VACUUM CLEANER

OPERATION INSTRUCTIONS MANUAL

VCS38A13L

Please read this Instruction Manual carefully before operating, and keep it properly.

Contents Safety Introduction

Product Introduction

Product Operation

Product Maintenance

Trouble Shooting

Safety Introduction

1. Do not place the vacuum cleaner close to heat

sources, radiation, or burning cigarette, Do not use

the appliance to remove the following objects:

- All liquids such as water and solvents.

- Lime, cement, ash and other construction dust

and garbage.

- Hot objects, such as cigarette butts.

- Sharp objects, such as glass shards, etc.

- Inﬂammable and explosive articles, such as gaso

line or alcohol products.

2. Do not let children play with or operate the vacuum

cleaner to prevent accidents.

3. Your vacuum cleaner is an electric appliance: It

must be used appropriately.

4. Do not leave the operating vacuum cleaner

unattended.

5. The power must be turned oﬀ during cleaning,

maintenance or when in storage.

6. Do not pull the power plug to turn oﬀ the vacuum

cleaner. Hold the plastic part of the plug to remove

it from the power socket.

7. The power supply voltage must correspond to that

of the vacuum cleaner charging voltage.

8. Keep the power cord away from sharp objects to

prevent it from being damaged.

9. To prevent ﬁres do not immerse the vacuum

cleaner in water, do not expose it to any heating

appliances.

10. Do not drag the power cord when moving the

charging station.

11. In the case of below situations do not use the

vacuum cleaner and send it immediately to the

nearest approved maintenance facility if:

- The vacuum cleaner fell and consequently

damaged.

- The power cord is damaged.

12. Stop operating the vacuum cleaner if the suction

inlet is blocked to prevent damages (such as

overheating) to the motor or deformations to the

vacuum plastic parts occasioned by overheating

motor.

13. Do not press the dust cup button during handling

to prevent the machine from falling oﬀ.

Product Introduction

Main Body

Dust Cup

3Hose

Extension Tube

Combination Tool

Main Brush

Note: all parts are assembled in the direction of the arrow, and the combination of the suction

brush and the small can be used directly in the pipe or metal tube.

Product Operation

Product use

Press the ON/OFF button:

Control the start and stop of the vacuum cleaner.

02.

03. Press the receiving button:

the power line is automatically rolled back into the fuselage.

Caution

Please slowly take up the cord, to avoid the power cord or power plug bruising human body

or furniture in the process of taking up.

Pull

04. Machine dismantlement:

Dust cup, main body, air sea and air cover can be disassembled, convenient to clean and

replace with loss accessories.

Dust cup

Main body

Air sea Air cover

Pull out the power cord to connect the power supply:

When you see the red mark on the power cord, do not pull out the cord outward.

01.

Brush use:

Press the pedal button and the bristles will stick out.

05.

Composite brush use:

According to the direction of arrow, 45 ° rotating brush out.

06.

Attachment:

The attachment can be used as follows.

07.

Bristles stick out

Press

Product Maintenance

Dust cup maintenance

Open the dust cup:

Lift the lid on the release button to open the lid, then take out the internal parts.

01.

Remove the ﬁlter cotton cleaning:

After opening the dust cup, the ﬁlter cotton shall be cleaned.

02.

Product Maintenance

Dust cup cleaning

01.

Remove the

dust cup

Dump garbage: Gently push the dust button and dump the garbage.

02.

Push

Remove the dust cup: Press the dust bucket release button, gently pull the dust bucket

handle, then remove the dust bucket.

Clean the ﬁlter cotton

Remove and clean the ﬁlter core:

Put the ﬁlter up and wash the ﬁlter under the tap.

03.

In case of malfunction, please refer to the following table

TROUBLESHOOTING

If the problem still can’t be solved, please contact local service center.

Solution

- Reinsert the plug

- Check the circuit breaker

- Press the machine's power switch

- Unplug the plug and wait for the thermal protector

to recover

- Clean up the stemming

- Timely clean up garbage

- Clean the ﬁlter cotton

The vacuum

cleaner does not

work

Possible reason

- The main brush or accessories are clogged

- Dust in the dust barrel is too full

- Dust in the dust cup ﬁlter cotton is too much

Suction becomes

weaker

Problem

- The power plug is not properly plugged into

the socket

- No electricity on the power socket

- The vacuum cleaner switch is not turned on

- Motor thermal protector acts

Install the ﬁlter core:

After cleaning, put the ﬁlter into the dust cup and notice the direction of the arrow.

04.

Caution

1. The ﬁlter parts can be put back for use only after being cleaned and dried. It is recommended

to have sun exposure for 24 hours to ensure it is thoroughly dried.

2. All parts must be ensured to be properly installed, otherwise it will cause product failure.

3. Water is not allowed to penetrate into the vacuum cleaner electrical components, or otherwise

may cause product failure.

Load the ﬁlter cotton.

05.
