Figure 6 Removing the transport locking screws ............................................ 18

Figure 7 Installing the eluent bottle cap ........................................................ 22

Figure 8 Installing the tubing weighting and aspiration filter .......................... 23

Figure 9 High-pressure pump with purge valve .............................................. 26

Figure 10 Inline filter ....................................................................................... 27

Figure 11 Pulsation absorber ........................................................................... 27

Figure 12 Exchanging the sample loop ............................................................ 29

Figure 13 Metrohm Suppressor Module (MSM) – Connection capillaries .......... 33

Figure 14 Peristaltic pump ............................................................................... 42

Figure 15 Connecting the MCS ....................................................................... 44

Figure 16 High-pressure pump – Parts ............................................................. 65

Figure 17 High-pressure pump – Cross-section ................................................ 72

Figure 18 Tool for piston seal (6.2617.010) ..................................................... 73

Figure 19 Removing the piston cartridge from the pump head ........................ 73

Figure 20 Inserting the piston seal into the tool ............................................... 74

Figure 21 Parts of the piston cartridge ............................................................ 75

Figure 22 Inline filter – Removing the filter ...................................................... 79

Figure 23 Parts of the Metrohm Suppressor Module (MSM) ............................ 82

Figure 24 Pump tubing connection – Replacing the filter ................................. 91

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 1 Introduction

930 Compact IC Flex SeS/PP (2.930.1500) ￭￭￭￭￭￭￭￭ 1

1 Introduction

1.1 Instrument description

The 930 Compact IC Flex is a robust ion chromatograph. It is distinguished

by:

￭Its intelligence: All of the functions are monitored, optimized and docu-

mented in an FDA-compatible manner. Intelligent components, such as

iColumns, save important data onto a chip.

￭Its compact design: It has a small footprint.

￭Its transparency: All components are easily accessible and located for

simple visibility and can be monitored during operation through a large

window.

￭Its safety: The wet end and the electronics are physically separated.

This prevents fluids from coming into contact with the electronics to a

large extent. A leak sensor is integrated into the wet end.

￭Its environmental compatibility.

￭Its low noise emission.

￭The intelligent MagIC Net software.

The 930 Compact IC Flex is operated using the MagIC Net software. A

USB cable is used to connect the device to a computer with MagIC Net

installed. The intelligent software detects the device automatically and

checks its functionality. The software controls and monitors the device,

evaluates the measured data and manages it in a database.

The 930 Compact IC Flex SeS/PP consists of the following modules:

Housing

The sturdy housing contains the instrument's electronic components,

including their interfaces and one connector for a separation column. In

addition, the housing provides space for a conductivity detector or an

amperometric detector. Capillaries and cables can be fed into and out of

the instrument through several openings.

Leak sensor

The leak sensor detects leaking liquid that collects in the instrument's base

tray. Liquid that leaks in the instrument is routed to the base tray using

drainage tubing and detected there.

High-pressure pump

The intelligent and low-pulsation high-pressure pump pumps the eluent

through the IC system. It is equipped with a chip where its technical speci-

fications and "life history" (operating hours, service data, etc.) are stored.

1.1 Instrument description ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭

2￭￭￭￭￭￭￭￭ 930 Compact IC Flex SeS/PP (2.930.1500)

Inline filter

Inline filters protect the separation column reliably from potential contam-

ination from the eluent. The filter pads with 2 µm pore size can be

replaced quickly and easily. They remove particles from the solutions, such

as bacteria and algae.

Pulsation absorber

The pulsation absorber protects the separation column from damage

caused by pressure fluctuations, e.g. when the injection valve is switched,

and reduces interfering pulsations during highly sensitive measurements.

Injection valve

The injection valve connects the eluent path to the sample path. By a

quick and precise switching of the valve, a quantity of sample solution

defined by the size of the sample loop is injected and flushed to the sepa-

ration column with the eluent.

Metrohm Suppressor Module (MSM)

The chemical suppressor MSM consists of the suppressor drive, a rotor

and, where applicable, an adapter. The suppressor drive gives you the flex-

ibility to use different rotors according to the principle "one drive – many

rotors". Suppression rotors with different capacities and construction or a

rotor for sample preparation (SPM Rotor) are readily interchangeable with

appropriate adapters as needed. The rotors are not included in the instru-

ment's scope of delivery. The rotor required for the application and any

adapter that is required must be ordered separately.

Peristaltic pump

The peristaltic pump is used for pumping sample and auxiliary solutions. It

can rotate in both directions.

Metrohm CO2 Suppressor (MCS)

The Metrohm CO2 Suppressor (MCS) removes the CO2 from the eluent

stream. This lowers the background conductivity, improves detection sen-

sitivity and minimizes the injection peak and system peak.

Detector

Metrohm offers a series of different detectors for various analysis tasks. A

suitable detector type must be ordered as a separate device.

Separation column

The intelligent separation column separates different components accord-

ing to their interactions with the column. Metrohm separation columns

are equipped with a chip where their technical specifications and history

(start-up, operating hours, injections etc) are stored.

Inhaltsverzeichnis

Andere Metrohm Laborausrüstung Handbücher

Metrohm

Metrohm 728 Bedienungsanleitung

Metrohm

Metrohm 884 Professional VA Bedienungsanleitung

Metrohm

Metrohm 917 Coulometer Bedienungsanleitung

Metrohm

Metrohm 930 Compact IC Flex Bedienungsanleitung

Metrohm

Metrohm 892 Professional Rancimat Bedienungsanleitung

Metrohm

Metrohm 942 Extension Module Vario HPG Bedienungsanleitung

Metrohm

Metrohm 728 Bedienungsanleitung

Metrohm

Metrohm 872 Bedienungsanleitung

Metrohm

Metrohm 790 Personal IC Bedienungsanleitung

Metrohm

Metrohm 832 KF Thermoprep Bedienungsanleitung

Metrohm

Metrohm 850 Professional IC Bedienungsanleitung

Metrohm

Metrohm 806 Bedienungsanleitung

Metrohm

Metrohm 800 Dosino Bedienungsanleitung

Metrohm

Metrohm 785 DMP Titrino Bedienungsanleitung

Metrohm

Metrohm 815 Bedienungsanleitung

Metrohm

Metrohm 870 KF Titrino plus Bedienungsanleitung

Metrohm

Metrohm Titrino 758 KFD Bedienungsanleitung

Metrohm

Metrohm 942 Extension Module Vario LQH Bedienungsanleitung

Metrohm

Metrohm 942 Extension Module Vario ChS-PP Bedienungsanleitung

Metrohm

Metrohm 895 Bedienungsanleitung

Metrohm

Metrohm 869 Bedienungsanleitung

Metrohm

Metrohm 751 GPD Titrino Bedienungsanleitung

Metrohm

Metrohm 882 Compact IC plus Bedienungsanleitung

Metrohm

Metrohm 942 Extension Module Vario SeS/PP Bedienungsanleitung

Beliebte Laborausrüstung Handbücher anderer Marken

Qiagen

Qiagen DML 3000 Bedienungsanleitung

Queensgate

Queensgate NANOSCAN OP400 Programmierhandbuch

Conviron

Conviron GEN1000-GE Bedienungsanleitung

Parr Instrument

Parr Instrument 4560 Bedienungsanleitung

IKA

IKA IC control Bedienungsanleitung

Integra

Integra DOSE IT Bedienungsanleitung

Agilent Technologies

Agilent Technologies 5800 ICP-OES Bedienungsanleitung

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Bedienungsanleitung

NI PXI-5422 Handbuch

Collomix

Collomix Aqix Bedienungsanleitung

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Bedienungsanleitung

Ocean Insight

Ocean Insight FLAME-NIR+ Bedienungsanleitung

Parker

Parker ALIGN-MG-NA Bedienungsanleitung

BD 644787 Bedienungsanleitung

DENTAURUM

DENTAURUM Compact Megaplus Bedienungsanleitung

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Bedienungsanleitung

VWR

VWR SAS Super IAQ Bedienungsanleitung

illumina

illumina MiSeqDx Bedienungsanleitung
